Lexmark C910 Setup Manual

Lexmark c910: setup guide
Hide thumbs Also See for C910:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Service Manual, Reference Manual
C910
Setup Guide
October 2001
www.lexmark.com

Advertisement

Table of Contents
loading

Related Manuals for Lexmark C910

Summary of Contents for Lexmark C910

  • Page 1 C910 Setup Guide October 2001 www.lexmark.com...

  • Page 2: Fcc Emissions Information

    FCC emissions information The Lexmark ABC has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

  • Page 3: Table Of Contents

    Introduction ........v About your printer ........v Other sources of information .
  • Page 4 Step 8: Verify printer setup ......67 Turning on the printer .......67 Printing a menu settings page .

  • Page 5: Introduction

    • Lexmark C910dn, a network model with duplexing capabilities. To customize your Lexmark C910 printer you can purchase a variety of input options including a high-capacity feeder. If you purchased your printer as part of a multifunction device, refer to the...

  • Page 6: Other Sources Of Information

    It also provides general information for administrators. The information on the CD is also available on the Lexmark Web site at www.lexmark.com/publications. Quick Reference The Quick Reference provides easy access to information about loading print...

  • Page 7: Step 1: Unpack Your Printer

    • Four toner cartridges • Four photodevelopers • Setup Guide • Lexmark C910 Publications CD • Quick Reference and sleeve • Drivers CD If any items are missing or damaged, refer to the publications CD for the designated Lexmark support phone number for your country.
  • Page 8 Familiarize yourself with the names and locations of items on the front and rear of Operator panel your new printer. This will help you during printer setup. We use the same terms throughout this book and on the publications CD.

  • Page 9: Step 2: Select A Location For Your Printer

    Choosing the correct location for your new Lexmark C910 is vital to ensuring the printer provides you with the quality of service you expect. Consider these factors when selecting a place to set up your printer: •...

  • Page 10: Allowing Enough Space

    (46.5 in.) (13 in.) When choosing a place to set up your printer, be sure to allow enough space for the printer and any options you may have purchased. It’s also important to allow space for proper ventilation around the printer.
  • Page 11 (6 in.) 1355.8 mm 329.5 mm (53.5 in.) (13 in.) The network and internet models are configured with two 550-sheet drawers. Make sure you have at least the amount of space indicated in the figure. Select a location for your printer...
  • Page 12 Duplex network printers 102 mm (5 in.) 1241.8 mm (56 in.) 508 mm (26 in.) Select a location for your printer 869.2 mm (34.3 in.) 329.5 mm (13 in.) 1355.8 mm 329.5 mm (53.5 in.) (13 in.) The duplex network printer is configured with two 550-sheet drawers and an internal duplex unit.
  • Page 13 329.5 mm (70.4 in.) (13 in.) You can add a high-capacity feeder to your printer if you have a printer cabinet or if you have a printer stand with optional drawers. When attaching a high-capacity feeder, make sure you provide the additional space indicated in the figure.

  • Page 14: Step 3: Set Up The Printer And Paper Handling Options

    Note: Be sure to set up the items in the order listed in the table. Set up the printer and paper handling options Use the following table to locate the instructions you need to set up your printer and any paper handling options you may have purchased.

  • Page 15: Installing The Printer Base Or Cabinet

    Installing the printer base or cabinet Set up the printer and paper handling options You can purchase an optional printer cabinet or printer base. The instructions for installing the printer cabinet or printer base are the same. To install the printer cabinet: Remove the printer cabinet from the box.

  • Page 16: Installing A 550-Sheet Drawer

    Set up the printer and paper handling options Installing a 550-sheet drawer Your printer supports a total of up to three optional 550-sheet drawers. Unpack the 550-sheet drawer and remove any packing material. Place the 550-sheet drawer on the optional printer cabinet, optional printer base, or in the location you have chosen for your printer.

  • Page 17: Positioning The Printer

    Anytime you move or lift the printer make sure you have enough people to help you. Use the handholds on the side of the printer when lifting. Once you have selected a location and set up any optional 550-sheet drawers, you are ready to position the printer.

  • Page 18: Installing An Optional Duplex Unit

    Installing an optional Set up the printer and paper handling options Your printer supports an optional duplex duplex unit unit that provides two-sided printing. To install the duplex unit: Have three other people help you place the printer in the location you have chosen.
  • Page 19 Open the duplex unit access door on the left side of the printer. Align the duplex unit with the slots in the printer. Slide in the duplex unit. Set up the printer and paper handling options...
  • Page 20 Set up the printer and paper handling options Align the thumbscrews on the duplex unit with the holes in the printer. Tighten the thumbscrews . Close the duplex unit door.

