The Front Panel

Peak LEDs

For the cleanest
recording, adjust
the Gain so the
level reaches at
least -6 on the
Input Bargraph
Meter, but never
ThE FRONT PANEl
lights the Clip LED
The Lambda Studio™ front panel offers the following features:
on the loudest
sound you'll be

MIC 1-2 GAIN

recording. If you
These knobs adjust the input gain levels of the Mic 1 and Mic 2 inputs.
see the Peak LED
light constantly,

LINE 1-2 GAIN

turn the Gain
These knobs adjust the input gain levels of the Line 1 and Line 2 inputs.
knob down until it
flashes only occa-
PEAK LEDS
sionally, on the
These LEDs light when the input signal is within 5dB of analog clipping. If the Peak
loudest part of the
LEDs flicker occasionally, the signal is approaching clipping levels, but does not neces-
performance.
sarily indicate distortion or actual clipping.
DO NOT TURN

MONITOR ASSIGN

DOWN A GAIN
These buttons select whether a pair of analog audio sources will be heard in stereo or
CONTROL TO
mono in the Direct Monitor Mix. In Stereo mode, the left inputs (Mic 1, Line 1) are
GET THE RIGHT
routed to the left monitor and right (Mic 2, Line 2) inputs are routed to the right
MIX IN YOUR
monitor.
HEADPHONES OR
MONITORS WHILE
In Mono mode, you'll hear the selected inputs in the center of the Direct Monitor Mix
RECORDING. USE
through the Headphone or Line outputs.
THE Monitor
Mix CONTROL
When a Monitor switch is in Mono, it does not change the signals going to the com-
FOR THIS
puter in any way—they will still be separate and stereo in the computer.
PURPOSE.
Monitor Assign
Line 1 Gain
Monitor Assign
Monitor Mix Control
USB LED
1/4" Instrument Input Jack
10
Mic 1-2 Gain
Mic 1
Mic 2
Peak
Peak
Monitor
Stereo Mono
Line 1 Line 2
Peak
Peak
Monitor
Stereo Mono
Output Level
Monitor Mix
Direct Playback
Clip
-6
-20
-40
USB +48V
Instrument
Peak LEDs
Line 2 Gain
Output Level
Input Bargraph Meter
+48V Phantom Power LED
1/8" Headphone Output Jack
