Summary of Contents for Grandview LF-MixxFII

  • Page 1 Fantasy Integrated TabTensioned Motorized Screen Model:LF-MIxxF...
  • Page 2 Description Floating wall bracket Top panel Alluminium housing Upper groove Locking piece String Lower groove Screen fabric Locking screw Bottom rod Accessories Floating mounting bracket (2pcs) 5×40mm Tapping screw & cap (8sets) M5x10 Screw (6pcs) Ceiling hanger (2pcs) Trigger line ( 1pc ) Remote Controller External IR receiver...
  • Page 3: Wall And Ceiling Mount Installation

    Installation Attention: > Please make sure there is no dust or dirt on the fabric surface before rolling it back to the casing Take out all the parts from the package and following the accessories guideline ensure all the parts are there. >...
  • Page 4 3.Loosen the locking screw to lower the locking piece down all the way (figure 6-7) Other Options Connection Diagram 一 . Function Destription for convertion from FM to IR Control When you insert the Wireless Synchro Convertor Receiver into EXTIR plug of the screen(Figure 45), you can use FM wireless remote control device.
  • Page 5: Rs232 Interface Settings

    Plug one side of the signal cord into the computer output jack at left side of the screen's end cap, the other side of the singal cord to the Central Control jack, RS232 or Grandview Wall Switch (Figure 41-42), and then you can control the up/stop/down of the screen via central control or computer.
  • Page 6: Operating Instructions

    Operating Instructions 5. Fasten the Fixing screw on the bracket, to fix casing tightly onto the brackets.( Figure 33-34 ) Function Description Press down and open the end cap door before using the control interface. Cover up the door if you do not need the external function.
