Explanation of icons

Symbol Description
Correct
Wrong
Press
Do not press
Turn
Switch
Switch off machine
Switch on machine
ENTER
ENTER (enter the menu)
ENTER
NAVIGATION
NAVIGATION (Navigating in the menu)
EXIT
EXIT (Exit the menu)
Time display (example: wait 4s/press)
4 s
Interruption in the menu display (other setting options possible)
Tool not required/do not use
Tool required/use
