Operation Environment - Modecom MC-WR11 Quick Start Manual

Wireless router
Quality of Service (QoS) - WMM, WMM-PS
Auto wireless transmission channel select for optimal performance
Wireless access control (MAC address filter)
Advanced Wireless control:
Fragment Threshold / RTS Threshold / Beacon Interval
Preamble Type: Long / Short
IAPP - Roaming (802.11f)
Protection / Aggregation / Short GI / WLAN Partition
RF Output Power control
Multiple BSSID
Dynamic DNS:
DynDNS.org / TZO / 3322.org
NAT:
NAT/NAPT IP sharing / DMZ / Port Forwarding / Port Trigger / UPnP
QoS:
Yes - IP (single or range) Grant MIN or MAX bandwidth
Firewall protection:
Ping Access on WAN / IGMP Proxy / Web Server Access on WAN / IPsec/
PPTP/L2TP VNP pass through /
Src MAC or IP Filter / URL Filter / Dst IP and Port Filter /
DoS Prevention:
Whole System Flood: SYN, FIN, UDP, ICMP
Per-Source IP Flood: SYN, FIN, UDP, ICMP
TCP/UDP Port Scan (High/Low Sensitivity)
ICMP Smurf, IP Land, IP Spoof, IP TearDrop, PingOfDeath, TCP Scan, TCP
SynWithData, UDP Bomb, UDP EchoChargen
Source IP Blocking (Block for a specified time)
System Management:
Access Schedule / NTP support / FW Upgrade / Save/Load Config / Reboot /
User name and password management

1.2 Operation Environment

Dimensions: 202 (L) x 120 (W) x 31 (H)mm
Unit Weight: 324g
Power Input: 9V DC, 1A
Consumption: 13.5W(Max)
Storage Temperature: -40ºC ~70ºC
