- Page 1 Ref : MM_ICAT Issued by : AR Date : 05/2010 Up-date :0 Page : 1/52 HOBIE ICAT OWNER’S MANUAL...
- Page 2 We offer this manual as a guide to increased safety and enjoyment of your new boat. The purpose of this publication is to provide easy, simple and accurate instructions on how to get your Hobie ready for the water. Please read them carefully and familiarize yourself with the boat and all of the parts spread before you.
-
Page 3: Table Of Contents
Tiller crossbar & stick 4-51 Gennaker (option) Contact ANNEXES: • SPARE PART ILLUSTRATED GUIDE • CONFORMITY KEEP THIS MANUAL IN A SAFE PLACE AND GIVE IT TO THE NEW OWNER IF YOU SELL YOUR BOAT Copyright HCE 2010 - www.hobie-cat.net... -
Page 4: The Manufacturing Of Hobie Cats Conforms To The Following Iso Norms
Module Abis Category Hull construction Carbone The manufacturing of Hobie Cats conforms to the following ISO norms : Hull construction and scantlings ISO 12215-1:2000 Stability and buoyancy assessment and categorization ISO 12217:2000 Hull identification -- Coding system ISO 10087:1995 FR-HCE Y0164B010 Builder’s plate... -
Page 5: Owner's Manual
(men at sea, towing, etc.) ; Sailing schools and clubs regularly organise training sessions to learn how to use the safety equipment and how to behave in case of emergency. Copyright HCE 2010 - www.hobie-cat.net... -
Page 6: Complementary Information
OWNER’S MANUAL Complementary information INTERNATIONAL HOBIE CLASS ASSOCIATION (I.H.C.A.) Hobie Cat owners are organised in a world-wide class association : the IHCA (Interna- tional Hobie Class Association). For Europe, you can contact theEHCA (European Hobie Class Association). Visit their web site : http://ehca.hobieclass.com to find the name and contact details of the association of you country. - Page 7 In order to avoid hull damages : - Always use a dolley to transport your Hobie on the beach (even if it is sand beach) and for launching. Step into the water with the dolley and once the cata is afloat take out the dolley.
-
Page 8: Handling And Maintenance
Climb abord and continue sailing. Maintenance of your Hobie This manual is not an exhaustive guide for the mainteance or repair of your Hobie. In case of difficulties, take contact with the builder or his representative. - Page 9 How to obtain warranty performance within 0 days of discovering the defect: Bring your boat to the nearest authorised Hobie Cat Europe dealer (a list of the dealers is available at HCE). Be sure to take proof of date of retail pur- chase (invoice).
-
Page 10: Your Distributor
Please carefully read the warranty conditions written in this manual. Please carefully and thoughroughly read this manual. Keep it in a safe place Give it to the new owner if you resell your Hobie. Copyright HCE 2010 - www.hobie-cat.net... -
Page 11: Assembly Manual
Issued by : AR Date : 05/2010 Up-date : 0 Page : 11/52 HOBIE ICAT ASSEMBLY MANUAL Necessary tools N° Illustration Description Lubricant Universal pliers Poignée d’étarquage Mètre ruban wrench #14 adhesive tape screw driver Copyright HCE 2010 - www.hobie-cat.net... -
Page 12: List Of The Parts
Date : 05/2010 Up-date : 0 Page : 12/ HOBIE ICAT ASSEMBLY MANUAL List of the parts Your iCat is delivered in 5 parcels (6 parcels if you have the Gennaker option) See detail below : Illustration N° Description Reference Front crossbar... -
Page 13: List Of The Parts
WASHER Z M10 99220285 WASHER 20X10.2X2 NYLON 99220290 STAY ADJUSTER 9922060 SCREW TH-B14 SPE 10X125X50 99226201 STOP BALL 9950010 THREEFOLD WINCH BLOCK +CARBO 9950016 DOUBLE BLOCK 99500470 SINGLE BLOCK MICRO 99500478 FOURFOLD BLOCK CARBO 99501005 Copyright HCE 2010 - www.hobie-cat.net... - Page 14 Lay the hulls parallel to each other. Position the back crossbar so that the pad-eyes are towards the front and the lacing buttons towards the back. Tighten the screws. Copyright HCE 2010 - www.hobie-cat.net Copyright HCE 2010 - www.hobie-cat.net .../...
- Page 15 Hull and crossbar assembly Illustration Steps Description Feed the front crossbar into the band at the front of the trampoline. Place the crossbar on the hulls. Fix the front crossbar in the same way as the back crossbar. Copyright HCE 2010 - www.hobie-cat.net...