  • Page 21: Installing An Optional High-Capacity Feeder

    — Eight height adjustment Four docking frame screws — Wrench If any items are missing or damaged, refer to the publications CD for the designated Lexmark support phone number for your country. Wrench Set up the printer and paper handling options spacers...
  • Page 22 Attaching the docking frame Set up the printer and paper handling options Make sure the printer power switch is in the Off position. Remove the two side covers from the top 550-sheet drawer. You may need to use a small flathead screwdriver to pry the covers up and outward.
  • Page 23 Insert two screws through the bottom screw holes of the docking frame and into the holes in the printer cabinet or printer base. Tighten the screws. Place the wrench in the holder on the high-capacity feeder. Set up the printer and paper handling options...
  • Page 24 Note: Make sure all four casters are on the guide rail. Set up the printer and paper handling options Attaching the guide rail and feeder Align the two holes on guide rail with the studs on the docking frame. Slide the guide rail down until it is fully seated on the docking rail.
  • Page 25 21. Roll the high-capacity feeder toward the printer until the feeder locks to the docking frame. When the feeder is in the correct position, you hear a click when it locks. Set up the printer and paper handling options...
  • Page 26 CAUTION! capacity feeder power cord at this time. Set up the printer and paper handling options Do not install the high- Attach the interface cable to the back of the printer and tighten the thumbscrews. Attach the interface cable to the side of the high-capacity feeder and tighten the thumbscrews.
  • Page 27 Installing height adjustment spacers Set up the printer and paper handling options Insert the point on the cable holder into the hole on the back of the top optional drawer. Place the high-capacity feeder cable into the holder. Close the cable holder.
  • Page 28 Set up the printer and paper handling options Place the high-capacity feeder on the floor or adequate work surface. Remove the four screws securing one of the casters to the high- capacity feeder. Add or remove spacers. To add spacers: Insert the four screws through the caster.

  • Page 29: Attaching The Paper Tray Labels

    Use the labels to indicate the tray number and help identify paper jams and change paper tray menu options. Refer to the illustrations to determine where to place the tray numbers for your printer configuration. Set up the printer and paper handling options...

  • Page 30: Step 4: Install Memory And Option Cards

    CAUTION! or option cards after initial printer setup, turn the printer off and unplug the power cord. If you have any other devices connected to the printer, turn them off as well and unplug any cables going to the printer.
  • Page 31 Screws Screws Install memory and option cards Loosen the eight screws on the system board cover. Do not remove the screws completely. Slide the cover up and away from the printer.
  • Page 32 Memory and flash memory card connectors Optional ImageQuick firmware card Optional hard disk Install memory and option cards Option card connector Parallel connector Ethernet connector connector Option card cover To install a... Memory card Firmware card Hard disk Option card Use the illustration to locate the connector for the card you want to install.

  • Page 33: Installing A Memory Card

    Installing a memory card Note: Memory options designed for other Lexmark printers may not work with your printer. Warning! Printer memory and flash memory cards are easily damaged by static electricity. Touch something metal such as the printer frame before you touch a memory card.

  • Page 34: Installing A Firmware Card

    Installing a Follow the instructions in this section to firmware card install a firmware card. If you have a Lexmark C910in, an ImageQuick™ firmware card is already installed. If an option card has been installed, you need to remove the option card before installing the firmware card.
  • Page 35 Warning! Firmware cards are easily damaged by static electricity. Touch something metal such as the printer frame before you touch a card. Alignment pins System board holes Unpack the firmware card. Avoid touching the metal pins on the bottom of the card. Save the packaging.

  • Page 36: Installing A Hard Disk

    Installing a hard disk Warning! damaged by static electricity. Touch something metal such as the printer frame before you touch the hard disk. Install memory and option cards Hard disks are easily Follow the instructions in this section to install an optional hard disk.

  • Page 37: Installing An Option Card

    Installing an option card Function Adds an Ethernet or Token-Ring port to connect your printer to a network. Install a MarkNet N2501e or N2401e internal print server if you received either of these cards as part of a multifunction printer upgrade.
  • Page 38 Note: The Lexmark C910n and Lexmark ABCdn printers ship with an Ethernet print server already installed. Warning! damaged by static electricity. Touch something metal such as the printer frame before you touch an option card. Install memory and option cards...
  • Page 39 Align the connector on the option card with the connector on the system board. The cable connectors on the side of the option card must fit through the connector slot. Push the option card firmly into the option card connector. Secure the card to the system board with the screws.

