SuperSix EVO Neo
Owner's Manual Supplement
READ THIS SUPPLEMENT AND YOUR
CANNONDALE BICYCLE OWNER'S MANUAL.
Both contain important safety information. Keep
both for future reference.
English

Advertisement

loading
Need help?

Need help?

Do you have a question about the SuperSix EVO Neo and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Cannondale SuperSix EVO Neo

Summary of Contents for Cannondale SuperSix EVO Neo

  • Page 1 English SuperSix EVO Neo Owner’s Manual Supplement READ THIS SUPPLEMENT AND YOUR CANNONDALE BICYCLE OWNER’S MANUAL. Both contain important safety information. Keep both for future reference.
  • Page 2 Safety Messages In this supplement, particularly important information is presented in the following ways: Indicates a hazardous situation which, if not avoided, may result in death or serious injury. NOTICE Indicates special precautions that must be taken to avoid damage. The following symbols are used in this manual: Symbol Name...

  • Page 3: Table Of Contents

    Contacting Cannondale Cannondale USA Cycling Sports Group, Inc. 1 Cannondale Way, Wilton CT, 06897, USA 1-800-726-BIKE (2453) Cycling Sports Group Europe B.V Mail: Postbus 5100 Visits: Hanzepoort 27 7570 GC, OLDENZAAL, Netherlands service@cyclingsportsgroup.com...

  • Page 4: Identification

    SuperSix EVO Neo - Owner’s Manual Supplement IDENTIFICATION Parts of Your Ebike Actual bike appearance will differ. Identification 1. X35 Rear Hub Drive Unit ** 4. Bottom Bracket Cover 9. Rear Cassette 2. iWoc® ONE 5. Charger/Battery Port 10. Bike Serial Number Location (drive interface) 6.

  • Page 5: Safety Information

    At anytime, if you To minimize risk we strongly recommend stop pedaling, the drive-assist will dis- that owners always have mechanical engage. work done by an Authorized Cannondale Dealer. 137377 Rev 1.
  • Page 6 No Child Seats or Trailers Child seats and trailers or racks can not be used and are not allowed to be used with your Cannondale E-Bike. 137377 Rev 1.
  • Page 7 Follow any state or local laws for any minimum age restrictions for E-Bikes. WHEN NOT RIDING - TURN THE DRIVE SYSTEM OFF TO PREVENT UNAUTHORIZED Ask your local Authorized Cannondale Dealer USE. for more information about operating an electrically assisted pedal bicycle in your area.
  • Page 8 SuperSix EVO Neo - Owner’s Manual Supplement (Operation continued..) (Operation continued..) ACCIDENTAL ACTIVATION - Always YOUR INSURANCE POLICIES - Your disconnect battery from the bike before insurance policies (e.g. liability, property working on the bicycle. If you transport and injury) may not provide coverage for the bike by car or plane follow/obey local accidents involving the use of this bicycle.
  • Page 9 Batterys & Chargers CHARGING - Bring indoors and allow to reach room temperature before charging. Make sure charger and DANGER A/C outlet are the same voltage. Locate both charger and battery indoors, in a clean, The battery pack voltage must match the battery dry area with good ventilation to charge.
  • Page 10 SuperSix EVO Neo - Owner’s Manual Supplement Mounting an External Battery Commuting EQUIPMENT - Any bicycle Including Do not attach any external battery to the an drive-assisted bike (ebike) must down tube water bottle location. be properly equipped for commuting...
  • Page 11 If you notice damage to the threaded insert, please ask your Cannondale You can be severely injured, paralyzed Dealer for help. or killed in an accident if you ignore this message.

