Thank you for your purchase of this Citizen watch. Before using the watch, read this instruction manual carefully to ensure correct use. After reading the manual, store it in a safe place for future reference. Visit the Citizen website (http://www.citizenwatch-global.com/) to view visual guides for operation of your watch.
Page 3
Safety precautions (IMPORTANT) This manual contains instructions that should be strictly followed at all times not only for optimal use, but to prevent any injuries to yourself, other persons or property. We encourage you to read the entire booklet (especially, pages 68 to 79) and understand the meaning of the following symbols: ■...
Page 4
Safety precautions (IMPORTANT) ■ Important instructions are categorized and depicted in this manual as follows: Warning (caution) symbol followed by instructions that should be followed or precautions that should be observed. Warning (caution) symbol followed by prohibited matters.
Page 5
Before using this watch After unpacking, the following must be carried out before using the watch: ◆ Checking the power reserve Page 17 Check the charge level of the watch. ◆ Setting the World Time Page 21 Select the city for which you want to indicate the time and date. ◆ Receiving the satellite time signal ...
Page 6
We recommend seeking the assistance of an experienced watch technician for sizing of your watch. If adjustment is not done correctly, the bracelet may unexpectedly become detached leading to loss of your watch or injury. Consult your nearest authorized Citizen service center.
Page 7
Before using this watch ◆ How to use a specially designed crown/push button Some models are equipped with a specially designed crown and/or push button to prevent accidental operation. Screw down crown and screw down push button Unlock the crown prior to operate your watch. Unlock Lock Rotate the crown...
Page 8
Before using this watch Recessed buttons Press the button with a narrow-tipped object such as a wooden toothpick.
Table of contents Features ……………………………………………………………… 10 Component identification ………………………………………… 11 Charging your watch ………………………………………………… 12 Using the world time function ……………………………………… 20 Switching summer time and standard time ……………………… 25 Before receiving the satellite time signal ………………………… 28 Turning off the signal reception …………………………………… 34 Receiving the satellite time signal …………………………………...
Page 10
Table of contents Checking and correcting the current reference position ………… 56 Troubleshooting …………………………………………………… 60 Eco-Drive (solar powered) watch handling precautions ………… 68 Water resistance …………………………………………………… 72 Precautionary items and usage limitations ……………………… 74 Specifications ………………………………………………………… 80...
"Perpetual calendar" No need for date correction at the end of each month. The leap year is also updated automatically. "World Time" Easy to see the time and calendar of cities all over the world. * "Eco-Drive" is Citizen original technologies.
Component identification Reception-in-progress indication (RX) Minute hand Hour hand Ⓑ Upper right button Reception result indicator (OK/NO) Function indication • Day of the week Crown • Summer Time indication (ON/OFF) 24-hour hand • Power reserve level Ⓐ Lower right button Second hand City indication Date indication...
Charging your watch This watch has a rechargeable cell which is charged by exposing the dial to light, such as direct sunlight or fluorescent lamps. After taking off the watch, put it in a location where the dial is exposed to bright light, such as by a window.
Page 14
Charging your watch • If the watch is obscured from light by long sleeves frequently, supplemental charging may be needed to ensure continual operation. • Do not charge the watch at a high temperature (about 60°C (140°F) or higher) as doing so may cause movement malfunction.
Page 15
Charging your watch ◆ When the watch reaches a low charge state (insufficient charge warning function) When the power reserve becomes low, the second hand moves once every two seconds. This is the insufficient charge warning function. Be sure to fully charge your watch.
Page 16
Charging your watch ◆ Charging time by environment Below are the approximate times required for charging when exposing the watch dial to light continuously. Please use this table as a reference only. Charging time (approx.) Illuminance To start working To become fully Environment To work for one (lx)
Page 17
Charging your watch Caution: This watch uses a special rechargeable cell. • If the surrounding temperature falls below 0°C (32°F) or exceeds 40°C (104°F), the “Charge suspension temperature detection function” will activate and charging will not be possible. • If you do not charge the watch for 60 days after it has stopped, the “Over discharge detection function”...
