EWM Phoenix 351-551 Operating Instructions Manual page 19

Item Symbol
1
2 VRD
3
4
5
6
7
8
9
10
11
12
099-005325-EW501
05.12.2014
Machine description – quick overview
Description 0
Lifting lug
Voltage reduction device (VRD)
The VRD signal light is illuminated, when the voltage reduction device is operating
without fault and the output voltage is reduced to a value specified in the relevant
standard- See 8 Technical data chapter. The voltage reduction device is only active on
VRD machine versions.
Ready for operation signal light
Signal light on when the machine is switched on and ready for operation
Main switch, machine on/off
Carrying handle
Cooling air inlet
Wheels, guide castors
Coolant tank
Coolant tank cap
Automatic cut-out of coolant pump key button
press to reset a triggered fuse
Connection socket, "-" welding current
Connection socket, "+" welding current
Front view
19
