INSTALLATION AND OPERATING INSTRUCTIONS
THERMIC DISTRIBUTION EUROPE
5 VOIE AXIALE
5660 COUVIN, BELGIUM
WARNING
If the information in this manual is not followed exactly, a fire or explosion
may result causing property damage, personal injury or loss of life.
Do not store or use gasoline or other flammable vapors and liquids in the vicinity
of this or any other appliance.
WHAT TO DO IF YOU SMELL GAS:
- Open windows
- Do not try to light any appliance.
- Do not touch any electrical switch; do not use any phone in your building.
- Immediately call your gas supplier from a neighbor's phone. Follow the gas
supplier's instructions.
- If you cannot reach your gas supplier, call the fire department.
Installation and service must be performed by a qualified installer, service agency
or the gas supplier.
R25- O25
DIRECT VENT GAS STOVES
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
S25##3710A
Advertisement
Table of Contents
Related Manuals for NESTOR MARTIN R25-O25
Summary of Contents for NESTOR MARTIN R25-O25
- Page 1 R25- O25 DIRECT VENT GAS STOVES INSTALLATION AND OPERATING INSTRUCTIONS THERMIC DISTRIBUTION EUROPE 5 VOIE AXIALE 5660 COUVIN, BELGIUM WARNING If the information in this manual is not followed exactly, a fire or explosion may result causing property damage, personal injury or loss of life. Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance.
-
Page 2: Installation Requirements For The Commonwealth Of Massachusetts
Installation Requirements for the Commonwealth of Massachusetts In the Commonwealth of Massachusetts, the installer or service agent shall be a plumber or gas fitter licensed by the Commonwealth. When installed in the Commonwealth of Massachusetts or where applicable codes; the unit shall be installed with a CO detector per the requirements listed below. -
Page 3: Safety Precautions
SAFETY PRECAUTIONS For safe installation and operation of your NESTOR MARTIN stove, please, carefully read the following information: • All NESTOR MARTIN gas fired appliances must be installed in accordance with these instructions. Carefully read all the instructions in this manual first. Consult the building authority having jurisdiction to determine the need for a permit prior to commencing the installation. -
Page 4: Product Specifications
PRODUCT SPECIFICATIONS Gas type Inlet supply pressure Manifold pressure Input Pilot Burner orifice orifice size size Minimum Maximum Minimum Maximum Minimum Maximum (mm) (inch WC) (inch WC) (inch WC) (inch WC) (BTU/h) (BTU/h) Natural 7" 14" 3 " 5" 22,000 30,000 4 x 1.19 Propane... - Page 5 A 23¼" 24" 20¼" 26" 29" 18" 14" 14⅝" 4½" 4½" 4⅝" 5" 3⅓" 6⅜" 22" 21" 32" S25##3710A...
-
Page 6: Installation
INSTALLATION DECIDING WHERE TO LOCATE YOUR STOVE 1. The stove should be located out of traffic and away from furniture and draperies. 2. This stove should have sufficient access for its safe operation and maintenance. 3. Locate a position where the flue system of the stove can be properly installed without damaging the integrity of the building. -
Page 7: Vent Terminal Clearances
VENT TERMINAL CLEARANCES Installations in Canada Installations in the United States A = Clearance above grade, veranda, 12" (30cm) 12" (30cm) porch, deck, or balcony B = Clearance to window or door that 12" (30cm) 9" (23cm) may be opened C = Clearance to permanently closed 12”... - Page 8 SPECIAL CLEARANCES FOR VERTICAL VENTING (THROUGH A FLAT ROOF) vent air intake terminal Minimum clearances for vertical terminals 4’ 2’ 4’ 2’ 8’ 4’ VENTING Your stove is approved for different types of installations: A. Top flue outlet with side wall venting (using a Simpson Duravent type terminal) B.
- Page 9 Notes on Side Wall Venting with Top Flue (Configuration A) When installing a stove with a side wall venting configuration (page 6, fig. A), respect a ratio of one quarter inch rise for every 2 feet horizontal. The minimum vertical rise allowed is 2 feet (measuring from the top of the stove's flue collar to the bottom edge of the 90°...
- Page 10 Notes on Side Wall Venting with Rear Flue Outlet (Configuration B) To install a stove with a rear flue outlet and side wall vent configuration (page 6, fig.B), begin by placing the flue collar at the rear of the stove: 1.
-
Page 11: Restriction Plate
RESTRICTION PLATE A set of restriction plates is supplied with your stove to reduce flue draft when required. 58mm (2¼") restriction plate 80mm (3⅛") restriction plate 60mm (2⅜") restriction plate 70mm (2¾") restriction plate These reduction plates are to be used in the following vent configurations: Top flue exit 2' vertical rise, 2' horizontal length 6' vertical rise, 24' horizontal length... - Page 12 CERAMIC BURNER Your stove is equipped with a 100% ceramic fiber gas burner. Nestor Martin's ceramic burner offers numerous technical and esthetic advantages: - Flames and glowing effect similar to a real wood fire - Highly resistant to leaks, corrosion and deformation over time - The elasticity of its gel foam ceramic fibers allow the burner to retain its heat resistant properties without deforming, withstanding even the most extreme temperature variations.
- Page 13 PLACING THE CERAMIC LOGS Open the firebox door to access the burner, and place the logs as shown in the photos below. It is essential to the proper operation of the stove that the logs be placed correctly. Place log A onto the burner's rear positioning Place log B onto the burner's front positioning points.
- Page 14 PLACEMENT OF THE EMBER GLOW FIBERS (OPTIONAL) A bag of platinum ember glow fibers is supplied is supplied with the ceramic burner kit. When heated, the embers glow and flicker, similar to real glowing ash. The embers must be placed correctly in order to function properly.
-
Page 15: Air Shutter Adjustment
CONNECTING THE GAS SUPPLY LINE WARNING: Only persons licensed to work with gas piping may make the necessary gas connections to this appliance. The gas line connection may be made using 3/8 " rigid tubing or an approved flex connector. When using copper or flex connectors, use only fittings approved for gas connections. - Page 16 SIT IPI Sytem S25##3710A...
-
Page 17: Maintenance
MAINTENANCE Before conducting any maintenance on the stove, always make sure that the stove is switched off and has had time to cool. WARNING: The area around the appliance must be kept clear and free from combustible materials, gasoline and other flammable vapors and liquids. •... -
Page 18: Replacing The Glass
5. Screw the retainer clamps back on. 6. Put the door back on its hinges. • Always use original Nestor Martin spare parts. • Make sure that the edges of the glass panel will not touch metal parts during thermal expansion. -
Page 19: Warranty
NESTOR MARTIN does not authorize any person or company to assume any other obligation or liability in connection with the sale, application engineering, installation, use, removal, return or replacement of its equipment;...
