- Page 1 OPERATING MANUAL KUMJRRW180CA YEARS Warranty (Power Source) Please read and understand this instruction manual carefully before the installation and operation of this equipment. © Welding Guns Of Australia PTY LTD 2012...
-
Page 2: Table Of Contents
UNI-MIG welders are manufactured and compliant with - AS/NZ60974.1 2006 - AS60974-6:2006 guaranteeing you electrical safety and performance. -
Page 3: Safety
SAFETY Welding and cutting equipment can be dangerous to both the operator and people in or near the surrounding working area, if the equipment is not correctly operated. Equipment must only be used under the strict and comprehensive observance of all relevant safety regulations. Read and understand this instruction manual carefully before the installation and operation of this equipment. - Page 4 Fire hazard. Welding on closed containers, such as tanks,drums, or pipes, can cause them to explode. Flying sparks from the welding arc, hot work piece, and hot equipment can cause fires and burns. Accidental contact of electrode to metal objects can cause sparks, explosion, overheating, or fire.
-
Page 5: Working Environment
CAUTION 1. Working Environment. 1.1 The environment in which this welding equipment is installed must be free of grinding dust, corrosive chemicals, flammable gas or materials etc, and at no more than maximum of 80% humidity. 1.2 When using the machine outdoors protect the machine from direct sun light, rain water and snow etc; the temperature of working environment should be maintained within -10°C to +40°C. -
Page 6: Technical Data
MMA/TIG option accessories. The-ARC180 gives you the best of both worlds great portability, with the power to get the job done. Built to our specification and manufactured in compliance to AS/NZ60974.1 Product Code: KUMJRRW180CA MMA option includes: ARC180 Machine, Earth Lead & Arc Lead 16mm x 4m, PVC Carry Case Product Code: KUMJRRW180CT TIG option includes: ARC180 Machine, Earth Lead &... -
Page 7: Machine Layout Descriptions
FRONT MAChINE LAYOUT DESCRIPTION Thermal Alarm LED Primary Power LED VRD LED Voltage Reduction Device Amperage Control Dial MMA /TIG Selector Switch Negative Output Positive Output Terminal Terminal Rear Machine Layout Description On /Off Power Switch Primary Input Power Lead... - Page 8 INSTALLATION SET UP FOR MMA (STICk) WELDING WITh MMA-TIG180 Please install the machine strictly according to the following steps. The protection class of this machine is IP21, so avoid using it in rain. Connection of Input Cables Primary input cable is supplied with this welding equipment. Connect the primary input cable with power supply of required input voltage.
- Page 9 MMA (Manual Metal Arc) Welding MMA (Manual Metal Arc) General Description One of the most common types of arc welding is manual metal arc welding (MMA) or stick welding. An electric cur- One of the most common types of arc welding is manual metal arc welding (MMA) or stick welding. An electric rent is used to strike an arc between the base material and a consumable electrode rod or ‘stick’.
- Page 10 MMA (Stick) Welding Fundamentals Electrode Selection As a general rule, the selection of an electrode is straight forward,in that it is only a matter of selecting an electrode of similar composition to the parent metal. However, for some metals there is a choice of several electrodes, each of which has particular properties to suit specific classes of work.
- Page 11 RECOMMENDED ELECTRODE CLASSIFICATION & SELECTION CHART APPLICATION DIAMETER PACKAGE PART No ESR11 2.5 / 3.2mm HANDYPACK ESR-11-BLISTER General-purpose electrode for structural steelwork, workshop 2.5mm 2.5KG PACK ESR-11-2.5mm-2.5kg and maintenance welding. Easily operated in positional welding, including vertically-down. Good gap-bridging. Possible to use 2.5mm 5.0KG PACK ESR-11-2.5mm-5kg...
- Page 12 INSTALLATION AND SET UP FOR DC TIG WELDING FOR MMA-TIG180 (1) Switch on the machine, select the TIG function with the TIG/MMA selector switch. (2) Insert the power cable plug of the TIG torch into the Negative socket on the front of the machine and tighten it.
- Page 13 LIFT ARC DC TIG OPERATION FOR MMA-TIG180 Lift Arc ignition allows the arc to be started easily in DC TIG by simply touching the tungsten to the work piece and lifting it up to start the arc. This prevents the tungsten tip sticking to the work piece and breaking the tip from the tungsten electrode.
