Setting Instructions for Movement Caliber C660
Contents
(click on a topic)
2. Before using this watch
4. Switching Modes (Display Functions)
Around the World
7. Switching between the Analog and Digital Times
16. About the All RESET Procedure
c. Overcharging Prevention Function
e. Power Save 2
19. Notes Regarding Use of this Watch
20. Care of Your Timepiece

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Movement Caliber C660 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Citizen Movement Caliber C660

Summary of Contents for Citizen Movement Caliber C660

  • Page 1: Table Of Contents

    Setting Instructions for Movement Caliber C660 Contents (click on a topic) 1. Features 2. Before using this watch 3. Names of Components and Major Functions 4. Switching Modes (Display Functions) 5. Checking ‘0’ Position of Each Hand 6. Accessing Times and Dates of Major Cities Around the World 7.

  • Page 2: Features

    Return to Table of Contents 1. FEATURES This watch is a combination solar – powered watch that contains a solar cell in its face that drives the watch hands, race time, chronograph, alarm and numerous other functions by converting light energy into electrical energy. It is also equipped with convenient functions including a power save mode that reduces power consumption when light is not shining on the solar cell, UTC (Coordinated Universal Time), and a world timer indicating the time and dates of...

  • Page 3: Names Of Components And Major Functions

    Return to Table of Contents 3. NAMES OF COMPONENTS AND MAJOR FUNCTIONS Name /Mode Time Calendar Timer Chrono - Timer Alarm Alarm 2 Zone graph (1) Mode Hand RACE AL-1 AL-2 (2) Hour Hand Always Indicates Hours (3) Minute Hand Always Indicates Minutes (4) Second Hand Always Indicates Seconds...

  • Page 4: Checking '0' Position Of Each Hand

    Return to Table of Contents 4. SWITCHING THE MODE (DISPLAY FUNCTIONS) In addition to the time and date modes, this watch is also equipped with three a race timer, chronograph, countdown timer as well as alarm 1 and alarm 1. The mode can be switched by turning the crown.
  • Page 5 Return to Table of Contents O-Position Correction (Setting to the Watch Base ‘0’ Position) When setting the 0-position of each hand, always make sure to turn the crown forward (clock-wise) to set each hand to its 0-position in the clockwise direction.

  • Page 6: Accessing Times And Dates Of Major Cities

    Return to Table of Contents 6. ACCESSING TIMES OR DATES OF MAJOR CITIES The time of date of major cities pre-registered in this watch can be easily accessed by pressing the buttons. <Access Procedure> Turn the crown to set the mode hand to the time [TME] or calendar [CAL] mode.

  • Page 7: Hand Evacuation Function

    Return to Table of Contents 7. SWITCHING ANALOG TIME AND DIGITAL TIME This watch is able to switch between analog time display and digital time display. <Switching Procedure> 1. Turn the crown to set the mode hand to the time [TME) mode. 2.

  • Page 8: Setting The Time

    Return to Table of Contents 9. SETTING THE TIME (TIME IS CORRECTED BY DIGITAL DISPLAY) When digital time is corrected, the second, minute, hour, 24 hour and UTC hour and minute hands of the analog time are corrected automatically in conjunction with digital time.

  • Page 9: Setting The Date

    Return to Table of Contents 10. SETTING THE DATE (DATE IS CORRECTED BY DIGITAL DISPLAY) 1. Turn the crown and set the mode hand to the calendar [CAL] mode. 2. Press either button (A) or button (B) to access the city to be corrected. 3.

  • Page 10: Using The Race Timer

    Return to Table of Contents 11. Using the Race Timer The race timer is able to set the time for 5-minute intervals for times between 60 and 10 minutes, and to 6,5,4,3,2 and 1 minute. <Setting the Race Timer> 3. Turn the crown and set the mode hand to the [RACE] race timer position. 4.
  • Page 11 Return to Table of Contents <Using The Auto Chronograph Measurement> When the race timer measurement is finished, upon finishing simultaneously, it changes to the auto chronograph that starts counting down automatically. The auto chronograph measures to a maximum of 23 hours, 59 minutes and 59 seconds in 1- second increments.

