Summary of Contents for Cannondale SUPERMAX
- Page 1 129975 SUPERMAX. OWNER’S MANUAL SUPPLEMENT.
- Page 2 In this supplement, particularly important information is presented in the following ways: Indicates a hazardous situation which, if not WARNING avoided, could result in death or serious injury. Indicates special precautions that must be NOTICE taken to avoid damage. A TIP provides helpful information. This manual meets EN standards 14764, 14766, and 14781.
-
Page 3: Table Of Contents
If you need a manual or supplement, or have a teCHnICaL InFOrMatIOn ......4 question about your bike, please contact your SUPERMAX Structure ......4 Cannondale Dealer immediately, or call us at one Wheel Hub ........5 of the telephone numbers listed on the back cover of this manual. -
Page 4: Safety Information
Please read Inspect For Safety in PART II, Section D. of your Cannondale Bicycle Owner’s Manual. If your SUPERMAX is damaged, do not ride it. Contact your Cannondale Dealer to arrange service through an authorized service center. yOU Can Be SeVereLy InJUred, ParaLyZed Or KILLed In an aCCIdent IF yOU IGnOre tHIS WarnInG. -
Page 5: Disassembly / Modification
(1) and the bottom of the fork an Authorized Headshok Service Center. steerer (2). Contact your Authorized Cannondale yOU Can Be SeVereLy InJUred, ParaLyZed Dealer for more information. Or KILLed In an aCCIdent IF yOU IGnOre yOU Can Be SeVereLy InJUred, tHIS WarnInG. -
Page 6: Technical Information
TECHNICAL INFORMATION Supermax Structure Identification PBR Lockout Button PBR Rebound Dial XLR Rebound Dial Loctite 242 (blue) 7-9 Nm (62-80 InLbs) XLR/PBR Carbon Outer Collar Bonded Upper Clamp Clamp Bolt Serial Number Location Frame Bumper Carbon Outer Tube (carbon fiber) -
Page 7: Wheel Hub
129975.PDF Wheel Hub ■ Either a SUPERMAX or LEFTY HYBRID wheel hub may be used with the SUPERMAX. The wheel hub must be matched with its correct brake adapter. See item 23 on previous page. ■ The hub cap is a left-hand thread. It retains the axle bolt assembly within the and should only be removed when replacing the bearings or axle bolts parts, not when removing the wheel. -
Page 8: Setting Sag
Sag is the distance the SUPERMAX compresses when the bike is statically loaded with your body weight in your riding position. Set it according to the SUPERMAX travel. Sag is set by changing the air pressure through the Schrader valve at the bottom of the SUPERMAX... - Page 9 129975.PDF to set sag: 1. Remove the Schrader valve cap (1) at the bottom of the SUPERMAX Attach a bicycle suspension pump to the Schrader valve (2). See Figure 1. 2. Set the recommended intial starting air pressure according to your weight.
-
Page 10: Pbr Lockout
PBr Lockout OPen POSItIOn LOCKed POSItIOn In the open position, LEFTY travel is active. In the locked position, LEFTY travel is The red rebound dial (1) is in the down locked. The red rebound dial is up. To go position. To go to the locked position, press back to the open position, press the red the blue button (2). -
Page 11: Wheel Removal
129975.PDF Wheel removal 1. If needed, loosen the brake line clamp on the front of the moto guard so the line can move freely. This will make handling the brake caliper and attached adapter easier. 2. See Figure 1. Use a 5 mm Allen key to loosen and back out both brake adapter mounting bolts enough so that the adapter and attached caliper can slide up and be... -
Page 12: Wheel Installation
Follow brake manufacturer’s instructions when mounting the brake caliper to the spindle brake bosses. Do not modify the fork in any way. PLEASE ASK YOUR CANNONDALE DEALER FOR HELP WHEN INSTALLING COMPATIBLE FRONT BRAKE SYSTEMS. -
Page 13: Maintenance
200 hours Headshok Service Center service) raCInG - If you race with your SUPERMAX, you will have to perform the items listed twice as often. (i.e. 50hrs becomes 25hrs) SCHEDULE PROFESSIONAL FORK SERVICE ANNUALLY (Minimum) Annually, or when problems are indicated you must have your SUPERMAX serviced through a Cannondale Dealer or an Authorized Headshok Service Center. -
Page 14: Cleaning
Cleaning Clean using only a mild soap and water solution. Clean water and common liquid dish washing soap will work best. Be sure to cover the adjusters with a clean plastic bag secured with a rubber band or masking tape. Spray off heavy dirt before wiping. Spray indirectly. NOTICE •... -
Page 15: Frame Bumper
129975.PDF Frame Bumper The bumper cushions the frame from contact with the SUPERMAX. Replace it with a new one if it ever becomes damaged, torn, or missing. rePLaCeMent: Clean surfaces well. Remove the backing from the new bumper, position and affix by pressing firmly against the outer tube. -
Page 16: Manual Reset
Contamination can result in reduced or lost braking performance. 3. Hold the valve open while fully compressing the SUPERMAX with the the handlebar until it bottoms out. With the air out, using moderate 35 +/- 3mm force, bottom out the SUPERMAX firmly several times. -
Page 17: Cannondale Limited Warranty
CANNONDALE LIMITED WARRANTY Cannondale Headshok (SUPERMAX, LEFTY, Fatty, Solo) suspension products are covered under the terms and conditions of the Cannondale Limited Warranty. It is available on the Policies page of our website at: www.cannondale.com Be sure to read the exclusions listed in the limited warranty. For example, damage from accidents and improper maintenance are not covered. -
Page 18: Replacement Parts
REPLACEMENT PARTS The following replacement part kits are available through a Cannondale Dealer: HD215/ KH074/ KH065/ Knobs Only LEFTYBOLTS Damping Cartridge KH113/ Solo Air Assembly (color=purple) is sold separately Solo Air Assembly Kit KH115/ #112 LEFTYBOLTS #112 #119 HD011/ Upper... - Page 19 WARNING! READ THIS SUPPLEMENT AND YOUR CANNONDALE BICYCLE OWNER’S MANUAL. BOTH CONTAIN IMPORTANT SAFETY INFORMATION. KEEP BOTH FOR FUTURE REFERENCE. CANNONDALE USA CANNONDALE EUROPE CANNONDALE UK Cycling Sports Group, Inc. Cycling Sports Group Europe, B.V. Cycling Sports Group 172 Friendship Road,...
