Summary of Contents for Erbauer ERI490CSW
- Page 1 ERI490CSW 18V CIRCULAR SAW ERI490CSW...
- Page 2 Original Instructions (Version 1.1)
- Page 3 Congratulations on your purchase of a quality power tool from Erbauer (UK) Ltd. This product should give you reliable service but for your peace of mind this power tool does carry a 2 year guarantee, the terms of which are detailed below.
-
Page 4: General Power Tool Safety Warnings
GENERAL PoWER TooL SAfETy WARNINGS Warning! Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future reference. The term “power tool” in the warnings refers to your mains-operated (corded) power tool or battery-operated (cordless) power tool. - Page 5 Liquid ejected from the battery may cause irritation or burns. Service a) Have your power tool serviced by a qualified repair person using only identical replacement parts. This will ensure that the safety of the power tool is maintained. 18V CIRCULAR SAW ERI490CSW...
-
Page 6: Further Safety Instructions For All Saws
SAfETy WARNINGS foR ALL SAWS Danger: Keep hands away from cutting area and the blade. Keep your second hand on auxiliary handle, or motor housing. If both hands are holding the saw, they cannot be cut by the blade. b) Do not reach underneath the workpiece. The guard cannot protect you from the blade below the workpiece. - Page 7 11. Never use saw blades made from high speed steel (HSS). 12. Always check walls, floors and ceilings to avoid hidden power cable and pipes. 13. Do not cut material containing asbestos. 14. Do not use circular saw to cut tree limbs or logs. 18V CIRCULAR SAW ERI490CSW...
- Page 8 FOR CHARGER 1. This appliance is not intended for use by persons (including children) with reduced physical,sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
- Page 9 The declared vibration emission been measured in accordance with a standardised test stated above and may be used to compare one tool with another tool. The declared vibration emission value may also be used in a preliminary assessment of exposure. 18V CIRCULAR SAW ERI490CSW...
- Page 10 Warning: The vibration emission value during actual use of the power tool can differ from the declared value depending on the ways in which the tool is used dependant on the following examples and other variations on how the tool is used:- How the tool is used and the materials being cut or drilled.
-
Page 11: Residual Risks
Be sure the supply is the same as the voltage given on the rating plate for the charger. The charger is fitted with a two-core cable and plug. Remove the mains plug from socket before carrying out any adjustment or servicing. 18V CIRCULAR SAW ERI490CSW... - Page 12 SyMBoLS To reduce the risk of injury, user must read instruction manual Warning Double insulation Indoor use only 1h charging time Do not expose to rain or water Do not burn Wear gloves Always charge the battery pack between temperatures 0°C to 30°C. Ideal charging temperature is 18°C to 24°C.
- Page 13 18V CIRCULAR SAW ERI490CSW...
- Page 14 LOCK-OFF BUTTON ON/OFF SWITCH FRONT HANDLE SPINDLE LOCK BUTTON BASE PLATE ANGLE SCALE BASE PLATE BEVEL LOCK KNOB PARALLEL GUIDE LOCK KNOB CUTTING MARK, 45° CUTTING MARK, 0° PARALLEL GUIDE BASE PLATE LOWER GUARD LEVER LOWER BLADE GUARD FIxED GUARD VACUUM ADAPTER BATTERY PACK BATTERY PACK RELEASE BUTTON...
-
Page 15: Technical Data
: 96dB(A) =3.0dB(A) Wear ear protection when sound pressure is over 80dB(A) ACCESSoRIES 3.0Ah 18V Li-Ion Battery packs 1h Charger Hex key Parallel guide Dust adapter Saw blade(Ø140 x Ø10 x 1.6mm, 40Teeth) Charger stands 2pcs 18V CIRCULAR SAW ERI490CSW... -
Page 16: Intended Use
oPERATIoN INSTRUCTIoNS Note: Before using the tool, read the instruction book carefully. INTENDED USE The machine is intended for lengthways and crossways cutting of wood with straight cutting lines as well as bevel angles to 50° while resting firmly on the work piece. -
Page 17: Changing The Saw Blade
Clean the saw blade and all the clamping parts to be assembled. Tilt back the lower blade guard (13) and hold it firmly with the lower guard lever (12). Place the saw blade (20) onto the inner flange (19). Assemble 18V CIRCULAR SAW ERI490CSW... - Page 18 the outer flange (21) and the blade bolt (22). Use the hex key to tighten the blade bolt (22) in anti-clockwise direction with 1/4 turn more than finger tight. Take care that the mounting positions of the inner flange and outer flange are correct. When mounting: Ensure that the cutting direction of the teeth (direction of arrow on saw blade) and the direction-of-rotation arrow on the blade...
- Page 19 Slide the parallel guide arm through both fixtures to achieve the required cutting distance and tighten screw to lock into position (7). It can be used from both sides of the base plate Fig 8 18V CIRCULAR SAW ERI490CSW...
- Page 20 (11).There is a cutting guide notch on the front of the base plate (11) for using with a parallel guide (10). For straight cuts, use the 0° guide mark to align with your parallel guide scale. For a 45° bevel cut, use the 45°...
-
Page 21: Environmental Protection
Do not attempt to open or remove any of the components. 18V CIRCULAR SAW ERI490CSW... -
Page 22: Plug Replacement
PLUG REPLACEMENT (UK & IRELAND oNLy) If you need to replace the fitted plug for charger then follow the instructions below. IMPORTANT The wires in the mains lead are colored in accordance with the following code: BLUE = NEUTRAL BROWN = LIVE As the colors of the wires in the mains lead of this appliance may not correspond with the colored markings identifying the terminals in your plug,... -
Page 23: Declaration Of Conformity
EN 61000-3-2 EN 61000-3-3 EN 60745-1 EN 60745-2-5 EN 62233 EN 60335-1 EN 60335-2-29 Authorised Signatory and technical file holder Date: 01/11/12 Signature: Name / title: Peter Harries / Quality Manager Erbauer (UK) Ltd. Trade House, Mead Avenue, BA22 8RT...
