Lexmark™ C910 Quick Reference Topic Printer menu overview Using the operator panel Understanding printer messages 6 Loading paper Locating and clearing paper jams 17 www.lexmark.com Page... - Page 2 Comments about this publication may be addressed to Lexmark International, Inc., Department F95/032-2, 740 West New Circle Road, Lexington, Kentucky 40550, U.S.A. In the United Kingdom and Eire, send to Lexmark International Ltd., Marketing and Services Department, Westhorpe House, Westhorpe, Marlow Bucks SL7 3RQ. Lexmark may use or distribute any of the information you supply in any way it believes appropriate without incurring any obligation to you.
-
Page 3: Printer Menu Overview
Printer menu overview Finishing Menu Duplex Duplex Bind Copies Blank Pages Collation Separator Sheets Separator Source Multipage Print Multipage Order Multipage View Multipage Border Network Menu PCL SmartSwitch PS SmartSwitch MAC Binary PS NPA Mode Network Buffer Job Buffering Network <x> Setup... -
Page 4: Using The Operator Panel
Scroll through menus or values. Increase or decrease a numerical value. Display the Job Menu or the Supplies Menu while the printer is busy. Select Select the item on the second line of the display. Save the selection as a new default setting. -
Page 5: Printing A Menu Settings Page
Select settings page prints. If you want to print a job that is personal or confidential, and you do not want anyone else to see it, the printer can hold your job in memory until you arrive at the printer. - Page 6 Note: Confidential printing only works with Lexmark C910 custom printer drivers. These drivers are located on the drivers CD that shipped with your printer and on the Web at www.lexmark.com. Note: If you send a large file to a shared network printer, it remains in the printer memory until you print it.
- Page 7 Menu see the job you want to print, and then press Select Press job to the printer. After the job prints, it is deleted from printer memory and the printer returns to the Ready state. until you to send the...
-
Page 8: Understanding Printer Messages
Understanding printer messages The following table lists some typical operator panel messages you may encounter and the action you can take to clear them. For more information on these or other printer messages, refer to the Lexmark C910 Publications CD. Message 37 Insufficient Memory The printer memory isn’t... - Page 9 Toner Empty and Open Cover Replace <color> messages. You must replace the toner cartridge to continue printing. Turn the printer off and check all cable connections. Turn the printer back on. If the service message recurs, call for service and report the message...
-
Page 10: Loading Paper
• Letter, A4 (60–105 g/m • 11x17, Legal, B4, A3 (60 - 90 g/m Lexmark Transparency Letter (P/N Lexmark Glossy Paper is 120 g/m Lexmark Transparency weight is 120 g/m Your printer supports a wide variety of paper types, sizes, and weights. - Page 11 • Cardstock: Letter, A4 (128–163 g/m • Paper Labels: Letter, A4 (up to 180 g/m Letter, A4 (105 - 128 g/m Lexmark Glossy Paper is 120 g/m Lexmark Transparency weight is 120 g/m Loading a 550-sheet tray Note: If you are loading an...
- Page 12 The position of the left paper guide tells the printer the size of the paper in the tray. Release the paper guide. Flex the sheets back and forth to loosen them, and then fan them.
-
Page 13: Loading The Multipurpose Feeder
Loading the multipurpose feeder Warning! Feeding more than a single sheet of glossy paper may damage the fuser. Squeeze the front paper guide lever and slide the guide until it lightly touches the stack of paper. Rotate the paper size dial until you see the correct size of paper indicated in the window. - Page 14 Open and extend the multipurpose feeder. Slide the paper guides to the correct position for the size paper you are loading. Press the paper feed plate down until it locks into place. Flex the sheets back and forth to loosen them, and then fan them.
-
Page 15: Loading The High Capacity Feeder
Loading the high capacity feeder Note: Load only plain paper in the high capacity feeder. Place the paper print side up between the paper guides. Move the SET button to the left to unlock the tray. You can load up to 3,000 sheets of plain paper in the optional high capacity feeder. - Page 16 Open the high capacity feeder top cover. Check the position of the paper guides. If the paper guide arrows are correctly aligned to the size paper you are loading, go to step 6 on page 15. If not, continue with step 3 on page 14. Loosen the left and right paper guide thumbscrews.
- Page 17 If there is only a Note: partial stack of paper in the tray, the paper low sensor will not allow the tray to go down. Add more paper to lower the tray. Flex the sheets back and forth to loosen them, and then fan them.
- Page 18 Close the top cover.
