Front & Back Panel Descriptions
1 2
5
6
7
9
12
3 4
10
1.
Input Knob
Controls the microphone pre-amplifier gain. Double can
accept dynamic or condenser microphones.
2. Input Light
Indicates the input level of the microphone. Flashing
green, sometimes orange is good. Flashing red is clipping
- not good!
3. Pitch and Time Edit Knobs
Allows you to add more or less pitch and time
8
humanization to the current patch.
4. Overdub and μMod Edit Knobs
Raises or lowers the mix levels of the Overdub voices
versus the μMod effects block.
5. Bank and Patch Display
Shows the current bank and patch