Charging your watch ◆ Checking the power reserve Check the current power reserve. 1. Ensure that the crown is in position 0 . 2. Press the lower right button Ⓐ . The function indication shows the power reserve level. • For details on the power reserve level, see the next page.
Page 19
Charging your watch Charging your watch The power reserve level Level Power reserve level Approx. 730 to 365 days Approx. 365 to 16 days Approx. 16 to 10 days Approx. 10 days Power reserve Power reserve is Power reserve is Power reserve is Approximate is sufficient for...
Page 20
Charging your watch • When the power reserve is at the CHARGE level, the second hand indicates the insufficient charge warning state (by moving once every two seconds). You can manually correct the time and calendar, but you cannot perform the other operations and receive satellite signals.
Using the world time function ◆ Confirming the world time Check the current world time (city) setting. 1. Ensure that the crown is in position 0 . Ⓑ 2. Press the upper right button Ⓑ . The second hand indicates the city currently selected.
Using the world time function ◆ Setting the World Time The watch can indicate the time and date of any of the 26 cities in the world you choose. • When using the watch in an area not listed in the table below, select and set the city with the same time difference. 1. Pull the crown out to position . The second hand indicates the current city setting, and the function indication shows the current summer time ON/OFF setting.
Page 23
Using the world time function ◆ City indication table Abbreviation City indication or second hand position Time difference LONDON 0 sec. PARIS 2 sec. ATHENS 4 sec. RIYADH 7 sec. DUBAI 9 sec. KARACHI 11 sec. DELHI 14 sec. +5.5 DACCA 16 sec.
Page 24
Using the world time function Abbreviation City indication or second hand position Time difference ADELAIDE 25 sec. +9.5 SYDNEY 28 sec. NOUMEA 30 sec. AUCKLAND 32 sec. MIDWAY ISLANDS 35 sec. −11 HONOLULU 37 sec. −10 ANCHORAGE 39 sec. −9 LOS ANGELES 42 sec.
Page 25
Using the world time function Abbreviation City indication or second hand position Time difference SANTIAGO 51 sec. −4 RIO DE JANEIRO 53 sec. −3 FERNANDO DE NORONHA 56 sec. −2 AZORES 58 sec. −1 • The city indications displayed on the watch may be different, depending on the model. • The time difference in the table above is based on UTC. • The time difference may change depending on the country or area.
Switching summer time and standard time ◆ Summer time Summer Time is a system adopted in some countries/areas to gain an extra hour of daylight during summer by advancing clocks by one hour. This watch can display summer time or standard time according to the city selected for world time.
Page 27
Switching summer time and standard time ◆ Checking the time currently shown Check whether the watch shows Summer Time or standard time. 1. Ensure that the crown is in position 0 . Ⓑ 2. Press the upper right button Ⓑ . The function indication shows the summer time ON/ OFF setting.
Page 28
Switching summer time and standard time ◆ Changing the summer time setting 1. Pull the crown out to position . 2. Press the lower right button Ⓐ to switch the summer time setting to ON or OFF. To show summer time Select "ON".
Before receiving the satellite time signal This watch receives the clock time information sent by satellite. This watch only receives time information. Location information cannot be acquired. ◆ Receiving the satellite time signal The satellite time signal can be received using the following three methods. You can also check whether the last attempt to receive the time signal was successful or not.
Page 30
Before receiving the satellite time signal When All Reset has been performed or you have manually adjusted the calendar, reception may take up to 70 seconds.
Page 31
Before receiving the satellite time signal ◆ Cautions regarding receiving the satellite time signal Do not perform satellite time signal reception while operating a vehicle as doing so is extremely dangerous. • If the second hand is moving once every two seconds (insufficient charge warning function), you cannot perform satellite time signal reception. Charge the watch sufficiently before attempting time signal reception.
Page 32
Before receiving the satellite time signal ◆ When receiving the satellite time signal As shown in the picture below, make sure you are in an area with few surrounding trees, buildings, or other objects with may obstruct the satellite time signal. Face the dial towards the sky and perform time signal reception.