-
Page 19: Locating And Clearing Paper Jams
Locating and clearing paper jams 200 Paper Jam Check Areas A,B 200 Paper Jam Check Area D 241 Paper Jam 242 Paper Jam 243 Paper Jam 244 Paper Jam Paper source 200 Paper Jam <x> Pages Jammed (Check Areas A–F, T1–5, MPF) 240 Paper Jam Check MP Feeder 241–244 Paper Jam Check Tray 1–4 249 Paper Jam Check Tray 5... - Page 20 200 Paper Jam <x> Pages Jammed (Check Areas A–F, T1–5, MPF) Jam message Check Areas A, B Check Area C Check Area D Check Area E Check Area F Check MPF – Check T1 Check T5 Check Areas A, B This message identifies the areas ( –...
- Page 21 Lifting points Right top cover latch and lifting point Rotate the top cover locking lever to the left. Place both hands on the lifting points and squeeze the right top cover latch. Lift the cover.
- Page 22 Warning! Do not use pointed objects to remove the paper. They may damage the transfer belt. Note: The paper may be covered with unfused toner, which can stain garments. Transfer belt Transfer belt Release lever Remove any paper on the transfer belt. If the paper source was the multipurpose feeder, check the area between...
- Page 23 Note: The top cover will not close until the lever is in the down position. Slowly pull the paper out of the fuser toward the inside of the printer. Rotate the fuser pressure release lever down. Check the top cover for additional jams.
- Page 24 Rotate the top cover locking lever to the right. If you cannot rotate the locking lever, the cover is not fully closed. Open the jam access door on the left side of the printer. Remove any paper inside the printer.
- Page 25 Close the jam access door. To prevent additional paper jams, make sure both sides of the door are closed. Close the front door. Press Go. If the paper jam message continues, check and clear all paper from the paper path.
- Page 26 To clear area C: Open the duplex jam access door on the right side of the printer. Remove the jam. Press Go. If the paper jam message continues, check and clear all paper from the paper path.
- Page 27 Gently pull out the duplex unit. Turn the paper forwarding dial counterclockwise. If the paper advances out of the duplex unit, remove the jam and go to step 7 on page 26. If the paper does not advance, go to step 4 on page 25. Open the duplex unit covers.
- Page 28 Close the duplex unit covers. Push the duplex unit in until it stops. Close the duplex jam access door. Press Go. If the paper jam message continues, check and clear all paper from the paper path.
- Page 29 Check Area E Note: If you have a high capacity feeder, pull the feeder away from the printer. This message indicates a paper jam in the top, middle, or bottom optional drawer paper path area. To clear area E: Open the jam access door on the top optional drawer.
- Page 30 Remove the jam. Close the jam access door. Open the jam access door on the bottom optional drawer. Remove the jam. Close the jam access door. Press Go. If the paper jam message continues, check and clear all paper from the paper path.
- Page 31 Check Area F Pull the high capacity feeder away from the printer. Open the jam access door on the top optional drawer. Remove any jam. Close the jam access door.
-
Page 32: Paper Jam Check Mp Feeder
240 Paper Jam Check MP Feeder Slide the high capacity feeder until the feeder locks to the docking frame. When the feeder is in the correct position, you hear a click. Press Go. If the paper jam message continues, check and clear all paper from the paper path. - Page 33 Lifting points Right top cover latch and lifting point Rotate the top cover locking lever to the left. Place both hands on the lifting points and squeeze the right top cover latch. Lift the cover.
- Page 34 Warning! Do not use pointed objects to remove the paper. They may damage the transfer belt. Transfer belt Remove the paper on the transfer belt. Place both your hands on the top cover as shown. Press down firmly until the top cover clicks into place.
- Page 35 To remove the jam: If you have a high capacity feeder, pull the feeder away from the printer. Open the jam access door for the paper tray indicated on the display. Remove the jam. Close the jam access door.
- Page 36 Pull out the paper tray indicated on the display. Remove any wrinkled or creased paper. Push down on the remaining paper in the tray until the bottom plate clicks into place. Close the paper tray. Press Go. If the paper jam message continues, check and clear all paper from the paper path.
- Page 37 249 Paper Jam Check Tray 5 Note: If you have an optional printer cabinet, the high capacity feeder will be identified as tray 3. 249 Paper Jam Check Tray 5 message indicates a jam in the high capacity feeder. To remove...
- Page 38 P/N 12N0423 E.C. 2N0016 October 2001 Lexmark and Lexmark with diamond design are trademarks of Lexmark International, Inc., registered in the United States and/or other countries. © 2001 Lexmark International, Inc. 740 West New Circle Road Lexington, Kentucky 40550 www.lexmark.com...
