Tail Control Test

8
WATCH OUT! Be sure to keep everything clear of the
propeller before starting the control test, in the event
that you accidentally turn on the motor.
1. Switch on the transmitter. Check the LED. Do not
touch the sticks for 2 seconds while the transmitter
automatically calibrates the controls.
2. Install the battery in the fuselage slot and plug in
the connector. Do not arm the motor.
3. Move the right stick side to side. The flaps should
move as on the following page. If each flap is not
level with the rest of the tail surface when the
right stick is centered, adjust the control lines so
they are level (see page 10).
Tail Control Test continued
View from Rear
Moves Up
View from Rear
Moves Up
9
