Tail Control Test

1. Switch on the transmitter. Check the LED.
Do not touch the sticks for 2 seconds
while the transmitter automatically
calibrates the controls.
2. Install the battery in the fuselage slot and
plug in the connector.
3. Move the right stick side to side. The
flaps should move as shown on the
following page. If each flap is not level
with the rest of the tail surface when
the right stick and trim lever are centered,
adjust the control lines so they are level
(see page 20).
Note: The small levers under or beside the
control sticks are called trim levers and are
used to adjust the "neutral" points of your
control sticks. It's very important that these
levers are centered when switching on the
transmitter and performing the control test.
8
WARNING: Be sure to keep everything
clear of the propeller when the tail control
test is performed in the event that the
motor is accidentally engaged.
Tail Control Test (continued)
View from
Rear
Moves Up
View from
Rear
Moves Up