  • Page 40: Reinstalling The System Board Access Cover

    Screw slot Install memory and option cards After you have finished installing cards on the printer system board, you must reinstall the system board access cover. Align the holes on the access cover with the screws on the printer as shown.

  • Page 41: Step 5: Attach Cables

    Step 5: Attach cables Network printing The Lexmark C910 can be attached to a network or locally (directly to a computer). You can attach your printer to a network using standard network cables. A 10BaseT/100BaseTX Fast Ethernet port is standard on the Lexmark C910n and Lexmark ABCdn.

  • Page 42: Local Printing

    — Token-Ring networks (Shielded Twisted Pair) use a DB9 connector — Ethernet 10Base2 networks (Thin Coax) use a BNC T-connector The printer automatically adjusts itself for the network speed. You can attach your printer locally using either a USB port or a parallel port.
  • Page 43 If you install an optional USB/Parallel Interface Card to the Lexmark C910n or Lexmark ABCdn, you need a 1284 A-C parallel cable such as Lexmark part number 43H5171 (9.8 ft), or a USB cable such as Lexmark part number 12A2405 (2 m).

  • Page 44: Step 6: Install Printer Supplies

    Step 6: Install printer supplies Opening the top cover Install printer supplies To access the Lexmark C910 printer supplies you must open the top cover. To open the top cover: Remove any shipping tape and packing material from the front of the printer.
  • Page 45 Right top cover latch Rotate the top cover locking lever to the left. Place both hands on the lifting points and squeeze the right top cover latch. Install printer supplies...
  • Page 46 Install printer supplies Lift the top cover until it stops. Remove any shipping tape and yellow packing material from inside the printer.

  • Page 47: Installing The Photodevelopers

    Touching the surface of the transfer belt or placing items on it may damage it. Transfer belt Your printer ships with four color-coded photodevelopers which you must place inside the top cover . Each photodeveloper has its own color-coded position inside the printer.
  • Page 48 Do not touch the glass. Touching the glass may damage it and reduce print quality. Do not remove the cover until you begin installing the photodeveloper. Align the photodeveloper with the slot in the printer as shown.
  • Page 49 As the photodeveloper slides in, remove the photodeveloper cover. Repeat steps 3 through 6 to install the remaining photodevelopers. Install printer supplies...

  • Page 50: Installing The Toner Cartridges

    Starter toner cartridges have a yield of up to 8,000 pages. You must install the toner cartridges inside the top cover of the printer. Each cartridge has its own color-coded position. Remove one of the toner cartridges from its packing material.
  • Page 51 Colored label Remove the shipping tape and any additional packing material. Align the toner cartridge with its slot in the printer. The toner cartridge is placed to the right of the corresponding colored label. Install printer supplies...
  • Page 52 Install printer supplies Slide the toner cartridge in until the cartridge is fully seated. Push the waste toner arm onto the photodeveloper until it snaps into place. Repeat steps 2 through 6 to install the remaining toner cartridges.

  • Page 53: Attaching The Quick Reference Booklet Sleeve

    Attaching the Quick Reference booklet sleeve The adhesive sleeve that came with your printer is a handy place to store your Quick Reference. Remove the protective paper from the back of the Quick Reference pouch. Firmly press the adhesive-backed sleeve onto the area inside the front door.

  • Page 54: Attaching An Adhesive Operator Panel Overlay

    If English is not your preferred language attach the overlay that has the appropriately translated button names: Locate the adhesive overlay packaged with your printer. Peel the backing off the overlay. Align the holes in the overlay with the buttons on the operator panel, and then press it into place.

  • Page 55: Closing The Top Cover

    Before closing the top cover, make sure the area under the cover is free of hands, clothing, and other items. Place both hands on the top cover as shown. Press down firmly until the top cover clicks into place. Install printer supplies...
  • Page 56 Install printer supplies Rotate the top cover locking lever to the right. If you cannot rotate the locking lever, the cover is not fully closed. Place both hands on the lifting points and squeeze the right top cover latch. Lift the top cover.

