  • Page 1 SuperSlice Owner’s manual supplement READ THIS SUPPLEMENT AND YOUR CANNONDALE BICYCLE OWNER’S MANUAL. Both contain important safety information. Keep both for future reference.

  • Page 2: Safety Information

    Notes ............20 NOTICE Indicates special precautions that must be taken to avoid damage. Cannondale Supplements This manual is a “supplement” to your Cannondale Your Authorized Bicycle Owner’s Manual. Cannondale Dealer This supplement provides additional and important model specific safety, maintenance, and technical To make sure your bike is serviced and maintained information.

  • Page 3: Intended Use

    “carbon fiber. ” Inspect frame carefully for damage (See PART II, All riders must understand a fundamental reality Section D. Inspect For Safety in your Cannondale of composites. Composite materials constructed Bicycle Owner’s Manual. )

  • Page 4: Tightening Torques

    ENGLISH Disc Brake on Road Bikes Tightening Torques Correct tightening torque for the fasteners (bolts, screws, nuts) on your bicycle is very important to your safety. Correct tightening torque for the fasteners is also important for the durability and performance of Relative to conventional rim brakes, disc brakes are your bicycle.

  • Page 5: Aerodynamic Handlebars

    Shifting weight back allows more rear braking effect before the rear wheel begins to skid when braking hard, or braking on a steep downhill. AERODYNAMIC See Part 1, Section 4C. of your Cannondale Bicycle extensions Owner’s Manual. Aerodynamic handlebars and extensions are...
  • Page 6 If you This kind of damage is not covered by the Cannondale choose more lightweight components, you must inspect Limited Warranty.
  • Page 7 SUPERSLICE - OWNERS MANUAL SUPPLEMENT TECHNICAL INFORMATION Frame Specification Item Specification Head Tube UPR: 1 1/8 In., LWR: 1 1/8 In. Bottom Bracket: Type/ Width PF30A / 73mm Front Derailleur Braze-On Seat Post: Dia./Binder Superslice Seatpost / Integrated 100mm Min. Seat Post Insert 700X25c Tire Size/ Max.
  • Page 8 ENGLISH Geometry Seat Tube Length Top Tube Horizontal Head Tube Angle Seat Tube Angle Standover Head Tube Length Wheelbase Front Center Chain Stay Length Bottom Bracket Drop 75mm Bottom Bracket Height Fork Rake Trail Stack Reach Pad Stack lowest Pad Stack highest Pad Reach shortest Pad Reach longest Dimensions = (centimeter)

  • Page 9: Serial Number

    The serial number located on the bottom bracket. It is a 7-character barcode (1). Use this serial number to registration your bike. See your Cannondale Bicycle Owner’s Manual for more information on warranty registration.
  • Page 10 NOTICE and quiet. Execesssive play, roughness or corrossion indicates a damaged bearing. Consult with your Cannondale Dealer on the quality and Removal compatibilty of any proposed replacement component. Make sure the PRESSFIT BB30 system is intended for use To avoid serious damage to the frame, it is important to with with a 46 mm I.D.
  • Page 11 Periodically, remove the seat post and the clamp A seat post should not be bottomed out inside the assembly to clean, inspect for damage and re-new the frame at any time. Have your Cannondale Dealer size application of grease and carbon gel. the seat post appropriately.
  • Page 12 Minimum Insert Suggested Tools: Park Tool SG-7.2 Park Tool CSB-1 Maximum Insert Maximum Depth For more information about carbon fiber seat posts, see also “Care and Maintenance of Carbon Fiber Seat Posts” in your Cannondale Bicycle Owner’s Manual. 134920 Rev 1.

  • Page 13: Exploded View

    SUPERSLICE - OWNERS MANUAL SUPPLEMENT Handlebar/Stem Exploded View 6 N-m Shroud Grommet Plug 6 N-m Screw Stem Top Cover Screw Fork Top Cap Top Cap Bolt Stem 10. Handle Bar 11. Stem Top Plate 12. Stem Washer 13. Stem Clamp Bolts Assembled View 134920 Rev 1.
  • Page 14 ENGLISH Pad Stack 15mm 9 N-m Arm Pad Spacers/Bolt Length Number of Pad Stack Change - STK Correct Bolt Length - BLT Bridge (1) 15mm Spacers (2) 0 mm 35mm 15mm 50mm 30mm 65mm 45mm 80mm 60mm 95mm 75mm 110mm 90mm 125mm Use the correct bolt lengths.
  • Page 15 SUPERSLICE - OWNERS MANUAL SUPPLEMENT Pad X Extension + Pad = 26.5mm Bridge = 3mm Spacer = 15mm Pad Y Handlebar = 11mm Stem = 26.2mm Instructions: Frame Size (cm) 1. Find your “Pad Y” in one or more places in this table.
  • Page 16 ENGLISH Chart : Pad X, Pad Y Note: This is the same data as Pad X and Pad Y tables (previous page). Here, the information is arranged semi-graphically to show overlapping Pad Y values possible with different frame sizes & component combinations. Instructions: 1.
  • Page 17 SUPERSLICE - OWNERS MANUAL SUPPLEMENT Internal Routing FB - Front Brake Hose RB - Rear Brake Hose This illustration is a simplified view of the internal handlebar system routing. wire connector DO NOT modify, cut, drill, or enlarge existing openings in the...
  • Page 18 ENGLISH Shimano Di2 - Battery Shimano SM-EW90A Secured to saddle rail. Control wires exiting the seat post interior Battery Battery Mount Mounting Screw Cable Ties Ensure adequate control Control Wire wire slack to avoid accidental Control Junction 3-port disconnections during seat post adjustment.
  • Page 19 SUPERSLICE - OWNERS MANUAL SUPPLEMENT Replacement Parts - Frame/Fork 4 N·m 4 N·m 122mm M12x1 2 N·m 167mm M12x1 2 N·m 2 N·m Part Number Description Part Number Description CK0037U00OS Superslice Seatpost CK3097U00OS Di2 Bracket (battery) CK0077U00OS Superslice Seatpost Binder...
  • Page 20 6 N·m 15mm 6 N·m 9 N·m Part Number Description KP476/ Kit, Preload Cap, Super Slice CK0097U0020 Superslice Stem 120mm CK0097U0060 Superslice Stem 60mm CK0097U0090 Superslice Stem 90mm CK0107U00OS Superslice Stack Spacers CK0117U00OS Superslice Base Bars - 380mm 134920 Rev 1.
  • Page 21 SUPERSLICE - OWNERS MANUAL SUPPLEMENT Tire-to-Frame Clearance THE MINIMUM TIRE-TO-FRAME CLEARANCE MUST BE MAINTAINED. If tire clearance is less than minimum specified, the rotating tire could come into contact with the frame causing the wheel to stop suddenly. This can throw a rider off the bicycle or result in a loss of control and crash.
  • Page 22 WWW.CANNONDALE.COM © 2018 Cycling Sports Group SuperSlice Owner’s Manual Supplement 134920 Rev. 1 CANNONDALE USA CANNONDALE EUROPE CANNONDALE UK Cycling Sports Group, Inc. Cycling Sports Group Europe, B.V. Cycling Sports Group 1 Cannondale Way, Hanzepoort 27, 7570 GC, Oldenzaal, Vantage Way, The Fulcrum,...
