Table Of Contents; List Of The Parts - Hobie MAX RACE Assembly Manual

Necessary tools
⇒
2 spanners nr 17
⇒
1 pair of niversal pliers
TABLE OF CONTENT
List of the parts.............................. 2
Hull assembly................................ 5
Trampoline .................................6-7
Rudders, tiller and tiller extension . 8
Preparation of the mast................. 9
Spreader ..................................... 10
Mast assembly ............................ 11
Stepping the mast ....................... 12
Trapezes ..................................... 13
Boom........................................... 14
Mainsail ....................................... 15
Cunningham................................ 16
Jib................................................ 17
Jib self tacking system ............... 18
Jib car control.............................. 19
Mainsheet...............................20-21
Spinnaker kit ............................... 22
It is advisable to be at least two people to
⇒
2 hulls
⇒
1 front crossbar with self-tacking jib
tracak
⇒
1 rear crossbar (trampoline lacing
posts)
⇒
1 Mast
⇒
1 Boom
⇒
1 one-piece trampoline with vectra
line + fibreglas rod
⇒
1 part bag (wires)
⇒
1 rigging bag
⇒
1 ropes bag
⇒
2 Rudder assemblies
⇒
1 Tiller crossbar
⇒
1 Tiller extension
⇒
1 mainsail + battens (7)
⇒
1 jib
⇒
1 trumpet spi kit (composed of one
asymmetrical spinnaker, one
polyester trumpet, one spi bag, one
rigging kit + ropes)
CAUTION - DANGER
ALUMINIUM MAST - STAY AWAY
OF ELECTRICAL WIRES

List of the parts

assemble the Hobie Max
LIST OF THE PARTS
2