  • Page 57: Step 7: Load Paper

    Step 7: Load paper Source Paper sizes Tray 1 Letter, A4, Legal, Tabloid A3, B4 Trays 2-4 Letter, A4, Legal, Tabloid, A3, B4, Universal Heavy media Letter, A4, Legal, Tabloid tray A3, Universal Multipurpose Letter, A4, A5, Legal, feeder Tabloid , A3, Executive, B4, JIS B5, Universal 7¾, 9, 10, DL, C4, C5, B5,...

  • Page 58: Loading The Paper Trays

    • Lexmark Glossy Paper • Cardstock: Letter, A4 (128–163 g/m • Paper Labels: Letter, A4 (up to 180 g/m Letter, A4 (105–128 g/m Lexmark Glossy Paper is 120 g/m Lexmark Transparency weight is 120 g/m Loading the paper trays Note:...
  • Page 59 Pull the paper tray out until it stops. Press the metal plate down until it locks. Load paper...
  • Page 60 Note: The position of the left paper guide tells the printer the size of the paper in the tray. If the left paper guide is in the wrong position, you may experience paper feeding problems or incorrect page formatting. Load paper...
  • Page 61 Note: Do not exceed the maximum stack height. Overfilling the tray may cause jams. Place the paper in the tray, print side down. Squeeze the front paper guide lever and slide the guide until it lightly touches the stack of paper. Load paper...
  • Page 62 Load paper Rotate the paper size dial until the size of the paper in the tray is indicated. Push the tray completely in the printer.
  • Page 63 Using the heavy media tray Note: Using the heavy media tray with lighter weight paper such as 16–26 lb plain paper may cause jams. Note: For more information about using the operator panel and changing menu settings, refer to the publications CD. PAPER MENU PAPER SIZE Return...

  • Page 64: Set The Paper Type

    PAPER MENU PAPER TYPE Menu Tray 1 Type Custom Type 1 Menu PAPER MENU PAPER TYPE Menu Load paper Return Select Stop Return Select Stop Return Select Stop Set the paper type Press Return once. Paper Menu appears on the first line and Paper Size appears on the second line.

  • Page 65: Loading The Multipurpose Feeder

    Manual bypass feeder—Send a print job to the feeder while specifying the type and size of media from your computer. The printer then prompts you to load the appropriate print media before it prints. To load the multipurpose feeder: Open the multipurpose feeder.
  • Page 66 Note: The guides are interconnected, when you move one, they both move together. Load paper Slide the paper guides to the correct position for the size paper you are loading. Press the paper feed plate down until it locks into place.
  • Page 67 Note: Do not exceed the maximum stack height. Overfilling the feeder may cause jams. Flex the sheets back and forth to loosen them, and then fan them. Do not fold or crease the paper. Straighten the edges of the stack on a level surface.
  • Page 68 Move the SET button to the left to unlock the tray. The multipurpose tray can be closed by lifting it. Set button Load paper...

  • Page 69: Loading The High-Capacity Feeder

    Loading the high- capacity feeder Note: Do not load any print media other than paper in the high-capacity feeder. The optional high-capacity feeder provides an additional input of 3,000 sheets of paper. To load the high-capacity feeder: Open the high-capacity feeder top cover.
  • Page 70 Note: The high-capacity feeder must be properly adjusted for A4 or Letter size paper. If the paper guides are in the wrong position, you may experience paper feeding problems. Load paper Loosen the left and right paper guide thumbscrews. Slide the guides left or right to the correct position for the size paper you are loading (A4 or Letter).
  • Page 71 Note: Do not exceed the maximum stack height. Overfilling the tray may cause paper jams. Flex the sheets back and forth to loosen them, and then fan them. Do not fold or crease the paper. Straighten the edges of the stack on a level surface.
  • Page 72 Repeat step 8 and step 9 until you have filled the tray or loaded the desired quantity. Close the high-capacity feeder top cover. Make sure the high-capacity feeder is pushed completely against the printer.

  • Page 73: Step 8: Verify Printer Setup

    (GFI) circuit. Plug one end of the power cord into the socket on the side of the printer and the other end into a properly grounded outlet. Verify printer setup...

  • Page 74: Printing A Menu Settings Page

    Turn on the printer. If the printer is attached locally (directly to a computer), leave the computer and any other attached devices turned off. You will turn these on in a later step.

  • Page 75: Printing A Network Setup Page

    Select Menu Stop If the printer is attached to a network, print a network setup page to verify the network connection. This page also provides important information that helps you configure for network printing. Press Menu until you see Utilities Menu, and then press Select.

