HOBIE ICAT
ASSEMBLY MANUAL

List of the parts

Your iCat is delivered in 5 parcels (6 parcels if you have the Gennaker option) See detail below :
Illustration
Copyright HCE 2010 - www.hobie-cat.net
Issued by : AR Date : 05/2010 Up-date : 0
N° Description
Front crossbar
Rear crossbar
Left rudder assembly
Right rudder assembly
Tiller crossbar
1
Boom
Wire bag
Rig bag + ropes
Gennaker rig kit (option)
Telescopic carbon tiller extension
Mainsail (white or smoke)
Mainsail battens
2 Daggerboards x 2
Gennaker sail (option) white or black
Trampoline
 Mast
Right hull
4-5
Left hull
6 Gennaker pole (option)
Page : 12/
Reference
17762500
17762600
17762170
17762180
17762260
17712800
17760500
1778000
1777020
9950260
1774000
17750910
17725800
17742700
17756182
17756180
1777000
.../...