-
Page 14: Dc Tig Welding
DC TIG Welding The DC power source uses what is known as DC (direct current) in which the main elec- trical component known as electrons flow in only one direction from the negative pole (terminal) to the positive pole (terminal). In the DC electrical circuit there is an electrical principle at work which should always be taken into account when using any DC circuit. -
Page 15: Tig Welding With Filler Wire Technique
TIG Welding Fusion Technique Manual TIG welding is often considered the most difficult of all the welding processes. Because the welder must maintain a short arc length, great care and skill are required to prevent contact between the electrode and the workpiece. Similar to Oxygen Acety- lene torch welding, TIG welding normally requires two hands and in most instances requires the welder to manually feed a filler wire into the weld pool with one hand while manipulating the welding torch in the other. -
Page 16: Tungsten Electrodes
Tungsten Electrodes Tungsten is a rare metallic element used for manufacturing TIG welding electrodes. The TIG process relies on tung- sten’s hardness and high-temperature resistance to carry the welding current to the arc. Tungsten has the highest melting point of any metal, 3,410 degrees Celsius. Tungsten electrodes are nonconsumable and come in a variety of sizes, they are made from pure tungsten or an al- loy of tungsten and other rare earth elements. -
Page 17: Tungsten Preparation
Tungsten Preparation Always use wheels when grinding and cutting. While tungsten is a very hard material, the surface of a DIAMOND diamond wheel is harder, and this makes for smooth grinding. Grinding without diamond wheels, such as aluminium oxide wheels, can lead to jagged edges, imperfections, or poor surface finishes not visible to the eye that will contrib- ute to weld inconsistency and weld defects. - Page 18 Suregrip Series 17V TIG TORCH 150A AIR COOLED TIG WELDING TORCH Rating: 150Amp DC, 105Amp AC @35% duty cycle. For use with non gas solenoid machines Wear Parts Identification Next Page Torch Model Description Part Number 17V Suregrip TIG Torch Package c/w 2m Gas Hose 17V-4MCP50 17V-8MCP50 Spare Parts...
- Page 19 Suregrip Series Standard Front End Parts 17V TIG TORCH Part # Description Part # Description Part # Description 18CG Cup Gasket 10N30 Collet Body 1.0mm 10N49L Long Alumina Nozzle Ø 10mm 10N31 Collet Body 1.6mm 53N48L Long Alumina Nozzle Ø 11mm 10N32 Collet Body 2.4mm...
-
Page 20: Mma (Stick) Welding Trouble Shooting
MMA (Stick) WELDING TROUBLE SHOOTING The following chart addresses some of the common problems of MMA welding. In all cases of equipment malfunction, the manufacturer’s recommendations should be strictly adhered to and followed. 1: No arc Possible Reason Suggested Remedy Incomplete welding circuit Check earth lead is connected. -
Page 21: Tig Welding Trouble Shooting
TIG WELDING TROUBLE SHOOTING The following chart addresses some of the common problems of DC TIG welding. In all cases of equipment malfunction, the manufacturer’s recommendations should be strictly adhered to and followed. 1: Tungsten burning away quickly Possible Reason Suggested Remedy Incorrect Gas Check that pure Argon is being used... - Page 22 8: Arc dif cult to start or will not start DC welding Possible Reason Suggested Remedy Incorrect machine set up Check machine set up is correct No gas, incorrect gas ow Check the gas is connected and cylinder valve open, check hoses, gas valve and torch are not restricted.
- Page 23 SPARE PARTS IDENTIFICATION - ARC180DC Part Number Description Part Number Description 1. 10037834 front plastic panel 10. 10006650 Single-phase rectifier bridge 2. 10016485 carry strap / handle 11. 10007251 IGBT 3. 10004966 TIG/MMA selector switch 12. 10037435 main PCB 4. 10037151 panel socket 35-50 13.
- Page 24 Email: sales@unimig.com.au / Web: www.unimig.com.au ABN: 14 001 804 422 Welding Guns Of Australia Pty Ltd (‘Us’, ‘We’) warrants that the following products under UNI-MIG, UNI-TIG, UNI-PLAS, UNI-FLAME, TECNA, T&R, HIT-8SS & ROTA, supplied by Us and purchased by you from an Authorised UNI-MIG, UNI-TIG, UNI-PLAS, UNI-FLAME, TECNA, T&R, HIT-8SS &...
- Page 25 WARRANTY / RETURNS / EXCHANGES We understand that sometimes you may need to return a product you have purchased from Welding Guns Of Australia PTY LTD Authorised Dealer Network, to assist you, we have set out below the Welding Guns Of Australia PTY LTD Returns Policy that you should know.
- Page 26 Failure or any breakage caused by overload, dropping or abusive treatment or use by the customer • Repair, modifications or other work carried out on the product other than by an Authorised UNI-MIG, UNI-TIG, UNI-PLAS, UNI-FLAME, TECNA, T&R, HIT-8SS & ROTA Service Dealer...
- Page 27 Input Cord, Inter-connecting Cord, Triggering Cable. This Warranty does not cover products purchased: • From a non-authorised UNI-MIG, UNI-TIG, UNI-PLAS, UNI-FLAME, TECNA,T&R, HIT-8SS & ROTA Dealer (such as purchases from unauthorised retailers and purchases over the Internet from unauthorised local/international sellers or sites such as EBay) •...
- Page 28 © Welding Guns Of Australia PTY LTD 2012 Welding Guns Of Australia Pty Ltd ABN: 14 001 804 422 PO Box 3033, Lansvale NSW 2166, AUSTRALIA 112 Christina Rd, Villawood, NSW 2163 Phone: (02) 9780 4200 Fax: (02) 9780 4244 Email: sales@unimig.com.au / Web: www.unimig.com.au...
