Outdoor Heater
Model No. GM124-013
Retain these instructions for future use.
TM
WARNING:
Improper installation, adjustment,
alteration, service or maintenance
can cause injury or property
damage.
Read the instructions thoroughly
before installing or servicing this
equipment.
FOR OUTDOOR USE
ONLY
OPERATES ON LPG
CARBON MONOXIDE HAZARD
This appliance can
produce carbon
monoxide which has
no odour.
Using it in an enclosed
space, eg. boat,
caravan, tent, car,
campervan or house,
may cause death.
CARBON MONOXIDE HA
This appliance can produce carb
monoxide which has no odour.
Using it in an enclosed space, e
caravan, tent, car, campervan o
house, may cause death.
Advertisement
Table of Contents
Related Manuals for Gasmate Infeno GM124-013
Summary of Contents for Gasmate Infeno GM124-013
- Page 1 Outdoor Heater Model No. GM124-013 WARNING: FOR YOUR SAFETY Improper installation, adjustment, If you smell gas: alteration, service or maintenance 1. Shut off the gas to the can cause injury or property appliance. damage. 2. Extinguish any open flame. Read the instructions thoroughly before installing or servicing this 3.
-
Page 2: Installation
Installation, Operation and Maintenance Instructions INSTALLATION Combustible materials are considered to be wood, Important Safety Rules: compressed paper, plant fibres, plastic, plexiglas or This appliance must only be used in a well ventilated other materials capable of being ignited and burned. area. Such materials shall be considered combustible even 1. This appliance shall not be installed or used indoors, though flame proofed, fire-retardant treated or plastered. in buildings, garages or any other enclosed area. Additional clearance may be required for glass, painted surfaces and other materials which may be damaged by 2. DO NOT place articles on or against this appliance. radiant or convection heat. 3. DO NOT use or store flammable materials near this 4. The appliance must be placed on a level and adequate appliance. footing and be readily accessible. - Page 3 7. The hose assembly should be properly located out of 6. Leak test the connection using a soapy water solution. pathways where people may trip over it. The hose Ensure no bubbles appear before proceeding. must be protected from contact with hot or sharp 7. Slowly open the gas cylinder valve all the way. Do not surfaces both during use and while in storage. The put excessive force on the valve at the full open hose assembly should be visually inspected prior to position, to avoid damaging the valve. each use of the appliance. If excessive abrasion or 8.
- Page 4 PATIO HEATER - For Outdoor Use Only Minimum Clearance from Combustible Surfaces*: 600mm 515mm Chimney cover Weather resistant heat reflector prevents water from entering the combustion zone and reflects heat down. Heat exchange Safety guard protects the full tube has a large height of the heat exchanger tube.
-
Page 5: General Assembly
GENERAL ASSEMBLY Connecting & Disconnecting to Gas Source IMPORTANT: Before connecting and disconnecting appliance to gas source, make sure control knob is in ‘OFF’ position. CAUTION: When the appliance is not in use, the gas must be turned off at the cylinder. Familiarise yourself with the general information and safety guidelines located at the front of this manual. Check: 1. The cylinder is filled. A sloshing sound will be heard when shaken. 2. The control knob is in the ‘OFF’ position. Connecting 1. -
Page 6: Assembly Instructions
ASSEMBLY INSTRUCTIONS Note: Remove any transit protection material Step 1 Step 2 To assemble unit - partially open gas chamber door. After heat exchange tube is fully extended, rotate Carefully lift heat reflector until entire heat exchange tube counter-clockwise until stopped. is exposed. Step 3 Step 4 Fully open gas chamber door. Remove knob from door Locate (3) holes to lock heat exchange tube in place. and place on control stem. Insert (3) included screws into holes. - Page 7 ASSEMBLY INSTRUCTIONS Step 5 Step 6 Place battery in compartment below control panel. Place the gas cylinder (not included) into the base assembly, and fix it with fixing chain. Attach the regulator to the cylinder, turn clockwise to tighten it securely. Make sure to check for leaks once the cylinder has been positioned - see instructions overleaf to check all hose connections. Battery(1.5V) (not included) Tighten...
- Page 8 ASSEMBLY INSTRUCTIONS ASSEMBLY INSTRUCTIONS STEP 8 STEP 7 Ensure cylinder valve is in its full off position. Check Turn on the gas cylinder ensuring that the control knob on the outdoor heater is turned OFF at this point. for any damage to either the cylinder connection or DO NOT ATTEMPT TO LIGHT THE HEATER!!.
-
Page 9: Troubleshooting
TEST FIRING APPLIANCE Test fire heater, following the lighting instructions on heater. Leak test all gas connections with soapy water. Soap bubbles indicate gas leakage. DO NOT use a flame to test for gas leaks. WARNING: White smoke may appear around the radiant head during the first minute of the initial firing. TROUBLE SHOOTING Problem Possible Causes Main burner won’t light • No gas • Low gas pressure • Blockage in orifice • Manual valve not in ‘LOW’ or ‘HIGH’ position Note: If the appliance cannot be adjusted to perform correctly it should not be used until serviced or repaired. Warning: Improper installation, adjustment, alteration, service or maintenance can cause injury or property damage. Any modifications or adjustments made to product without prior authority from the manufacturer will void any warranty claims. Read the installation, operating and maintenance instructions thoroughly before installing or servicing this equipment. -