  • Page 12: Technical Information

    (e.g. the specified sizing of the attached gear ratios (front/rear chain rings) ). Attempts to “hot-rod” or “improve” the speed of the bike are dangerous to the rider. Use only specified Cannondale and/or manufacturer drive-assist service and replacement parts. 137377 Rev 1.
  • Page 13 Drive System Specifications Platform / Region Supersix EVO NEO / EU Specification Model Code C66150M C66250M C66350M C66150M C66250M C66350M SuperSix SuperSix SuperSix SuperSix SuperSix SuperSix Model Name EVO Neo EVO Neo EVO Neo EVO Neo Neo 1 Neo 1...
  • Page 14 SuperSix EVO Neo - Owner’s Manual Supplement Geometry 75 mm Dimensions = centimeter/inches Item Size Seat Tube Length 47.7/18.8 51.5/20.3 53.6/21.1 Top Tube Horizontal 53.4/21.0 54.6/21.5 55.7/21.9 Head Tube Angle 71.2° 73.0° Seat Tube Angle Effective 73.7° Standover 75.8/29.8 78.8/31.0 80.8/31.8...
  • Page 15 To avoid serious damage to the frame, follow the manufacturer’s instruction for assembly and installation of the bearing system. Use the specified bottom bracket tools when servicing. Consult with your Cannondale Dealer on the quality and compatibilty of any proposed replacement component. Do not use chemical solvents to clean. Do not remove frame material or use surfacing tools on bottom bracket shell.
  • Page 16 Please Note: Do not attempt to work on the cable routing yourself. Due to the complex nature of the parts and the level of disassembly required to gain access, have any repairs or replacements of the battery, cables or hoses parts identified performed by an authorized Cannondale e-bike service center.
  • Page 17 Internal Battery • To prevent damage to the battery it is very important to observe the specified maximum tightening torques of the clamp and mounting bolts. 2 N·m Max. The three clamps are positioned on the battery for alignment with the frame holes before installation, and the clamp spacing vary between differing frame sizes.
  • Page 18 SuperSix EVO Neo - Owner’s Manual Supplement Rear Wheel The drive unit manufacture’s instructions To install: contain important details about handling parts of the drive system. Read those Turn OFF the drive system. See instructions now. manufacturers‘ instructions. 2. Secure the bicycle in a bicycle work stand with the rear wheel off the ground.
  • Page 19 M4 x 12 mm 1 N·m M4 x 8 mm 1 N·m NOTICE Ensure that the chainstay cable cover (1) is capturing the power cable at the dropout end and is not oriented towards brake rotor. Do not ride the bike without the chainstay cable guard.
  • Page 20 SuperSix EVO Neo - Owner’s Manual Supplement Removing the internal battery Front Derailleur Mount The internal battery must only be service by a professional bike mechanic. Disassemble the headset cap so that the fork may be lowered slightly within the headtube. This is required to enable adequate cable slack.
  • Page 21 If you Head Tube Stop 3. Steering Angle find damage have the frame inspected by your Cannondale Dealer . If the dropout is un-damaged, apply a light film NOTICE of grease between the frame and mount. This will help minimize any noise or “creaking”...
  • Page 22 SuperSix EVO Neo - Owner’s Manual Supplement Seat Post Installation & Adjustment Minimum Insert The minimum insert depth the seat post must be Before installing: inserted into the frame is 65mm. • Use a clean shop towel to wipe out any...
  • Page 23 Apply heavy grease between sliding wedge and frame interface Identification to prevent creaking. Saddle Clamp Seat Post Sliding Clamp Seal Di2 Battery Battery Bracket Di2 Cable 6 N·m 65mm Apply carbon paste to 6 N·m entire length of the inserted seat post Minimum Insert Maximum Insert Maximum Depth...
  • Page 24 Service Instruction for the parts kit. These instructions are not provided in this manual. We reccommend that you have a Cannondale Dealer perform the replacement. Please Note: During first assembly of the nut base, it is important to not push on the 4mm allen when tightening onto the seatpost.
  • Page 25 (shown disassembled) Correct application of carbon paste and grease. The pressure sensitive adhesive double-sided tape secures the aligned nut base in the frame. When applied the nut base and frame should be very clean for a good bond. Ready to accept seat post. This is CORRECT.
  • Page 26 SuperSix EVO Neo - Owner’s Manual Supplement KNØT Stem Spacers Spacers can be flexed open to allow spacer assembly / disassembly without disconnecting cables. Bend spacer inwards to route cables through first slot, then route cables through the second slot.
  • Page 27 English Hinge covers together and slide them over the stem body. Stem body and covers have interlocking features. Close right stem cover first, then rotate left stem cover in place and close around the stem body Assemble the stem covers with the M3 bolt (1Nm) 137377 Rev 1.
  • Page 28 SuperSix EVO Neo - Owner’s Manual Supplement KNØT / SAVE SystemBar STEM REACH LENGTH DROP 5 N·m 5 N·m 1 N·m 2 N·m (1X) 5 N·m (4X) 7.5mm (2X) 12.5mm 5 N·m KNØT & SAVE Shared Parts Description Part Number...
  • Page 29 Handlebar Width Description Part Number (cm) CP2650U1038 CP2650U1040 KNØT CP2650U1042 CP2650U1044 CP2600U1036 CP2600U1038 SAVE CP2600U1040 CP2600U1042 CP2600U1044 Stems Stem Length Stem Rise Description Part Number (degrees) (mm) CP2300U1080 CP2300U1090 - 17 CP2300U1010 CP2300U1011 CP2300U1012 KNØT Stems CP2250U1080 CP2250U1090 CP2250U1010 CP2250U1011 CP2250U1012 K2804080 K2804090...
  • Page 30 The maximum spacer stack height is 55mm. The example above depict 2x 12.5mm spacers and 4x 7.5mm spacers, resulting in 55mm. • The KNØT stem is to be used only with a Cannondale SystemBar handlebar such as SAVE or KNØT SystemBar. Use only the Cannondale SI Compression plug K35009.

  • Page 31: Replacement Parts

    REPLACEMENT PARTS 6 N·m 4-6 N·m 2 N·m 1 N·m 2 N·m eTap water bottle bolts 10 mm (max. length) 2 N·m 1 N·m 40-50 N·m QTY 3 Part Number Description Part Number Description K26030 S6 EVO Internal Seat Binder K32160 S6 EVO/CAAD13 DT Cable Guide K33009...

  • Page 32: Ebike Pre-Ride Checklist

    SuperSix EVO Neo - Owner’s Manual Supplement EBIKE PRE-RIDE CHECKLIST Before and After Each Ride: • Clean and visually inspect the entire bike for cracks or damage. See “Inspect for Safety” in your Cannondale Bicycle Owner’s Manual.” • Make sure the battery is fully charged and mounted securely. Follow the drive system charging instructions.

  • Page 33: Ebike Maintenance

    Unauthorized opening or service of the drive unit will void the warranty. 3. Every 1000 km, bring your bike in to your Authorized Cannondale Dealer for a regular detailed inspection, adjustment, and replacement of wear items across the entire bike. Electrically powered-as-...

  • Page 34: Cleaning

    SuperSix EVO Neo - Owner’s Manual Supplement Cleaning When cleaning your bike, use a damp sponge or a soft brush with only a mild soap and water solution. Rinse the sponge often. Do not spray water directly on controls or drive system components.
  • Page 36 WWW.CANNONDALE.COM © 2019 Cycling Sports Group SuperSix EVO Neo Owner’s Manual Supplement 137377 Rev. 1 CANNONDALE USA CANNONDALE EUROPE CANNONDALE UK Cycling Sports Group, Inc. Mail: Postbus 5100 Cycling Sports Group Visits: Hanzepoort 27 1 Cannondale Way, Vantage Way, The Fulcrum,...