-
Page 16: Trampolin Assembly
To attach the trampoline on the rear crossbar, be- gin on the left side. Pull the line, lead it through the pad-eye, go back through the buckle. Then, back through the pad-eye and back through the buckle. Copyright HCE 2010 - www.hobie-cat.net Copyright HCE 2010 - www.hobie-cat.net .../... - Page 17 Then, lead the line through the eyelet. then back through the pad-eye, and once again through the eyelet. Stop the line with a eight figure knot on the pad- eye. Copyright HCE 2010 - www.hobie-cat.net Copyright HCE 2010 - www.hobie-cat.net .../...
- Page 18 Correct lacing Finish with a half hitch knot. Finished assembly. Copyright HCE 2010 - www.hobie-cat.net...
-
Page 19: Preparation Of The Mast
Insert the end of the fixed part of the spreader bar in the back mast fitting and insert the screw. Put the bolt on and tighten with the spanner Copyright HCE 2010 - www.hobie-cat.net Copyright HCE 2010 - www.hobie-cat.net .../... - Page 20 Preparation of the mast : Spreader bars Illustration Steps Description Guide the adjustable piece towards the front mast fitting. Fix it in place using the axe and the split ring. Finished assembly. Repeat the steps 5-8 on the other side. Copyright HCE 2010 - www.hobie-cat.net...
- Page 21 G :Trapeze lines Take the 8 mm shackle from the bag and pass the forestay [A] into it. Then pass the shrouds [B] on each side of the forestay. Copyright HCE 2010 - www.hobie-cat.net Copyright HCE 2010 - www.hobie-cat.net .../...
- Page 22 Finish with the trapeze wires [C] as shown in the photo. Fix the shackle with the wires onto the mast tang at the top of the mast. Finished Assembly. Be careful to firmly tighten the shackle axe with the pliers. Copyright HCE 2010 - www.hobie-cat.net...
- Page 23 Feed the other end into the hole as shown on the photograph. Lead the rope under the mast and feed it through the second hole above the other. Tie a knot at the end. Copyright HCE 2010 - www.hobie-cat.net Copyright HCE 2010 - www.hobie-cat.net .../...
- Page 24 Pass the gennaker halyard through the pulley, Fix it to the swivel that is supplied with the furler. Join the two ends together and leave for the time being. Copyright HCE 2010 - www.hobie-cat.net Copyright HCE 2010 - www.hobie-cat.net...
- Page 25 [B] to the right hand side fixation of the mast. Insert the ends of the two cables into the borings at the bottom of the mast. Copyright HCE 2010 - www.hobie-cat.net Copyright HCE 2010 - www.hobie-cat.net .../...
- Page 26 Be careful to bring the wire [A] to the left side and the wire [B] to the right side. Put the mast foot into the mast base, without tightening the cables for the moment. Copyright HCE 2010 - www.hobie-cat.net Copyright HCE 2010 - www.hobie-cat.net .../...
- Page 27 Once that the assembly in finished cover all with adhesive tape. Copyright HCE 2010 - www.hobie-cat.net...
- Page 28 Steps Description Take the bridles from the wire bag Fix them into the bridle fittings at the front of the hulls using the axe and split ring as shown in the photo opposite. Finished assembly Copyright HCE 2010 - www.hobie-cat.net...
-
Page 29: Stepping The Mast
Take the two stay adjusters from the wire and rope bag and fix to the eye-bolts using the clevis pins and split rings. Then, join each shroud to the top of each stay adjuster using the clevis pins and split rings. Copyright HCE 2010 - www.hobie-cat.net... - Page 30 The person at the back advances along the mast while raising it. As the mast rises, the person in front moves back little by little, pulling on the trapeze to help raise the mast. Copyright HCE 2010 - www.hobie-cat.net Copyright HCE 2010 - www.hobie-cat.net .../...
- Page 31 Copyright HCE 2010 - www.hobie-cat.net...
-
Page 32: Mast Rotation
Continue underneath and to pass it into the pulley on the right-hand side installed at stage 2. Come back towards the hull. Copyright HCE 2010 - www.hobie-cat.net Copyright HCE 2010 - www.hobie-cat.net .../... - Page 33 Page : / HOBIE ICAT ASSEMBLY MANUAL Mast Rotation Illustration Steps Description Bring it out at the side of the trampoline and fix it in the cleat. Repeat the same operation for the left hand side. Copyright HCE 2010 - www.hobie-cat.net...
- Page 34 Take the central gooseneck hinge out of the rigging bag. Install it around the mast fitting. Slide the end of the boom into the hinge. Fix in place using the clevis pin and split ring. Copyright HCE 2010 - www.hobie-cat.net...
- Page 35 Pass the two ends of the laces into the hole in the batten. Pass through the eyelet on the sail from the top. Tie a reef knot over the laces. Tighten and slip the two ends into the batten sleeve. Copyright HCE 2010 - www.hobie-cat.net...