Page 33
Before receiving the satellite time signal • Receiving signals indoors near a window • Place the watch near a window with a wide view of the sky and orient the dial in an obliquely upward direction (approximately 45°). • If there are buildings, trees, or other obstacles above the window, satellite signals may not be able to be received. • The direction of the window that allow signal reception may be limited. Find the direction in which you can securely receive signals. • Satellite signals may not be able to be received through wire-reinforced glass or heat reflective glass (or film).
Page 34
Before receiving the satellite time signal ◆ Poor reception areas It may be difficult to receive the satellite time signal under certain environmental conditions or in certain areas. Areas with obstructions above the Nearby objects which emit magnetism watch or noise • High-voltage electric cables, railway • Indoors or underground • Areas surrounded by tall...
Turning off the signal reception You can turn off the signal reception on aircrafts or in areas where use of radio waves is prohibited. 1. Pull the crown out to position . 2. Press and hold the upper right button Ⓑ for two or Ⓑ...
Receiving the satellite time signal ◆ Manual reception 1 Use this method for normal reception. 1. Ensure that the crown is in position 0 . 2. Press and hold the lower right button Ⓐ for two or more seconds. After indicating the previous reception result, the tail of the second hand moves to “RX”...
Page 37
Receiving the satellite time signal The second hand will move normally once reception is finished and the reception result has been displayed for 2 seconds. Successful signal reception Failed signal reception Reception result (OK) Reception result (NO) The time will be updated and the Normal operation resumes with the previously set time.
Page 38
Receiving the satellite time signal To cancel the reception Press and hold the lower right button Ⓐ for two or more seconds. The reception is canceled and the current time will be indicated. • If the time is not correct even after performing signal reception, it is possible that the leap second has been updated.
Receiving the satellite time signal ◆ Manual reception 2 Use this method when the leap second has been updated or when all reset has been performed. 1. Ensure that the crown is in position 0 . 2. Press and hold the lower right button Ⓐ for seven or more seconds.
Page 40
Receiving the satellite time signal The second hand will move normally once reception is finish and the reception result has been displayed for 2 seconds. Successful signal reception Failed signal reception Reception result (OK) Reception result (NO) The time will be Normal operation updated and the watch resumes with the...
Page 41
Receiving the satellite time signal ◆ Checking the satellite time signal reception You can check the previous result of satellite time signal reception (Manual 1/ Manual 2/Circumstantial reception). 1. Ensure that the crown is in position 0 . 2. Press the lower right button Ⓐ . The tail of the second hand indicates the reception result.
Page 42
Receiving the satellite time signal • Even if reception has succeeded, “NO” will be indicated if more than 48 hours have passed since time signal reception was last performed. • The second hand also indicates the "OFF" if signal reception is set to OFF. (See page 34.) 3. Press and release the lower right button Ⓐ to finish the procedure. • The current time indication will resume automatically when leaving the watch for approx. 10 seconds.
Page 43
Receiving the satellite time signal ◆ About circumstantial reception If the satellite time signal has not been received for an extended period of time, this watch is equipped with a function which enables it to automatically receive the time signal (circumstantial reception). When the following five conditions are met, the watch will start automatic reception.
Checking and adjusting leap seconds This watch displays the time information by setting the leap second and time difference (manual adjustment) to the International Atomic Time information received from the satellite. • The leap second setting is specified according to the time of shipment. "-35 seconds” is specified as of January 2013. • When the leap second information is received through performing manual reception 2 (see page 38), the leap second is automatically adjusted. • The leap second can also be adjusted manually. You can find a list of leap seconds at the homepage of IERS (INTERNATIONAL EARTH ROTATION &...
Page 45
Checking and adjusting leap seconds 1. Pull the crown out to position 2 . Ⓑ 2. Press the upper right button Ⓑ . Using the "0:00:00" position as the starting point, the minute hand and second hand will indicate the leap second setting after a few seconds. When 0 minutes and When 1 minute and 35 seconds is indicated: 5 seconds is indicated:...
Page 46
Checking and adjusting leap seconds 3. Rotate the crown to adjust the leap second. • The leap second can be adjusted in the range of 0 to –90 seconds. 4. Push the crown in to position 0 to finish the procedure. The leap second setting is specified according to the time of shipment. "-35 seconds” is specified as of January 2013.