  • Page 12: Using The Chronograph

    Return to Table of Contents 12. USING THE CHRONOGRAPH The chronograph is able to measure and display time up to a maximum of 23 hours, 59 minutes, 59.99 seconds in 1/100th second units. After 24 hours have elapsed, the chronograph automatically returns to the chronograph reset display (00'00"00) and stops.

  • Page 13: Using The Timer

    Return to Table of Contents 13. USING THE TIMER The timer can be set to a maximum of 99 minutes in 1-minute units. When the set time has elapsed, a tone indicating that the set time is up sounds for about 5 seconds, after which the timer returns to the timer initial setting display.

  • Page 14: Using The Alarm

    Return to Table of Contents 14. USING THE ALARM The alarm setting procedure and other procedures for alarm use are the same for Alarm 1 and 2. Only the tone that sounds is different. The alarm sounds for 15 seconds when the set time is reached once a day. When the alarm is sounding, it can be turned off by pressing button (A) or (B).

  • Page 15: Using Zone Setting

    Return to Table of Contents 15. USING ZONE SETTING The zone setting function enables only those cities for which "SET" has been selected to be easily accessed (displayed) in each mode. <Using Zone Setting> 1. 1.Turn the crown while in the normal position and set the mode hand to the mode setting [SET] mode.

  • Page 16: Functions Unique To This Solar Powered Watches

    Return to Table of Contents 17. Functions Unique to this Solar Powered Watch When the watch When power becomes generation stops insufficiently as a result of charged light not shining on the watch When the watch is charged Insufficient Charge Warning Analog Display Two Second Interval When power...
  • Page 17 Return to Table of Contents [Insufficient Charging Warning Function] Regardless of the display (Mode) of the watch at (Analog Display) the time, when the watch becomes insufficiently charged, the watch changes to the time display and the second hand begins to move at two-second- interval movement.
  • Page 18 Return to Table of Contents [Time Setting Warning Function] (Analog Display) The watch stops when insufficient charging continues for about 1.5 days. When the watch is charged by exposing to light after having stopped due to insufficient charging, each hand is rapidly advanced to the base position and stops.
  • Page 19 Return to Table of Contents [Power Save 1] When power is not generated as a result of the solar cell not being exposed to light, the second hand stops when it reaches the zero seconds position and the watch automatically enters the power save state to inhibit power consumption of the secondary battery.

  • Page 20: General Reference For Charge Times

    Return to Table of Contents 18. GENERAL REFERENCE FOR CHARGING TIMES The time required for recharging varies according to the model of the watch (color of the dial, etc). The following times are shown below to serve only as a reference.

  • Page 21: Specifications

    Return to Table of Contents PRECAUTIONS ABOUT CARE AND HANDLING OF WATCHES TEMPERATURE CARE that water resistant quality remains at factory specifications. Avoid temperature extremes. Exposing your watch to high temperatures, such as placing it on the dashboard of a vehicle CARE FOR METAL BRACELETS or use in a hot tub, may cause the watch to malfunction, To extend the life and maintain the good appearance of the...

  • Page 22: Water Resistance

    Return to Table of Contents Water Resistance The water-resistant quality of our timepieces is offered in varying degrees depending on the model. This ranges from non-water resistant models to those suitable for SCUBA diving. Water resistance of our timepieces is measured in BAR or Barometric Pressure. Each BAR of pressure is equal to 14.5 pounds per square inch of pressure.

  • Page 23: Specifications

    Return to Table of Contents 21. Specifications Movement Caliber Number C660 Accuracy Within +/- 15 seconds per month (when worn at normal temperatures of 5 C to 35 C/(41 F to 95 Operating temperature range Watch operating temperature range : 0 C +55 C (32 F to...
