Grandview FA-MIxx II User Manual

Fantasy series integrated screen with ir remote control

Advertisement

Quick Links

Advertisement

loading
Need help?

Need help?

Do you have a question about the FA-MIxx II and is the answer not in the manual?

Questions and answers

Summary of Contents for Grandview FA-MIxx II

  • Page 2: Installation Steps

    Installation Floating wall bracket installation 1. Choose screws for mounting according to wall material. ( Tips: Wood screws for wood wall, and Tapping screws for concrete wall.) 2. Mount the brackets onto the wall, assuring they are at the horizontal level. (Tips: draw an erasable level line when mounting the brackets) (Figure 1) Here below are the details: Figure 24 Installation Steps...
  • Page 3: Function Description

    Operating Instructions 5. Fasten the Fixing screw on the bracket, to fix casing tightly onto the brackets.( Figure 33-34 ) Function Description Press down and open the end cap door before using the control interface. Cover up the door if you do not need the external function.
  • Page 4 Plug one side of the signal cord into the computer output jack at left side of the screen's end cap, the other side of Supply Control Adapter the singal cord to the Central Control jack, RS232 or Grandview Wall Switch (Figure 41-42), and then you can control the up/stop/down of the screen via central control or computer.