Checking and adjusting the rollover number In order for this watch to correctly process the week information* received from the satellite, a rollover number for each time period is set. The rollover numbers will be updated automatically. If the rollover number setting is incorrect, the time and date may not be displayed accurately.
Page 48
Checking and adjusting the rollover number Time period (Coordinated Universal Time, GMT) Rollover number 22/8/1999 (Sun) 00:00 – 6/4/2019 (Sat) 23:59 7/4/2019 (Sun) 00:00 – 20/11/2038 (Sat) 23:59 21/11/2038 (Sun) 00:00 – 6/7/2058 (Sat) 23:59 7/7/2058 (Sun) 00:00 – 19/2/2078 (Sat) 23:59 20/2/2078 (Sun) 00:00 –...
Page 49
Checking and adjusting the rollover number 1. Pull the crown out to position 2 . Ⓑ 2. Press the upper right button Ⓑ . The minute hand and second hand will indicate the current leap second setting. 3. Press and hold the upper right button Ⓑ for five or more seconds.
Page 50
Checking and adjusting the rollover number 4. Rotate the crown to adjust the rollover number. • The rollover number can be adjusted in the range of 0 – 5. See the table on page 47 for appropriate rollover number. 5. Push the crown in to position 0 to finish the procedure.
Adjusting the time/calendar manually Manually adjust the time/calendar when the watch cannot receive the time signal. 1. Pull the crown out to position 2 . The second hand moves to the 30-second position. 2. Press the lower right button Ⓐ . The second hand moves to the 0 second position, and it becomes possible to adjust the time/calendar. 0 1 2 Ⓐ...
Page 52
Adjusting the time/calendar manually 3. Press the lower right button Ⓐ to select the ② ⑤ correction target. Each time you press the lower right button Ⓐ , the correction target changes as follows and the corresponding hand slightly moves. ① ② Time (minutes) → Time (hours/24-hour time) → ③...
Page 53
Adjusting the time/calendar manually 4. Rotate the crown to adjust each setting. • If you spin the crown quickly, the hands for the time and day will move continuously. To slow down and stop them, slightly rotate the crown. • To move the date forward or backward by one day, slightly rotate the crown. • The year and month are indicated by the second hand. Adjust them by referring to the figure in the next page. 5. Repeat procedures 3 and 4. 6. On the stroke of the time signal, push the crown in to position 0 to finish the setting.
Page 54
Adjusting the time/calendar manually ◆ Month and year indications The number of years and months since the leap year is December indicated by the position of the second hand. [Month] January December : between 12:00 and 01:00 January : between 01:00 and 02:00 February : between 02:00 and 03:00 [Year] Leap year:...
Page 55
Adjusting the time/calendar manually You can get the actual year from the number of years passed from the leap year by referring to the following table: Indication of the second hand Passed year Year Hour marker Leap year 2016, 2020, 2024 1st min.
Page 56
Adjusting the time/calendar manually February 3rd year The figure shows February in the 3rd year since the last leap year.
Checking and correcting the current reference position ◆ What is the reference position? The base position for all the hands to indicate the time and date. If the reference position is not correct, the time and functions are not indicated correctly.
Page 58
Checking and correcting the current reference position ◆ Checking and correcting the current reference position 1. Ensure that the crown is in position 0 . Ⓑ 2. Press and hold the upper right button Ⓑ for seven seconds. All hands and the date indication move to indicate the current reference position.
Page 59
Checking and correcting the current reference position ② 5. Press the lower right button Ⓐ to select the correction target. Each time you press the lower right button Ⓐ , the correction target changes as follows and the corresponding hand slightly moves. ① Day of the week (function indication)/date Ⓐ indication → ②...
Page 60
Checking and correcting the current reference position 6. Rotate the crown to correct the reference position of the active hand/ indication. • When you rotate the crown quickly, each hand will move continuously. To slow down and stop them, slightly rotate the crown. 7. Push the crown in to position 0 to finish the correction. 8.
Troubleshooting If you have a problem with your watch, check the table below. Problems with time signal reception. Symptoms Remedies Page Cannot start signal reception or cannot Check to see if the signal reception setting is turned ON. confirm signal reception.
