Standard Live Setup

The standard live setup for VoiceTone Double couldn't be
easier - put Double between your microphone and your
microphone input on your sound system. In this
configuration the Left Output produces the mixed wet and
dry mono signal.The Right Output produces your dry voice
for use with the Mono Live Sound Engineer configuration
(pg 17); it is not required for standard operation.
Configuring Standard Setup:
1. Connect your microphone to Double's Mic Input.
2. Connect the Left Output to a mic input channel on
your sound system.
NOTE:
The default for Double is stereo mode off (mono). If
the stereo LED is on but you prefer mono, press and
hold the two switches under the Stereo LED to
change back to mono.
Setup Configurations
3. Connect Double's power adapter to main power
and to the Power Input on Double.
15