  • Page 76: Step 9: Configure For Tcp/Ip

    2. If your network is not using DHCP, you must manually assign an IP address to the printer. One of the easiest ways is to use the operator panel: Press Menu until you see Network Menu, and then press Select.

  • Page 77: Verifying The Ip Settings

    IP address: ping xxx.xxx.xxx.xx If the printer is active on the network, you will receive a reply. If your printer has an optional ImageQuick firmware card installed, it can be configured for Pull Printing once an IP address has been assigned.

  • Page 78: Network Printing

    Macintosh UNIX/Linux The following instructions explain how to install printer drivers on printers attached to a network. In Windows network environments, Lexmark printers can be configured for direct printing or for shared printing. Supported network printer ports • Microsoft IP port (Windows NT 4.0 and Windows 2000) •...
  • Page 79 You must create a printer object (icon) on the desktop of each network client using the LaserWriter 8 printer driver and the Lexmark C910 PPD file. Specific information about installing the printer on your AppleTalk network can be found in the online documentation on the drivers CD that shipped with your printer.
  • Page 80 NetWare Install printer drivers You can find a Lexmark PPD Installer in the downloadable Web package available on the Lexmark Web site at www.lexmark.com. Depending upon which version of the drivers CD shipped with your printer, you may also find this software on the drivers CD. Launch the Lexmark PPD Installer and follow the instructions to install the PPDs.

  • Page 81: Local Printing

    Non-NDPS (queue-based) For the latest information about Lexmark support for non-NDPS environments, click View Documentation on the drivers CD and look for information about network printer installation. Local printing In order to print, you must install a printer driver on the computer attached to the printer.
  • Page 82 Updated system and custom drivers are available on Lexmark’s Web site at www.lexmark.com. You must install the Lexmark C910 PPD and use it with the LaserWriter 8 printer driver or the Adobe PostScript driver. You can find the Lexmark C910 PPD and specific information about local printer installation on Macintosh computers on the drivers CD that shipped with your printer.

  • Page 83: Identifying Printer Users

    If you have a version of Acrobat capable of full text searching, we have created catalog entries to help you find the information you need. The type of helpful information provided on the Lexmark C910 Publications CD includes: •...

  • Page 84: Distributing The Information

    CD, and then click Navigation or Print as Book from the Home page. In addition to the Lexmark C910 Publications CD, your printer shipped with a Quick Reference. We recommend that you store this booklet in the convenient sleeve. The sleeve should be attached inside the front door of the printer.

  • Page 85: Statement Of Limited Warranty

    Lexmark C910 This Statement of Limited Warranty applies to this product if it was originally purchased for your use, and not for resale, from Lexmark or a Lexmark remarketer, referred to in this statement as “Remarketer.” Warranty...
  • Page 86 Lexmark offers a variety of extended warranty programs that include an extension of technical support. For products no longer covered by a Lexmark warranty, technical support may only be available for a fee. We do not warrant uninterrupted or error-free operation of a product.
  • Page 87 This limitation of liability will not apply to claims by you for bodily injury or damage to real property or tangible personal property for which Lexmark is legally liable. In no event will Lexmark be liable for any lost profits, lost savings, incidental damage, or other economic consequential damages.
  • Page 88 Statement of limited warranty...

  • Page 89: Index

    48 option cards 31 parallel cable 37 print server 31 Quick Reference sleeve 47 RJ-45 connector 35 USB cable 37 base printer 4 bin 1 2 cables Ethernet 35, 36 parallel 37 power 67 Token-Ring 35, 36...
  • Page 90 31 introduction v IP address, setting 70 IP settings, verifying 71 labels paper tray 23 printing 51 Lexmark ABC Publications CD vi Lexmark Web site vi Linux 74 loading high capacity feeder 63 multipurpose feeder 59 paper trays 52...
  • Page 91 2 Tri-Port Adapter 31 turning on the printer 67 UNIX 74 unpacking high-capacity feeder 15 memory cards 27 option cards 32 printer 1 USB 37 USB/Parallel Interface Card 31 warranty 79 Web site, Lexmark vi Windows 72, 75, 76 Index...
  • Page 92 P/N 12N0401 E.C. 2N0016 Lexmark and Lexmark with diamond design are trademarks of Lexmark International, Inc., registered in the United States and/or other countries. © 2001 Lexmark International, Inc. 740 West New Circle Road Lexington, Kentucky 40550 www.lexmark.com...
