- Page 1 WOODBOX TECHNOLOGY ® Instructions Thermic Distribution Europe / 5 Rue du Lion - 5660 Couvin - Belgium IQ33#6700A...
- Page 2 Instructions Thermic Distribution Europe s.a. 5, rue du Lion 5660 Couvin Belgique...
- Page 3 • In the event of a problem, contact him directly. • Ask him to obtain the original NESTOR MARTIN parts. Beware of forgeries. To obtain a part, contact your installer/ dealer in order to identify the order number of the part. Pass on this information to your installer and he will order the part directly from NESTOR MARTIN.
-
Page 4: Installation
INSTALLATION DIMENSIONS IQH13 IQ33 IQ43 IQH33 IQH43 L [mm] H1 [mm] H2 [mm] h [mm] I [mm] P [mm] b [mm] a [mm] D [mm] d [mm]... - Page 5 dimensions with frames IQ33 IQ43 IQH13 IQH33 IQH43 type of frame frame 3 sides width 25 mm 618 661 726 683 476 886 618 927 726 863 frame 4 sides width 25 mm 618 678 726 700 476 903 618 944 726 880 frame 3 sides width 50mm 668 686 776 708 526 911 668 952 776 888 frame 4 sides width 50mm...
-
Page 6: Installation Instructions
INSTALLATION INSTRUCTIONS • Installation must conform to current building regulations. • The position of the appliance must respect the minimal distances in regards to combustible materials, shown on the descriptive plate. If necessary, install a wall protector. If the ground is not tiled, (i.e. fi tted carpet, parquet…) install a fl... - Page 7 HOT AIR DISTRIBUTION Your appliance is equipped with a heat recovery system and two fl ue outlets which allow fl exible tubes to be connected. The fl exible tubes can be arranged in such a way that the hot air is blown into other rooms. If you prefer the hot air to come from the ducts and from the front at the same time, it is possible to remove the defl...
- Page 8 ATTACHING THE FRAMES (OPTIONAL) fi xing screw of original frame left stopper left stopper fi xing screw of original frame original frame optional frame fi xing screw of optional frame To attach one of the optional frames, proceed as follows: Remove the original frame’s fi...
- Page 9 POSITIONING THE INSET Respect the minimal fi tting measurements type 1 confi guration, with overfl owing frame type 2 confi guration, with fi tted frame D = height of inset F = width of inset M = depth of inset N + 20mm = Maximum dimension between the chimney posts.
- Page 10 ACCESSING THE FAN Your appliance can be used as a natural convection heater or with a fan. Space is provided at the bottom of the outer casing for a tangential fan. To access this fan: Unscrew and remove the instrument panel (2 screws) Unscrew the two fi...
- Page 11 Remove the sliding plate containing the fan and the control accessories (2 screws)
-
Page 12: Electrical Diagram
ELECTRICAL DIAGRAM Wiring for IQ33, IQ43, IQH33, IQH43 live wire neutral wire earth wire Speed drive The clixon closes the circuit when the temperature goes above 50°C. The ventilator fan starts to function at the speed set by the speed switch drive. -
Page 13: Wiring Diagram
WIRING DIAGRAM switch IQ33, IQ43, IQH33, IQH43 speed drive switch IQH13 speed drive... - Page 14 ATTACHING AN EXTERIOR AIR-INTAKE SYSTEM The appliance is designed so it can be connected to an exterior air-intake system. Use a fl exible metal pipe of an interior diameter of 100mm. to make attaching the pipe easier, fi rst unscrew and remove the instrument panel. slide the teloscopic nozzles until the they touch the top of the box...
- Page 15 INSTALLATION WITHOUT EXTERIOR AIR INTAKE To allow the combustion air to come from the front of the appliance, remove this part by raising two screws...
-
Page 16: Approved Fuels
FUELS APPROVED FUELS Your appliance has been designed to burn the following approved fuels: Recommended solid fuels: beech wood, birch, oak, ash, hornbeam and wood from fruit trees. Non-recommended solid fuels: conifer, damp wood, chemically treated wood, shavings, wood pellets, coke. It is prohibited to burn refuse or fl... - Page 17 USER INSTRUCTIONS THE CONTROLS The appliance has two main controls: The UPPER AIR FLOW control The LOWER AIR FLOW control The two controls can be used together in a way to combine the two air fl ows to achieve optimum performance WARNING: the controls can be hot.
- Page 18 Controls>different uses With the Woodbox combustion system, the air needed for the combustion can be brought from above or below the fi re according to the type of fuel used. A wood fi re must be fuelled from above (upper air supply), while a coal fi re is better fuelled from below (lower air supply).
- Page 19 USING WOOD> LIGHTING MANUALY • Set the UPPER AIR SUPPLY to maximum • Set the LOWER AIR SUPPLY to maximum Tip: leave the door slightly open to stoke the fi re. It will increase the draw and allow an ember bed to be achieved. •...
- Page 20 USING WOOD>ADDING LOGS To prevent smoke fumes from entering the room while adding wood and to ensure a rapid recovery of the hearth, do as follows: • Refi ll the appliance only when there is no longer an ember bed. •...
- Page 21 To avoid an overfl ow of ashes, empty the ashtray regularly. However, a fi ne layer of ash on the grate helps the combustion of the wood and retains heat. It is advisable to empty the ashtray when the appliance is not in use. To remove the ashes, drop them from the hearth into the ashtray through the grate with the tool provided.
-
Page 22: Utilisation De La Télécommande
SELF-CLEANING OF THE WINDOW Your appliance is equipped with an integrated glass pane cleaning system (“Airwash”) which uses hot air to minimalize the marks on the glass pane. If you use a dry fuel, a large part of the tar deposited on the window will burn and disappear when the appliance is running at a high temperature. -
Page 23: First Use
fi nish as the abrasion can cause marks that are diffi cult to remove. To clean a painted appliance, use a stiff brush. For tough marks, it is better to touch up the paint with a paint designed for stoves (NESTOR MARTIN high temperature gloss paint) than to try to clean them. -
Page 24: Garantie
NESTORMARTIN. To make a warranty request for a faulty part, have the part replaced and send the faulty part to a NESTOR MARTIN distributor for inspection. If the fault is covered by the warranty, you will not be charged for the replacement part.