(Continued) manual reception. If the remedies above do not solve the problems, — consult your nearest Authorized Citizen Service Center. Check and correct the World Time setting. 20 to 24 If the time is not indicated correctly after performing 38 to 39 manual reception 1, perform manual reception 2.
Page 63
Troubleshooting The hands do not work properly. Symptoms Remedies Page The second hand moves once every two Charge the watch. 12 to 16 seconds. Push the crown in to position 0 . — All hands stop moving. Charge the watch by exposing it to direct sunlight 12 to 16 until the second hand starts moving every second.
Page 64
Troubleshooting The time and/or date is incorrect. Symptoms Remedies Page Check the World Time setting. 20 to 24 Change the Summer Time setting. 25 to 27 The time and/or date is Check and correct the current reference position. 56 to 59 incorrect.
Page 65
Send the watch to your nearest Authorized Citizen Service Center. Charge the watch for 2 to 3 days under direct sunlight. If the second hand starts moving once every two seconds The watch stops the watch is being charged correctly.
Troubleshooting ◆ All Reset When the watch does not work properly, you can reset all the settings. If the power reserve is insufficient, charge the watch first. Check before performing All Reset. After performing All Reset, you need to configure all the settings again. Set the watch again by following the procedures.
Page 67
Troubleshooting 1. Correct the current reference position. See page 57. After performing All Reset, the watch is in reference position correction mode. See from step 5 on page 58. 2. Set the World Time. See page 21. • To set Summer Time, see page 27. 3. Adjust the time/calendar. • For adjustment through receiving the satellite time signal: See pages 35.
Page 68
Troubleshooting ◆ Performing All Reset Perform this operation after checking the contents of the previous page. 1. Pull the crown out to position 2 . 2. Press and hold both the lower right button Ⓐ and the Ⓑ upper right button Ⓑ for three or more seconds. The second hand moves to the “0” second position, the hour hand and date indication move slightly, and the watch is reset.
Eco-Drive (solar powered) watch handling precautions <Always Make Sure to Recharge Frequently> • Please note that if you wear long sleeves, the watch may stop as a result of being covered by your sleeve and blocked from the light. • When you take off the watch, try to place it in as bright a location as possible. This will ensure optimal operation.
Page 70
Eco-Drive (solar powered) watch handling precautions CAUTION Recharging Precautions • Do not charge the watch at a high temperature (about 60°C (140°F) or higher) as doing so may cause the movement to malfunction. Examples: - Charging the watch too close to a light source which generates a large amount of heat such as an incandescent lamp or halogen lamp. * When charging under an incandescent lamp, be sure to leave 50 cm (19-11/16 inch) or more between the lamp and the watch to avoid exposing the watch to excessive heat.
Page 71
Eco-Drive (solar powered) watch handling precautions <Replacement of Rechargeable Cell> • This watch utilizes a special rechargeable cell that does not require regular replacement. However power consumption may increase after using the watch for a number of years due to wear of internal components and deterioration of oils. This may cause stored power to be depleted at a faster rate. For optimal performance, we recommend having your watch inspected (chargeable to the owner) by an Authorized Service center to ensure operation is within factory specifications.
Page 72
Eco-Drive (solar powered) watch handling precautions WARNING Use Only the Specified Battery • Never use a battery other than the rechargeable cell specified for use in this watch. Although the watch structure is designed so that it will not operate when another type of battery is installed, if a silver battery or other type of battery is installed in the watch and the watch is recharged, there is the risk of overcharging which may cause the battery to rupture.
Water resistance WARNING Water Resistance • Refer to the watch dial and the case back for the indication of the water resistance of your watch. The following chart provides examples of use for reference to ensure that your watch is used properly. (The unit "1bar" is roughly equal to 1 atmosphere.) • WATER RESIST(ANT) ××bar may also be indicated as W.R.××bar. • Non-water resistant models are not designed to come into contact with any moisture. Take care not to expose a watch with this rating to any type of moisture. • Water resistance for daily use (to 3 atmospheres) means the watch is water resistant for occasional accidental splashing.