-
Page 36: Hoisting The Mainsail
Go passed the hook and let it slide back, it will hook automatically. To lower the mainsail, pull on the halyard, turn the mast to the side to unhook and pull on the sail to lower it. Copyright HCE 2010 - www.hobie-cat.net... - Page 37 Hang the large shackle with the two double pulleys to the tack point of the mainsail. Lace the end of the Cunningham rope between the double pulleys, the cleats and single pulleys on the mast foot according to the diagram opposite. Copyright HCE 2010 - www.hobie-cat.net...
-
Page 38: Mainsheet System
As seen from the other side. Take the mainsheet system (already mounted) from the rigging bag and attach the snap hook to the strap of the mainsail, under the boom. Copyright HCE 2010 - www.hobie-cat.net Copyright HCE 2010 - www.hobie-cat.net .../... - Page 39 Pass the main sail sheet in to the cleat on the traveller. Separate the two parts and pass them into the cleats behind the rear crossbar, as in the photo opposite. Mainsheet system mounted on the boat. Copyright HCE 2010 - www.hobie-cat.net...
-
Page 40: Rudder Assembly
(as shown on the photograph opposite) Insert the gudgeon through the top of the rudder arm and the upper pintle, then the bottom of the rudder arm and through the lower pintle. Copyright HCE 2010 - www.hobie-cat.net Copyright HCE 2010 - www.hobie-cat.net .../... - Page 41 To lower the rudder, pull the fixing arm up to allow the rudder to rotate towards the low position, and engage the round plastic part into its cavity on the rudder arm in order to block the rudder. Fix the elastic over the fixing arm. Copyright HCE 2010 - www.hobie-cat.net...
-
Page 42: Tiller Crossbar
Insert the end of the tiller crossbar onto the axe at the end of the rudder arm. Insert the security washer as shown on the photo. Fix the tiller extension in the middle of the tiller crossbar as shown in the photo. Copyright HCE 2010 - www.hobie-cat.net... -
Page 43: Mast
Take the Gennaker central tension rope and install between the pad eye and the bridle fixing point on the stay adjuster. Then fix the two pole bridles on the bridle supports on the hulls. Copyright HCE 2010 - www.hobie-cat.net Copyright HCE 2010 - www.hobie-cat.net .../... - Page 44 Then through the loop. Tension. Stop with a knot. Do the same thing on the opposite side. Copyright HCE 2010 - www.hobie-cat.net Copyright HCE 2010 - www.hobie-cat.net .../...
- Page 45 Mount the Gennaker sheet pulleys onto the shroud fixations as shown on the photo opposite. To do that, unclip the strap lead it around the stay adjuster and clip it. Proceed in the same way for the other side. Copyright HCE 2010 - www.hobie-cat.net...
- Page 46 Lead the rope inside the furler. Turn the furler until the rope has gone all the way around. It should come out the other side. Pass the rope behind the metal crochet. Finished assembly. Copyright HCE 2010 - www.hobie-cat.net Copyright HCE 2010 - www.hobie-cat.net .../...
- Page 47 To fix the furler to the pole, open the snap hook. Pass it into the pad-eye situated at the attach point of the pole bridles. Close the snap hook. Copyright HCE 2010 - www.hobie-cat.net Copyright HCE 2010 - www.hobie-cat.net .../...
- Page 48 Hoist the gennaker by pulling on the gennaker ha- lyard and once the gennaker is completely hoisted, stop it in the clam cleat on the mast. Copyright HCE 2010 - www.hobie-cat.net...
-
Page 49: Left Hull
Then pass through the winch pulley on the left hull. Pass to the right side into the other winch pulley and come back to fix onto the Gennaker clew point. Copyright HCE 2010 - www.hobie-cat.net... - Page 50 Up-date : 0 Page : 50/ HOBIE ICAT ASSEMBLY MANUAL Gennaker kit : Furler line (option) Illustration Steps Description Passage of the furler line on the front crossbar. Fixation on the rear of the trampoline. Copyright HCE 2010 - www.hobie-cat.net...
- Page 51 Ref : MM_ICAT Issued by : AR Date : 05/2010 Up-date : 0 Page : 51/ HOBIE ICAT ASSEMBLY MANUAL Gennaker kit : Overall view (option) Copyright HCE 2010 - www.hobie-cat.net...
- Page 52 HOBIE ICAT OWNER’S MANUAL HOBIE CAT EUROPE ZI Toulon Est, BP 250, 8078 Toulon cedex 9, France Tel + (0)494 08 78 78 - Fax + (0)494 08 1 99 E-mail : info@hobie-cat.net - site web www.hobie-cat.net Copyright HCE 2010...