Page 74
Water resistance • Upgraded water resistance for daily use (to 5 atmospheres) means that the watch may be worn while swimming, but is not to worn while skin diving. • Upgraded water resistance for daily use (to 10/20 atmospheres) means that the watch may be worn while skin diving, but not while scuba or saturated diving using helium gas. Water-related use Minor exposure Swimming and Operate the crown to water (washing general washing Skin diving, Scuba diving...
Precautionary items and usage limitations CAUTION To Avoid Injury • Be particularly careful when wearing your watch while holding a small child, to avoid injury. • Be particularly careful when engaged in strenuous exercise or work, to avoid injury to yourself and others. • Do NOT wear your watch while in a sauna or other location where your watch may become excessively hot, since there is the risk of burns. • Be careful when putting on and taking off your watch, since there is a risk of damaging your fingernails, depending on the manner in which the band is fastened. • Take off your watch before going to bed. CAUTION Precautions • Always use the watch with the crown pushed in (normal position). If the crown is of the screw...
Precautionary items and usage limitations • Even if your watch has a high level of water resistance, please be careful of the following. - If your watch is immersed in sea water, rinse thoroughly with fresh water and wipe with a dry cloth. - Do not pour water from a tap directly onto your watch. - Take off your watch before taking a bath. • If seawater enters the watch, place the watch in a box or plastic bag and immediately take it in for repair. Otherwise, pressure inside the watch will increase, and parts (crystal, crown, push button, etc.) may come off.
Page 77
- The pin of the band is protruding. • We recommend seeking the assistance of an experienced watch technician for sizing of your watch. If adjustment is not done correctly, the bracelet may unexpectedly become detached leading to loss of your watch or injury. Consult your nearest authorized Citizen service center. <Temperature> • The watch may stop or the function of the watch may be impaired in extremely high or low temperature. Do not use the watch in places where the temperature is outside the operating...
Precautionary items and usage limitations <Strong Shock> • Avoid dropping the watch or subjecting it to other strong impact. It may cause malfunctions and/ or performance deterioration as well as damage to the case and bracelet. <Static Electricity> • The integrated circuits (IC) used in quartz watches are sensitive to static electricity. Please note that the watch may operate erratically or not at all if exposed to intense static electricity. <Chemicals, Corrosive Gasses and Mercury>...
Page 79
Precautionary items and usage limitations CAUTION Always Keep Your Watch Clean • Rotate the crown while it is pressed in fully and press the buttons periodically so they do not become stuck due to accumulations of foreign matter. • The case and band of the watch come into direct contact with the skin in the same manner as undergarments. Corrosion of the metal or unnoticed soiling such as that caused by perspiration and dirt can soil sleeves and other portions of clothing. Keep your watch clean at all times. • The case and band of the watch come into direct contact with the skin. If you think there is something wrong, discontinue wearing the watch immediately and consult your physician.
Precautionary items and usage limitations Caring for Your Watch • Wipe any dirt or moisture such as perspiration from the case and crystal with a soft cloth. • For a metallic, plastic or rubber (urethane) watchband, wash any dirt off with water. Remove the small amounts of dirt trapped between the crevices of the metallic band with a soft brush. • For a leather band, wipe off dirt using a dry cloth. • If you will not be using your watch for an extended period of time, carefully wipe off any perspiration, dirt or moisture and store in a proper location, avoiding locations subject to excessively high or low temperatures and high humidity.
Specifications Model Type H90* Analog solar-powered watch Timekeeping Within ±15 seconds per month when worn at normal operation accuracy (without temperatures (between +5°C and +35°C (between 41°F and 95°F) ) reception) Operating temperature -10°C to +60°C (14°F to 140°F) range Chargeable temperature 0°C to +40°C (32°F to 104°F)
Page 82
Specifications • Solar power function • Power reserve indication • Charge suspension temperature detection function • Overcharging prevention function • Over discharge detection function • Insufficient charge warning function (two-second interval movement) • Satellite time signal reception function (manual reception 1/manual reception 2/circumstantial reception) Additional •...
Page 83
This product follows the provisions of R&TTE Directive (1999/5/EC) ETSI EN300 440-2 V1.4.1 ETSI EN301 489-3 V1.4.1 EN60950-1 : 2006 +A12 : 2011...
