TEMCO FIREPLACE PRODUCTS, Inc.
Installation Instructions for Low Profile, Front-Opening,
Models TLC42-4, TLC42-4I,TLC42-4MB, TFC42-4, TLC39-3, TLC39-3I, TFC39-3, TLC36-3,
TLC36-3I, TLC36-3MB, TFC36-3, A42L-4, A42F-4, A39L-3, A39F-3, A36L-3 and A36F-3
36" Louvered Heat Circulating Fireplace
If the information in this manual is not followed exactly, a fire or explosion may result
causing property damage, personal injury or loss of life.
−
Do not store or use gasoline or other flammable vapors and liquids in the vicinity
of this or any other appliance.
−
Installation and service must be performed by a qualified installer. Do not attempt
to install this fireplace yourself!
Wood-Burning Fireplaces
READ AND SAVE THESE INSTRUCTIONS
WARNING
FOR YOUR SAFETY
42" Flush Face Heat Circulating Fireplace
P.O. BOX 1349 Manchester, TN 37349
P.O. Box 1148 Perris, CA 92572
A subsidiary of Temtex Industries, Inc.
PRINTED IN USA
02/97
7N70359C
Advertisement
Table of Contents
Related Manuals for Temco TLC42-4
Summary of Contents for Temco TLC42-4
- Page 1 TEMCO FIREPLACE PRODUCTS, Inc. Installation Instructions for Low Profile, Front-Opening, Wood-Burning Fireplaces Models TLC42-4, TLC42-4I,TLC42-4MB, TFC42-4, TLC39-3, TLC39-3I, TFC39-3, TLC36-3, TLC36-3I, TLC36-3MB, TFC36-3, A42L-4, A42F-4, A39L-3, A39F-3, A36L-3 and A36F-3 READ AND SAVE THESE INSTRUCTIONS 36" Louvered Heat Circulating Fireplace 42"...
-
Page 2: Table Of Contents
All models are listed for use in residential construction in to operating your fireplace after installation. For you to real- the United States with a TEMCO double-wall 8" diameter ize all the advantages and use of the reliable service that air-cooled chimney and the components listed below. -
Page 3: Basic Rules
Flue support is required for every 6' of offset chimney. TEMCO parts will void the UL listing and the TEMCO c. Guy wire stabilizer is required for chimneys extending warranty. more than 6' above roof line. -
Page 4: Planning Ahead
PLANNING AHEAD CHOOSING THE LOCATION FOR Figure 1 YOUR FIREPLACE: Figure 1 shows some of the many ways your fireplace may be installed. Consider the traffic pattern in your room and the location of doors and windows. A corner location may be best where space is limited. -
Page 5: Outside Air Kit And Glass Door Accessories
OUTSIDE AIR KIT AND GLASS DOOR Figure 3 Use of the Plumb Bob ACCESSORIES A fireplace needs a steady supply of air in order to draw properly. Many houses and apartments which are well sealed lack sufficient air for normal operation. IN SUCH HOUSES, IT IS RECOMMENDED THAT A COMBUSTION AIR KIT BE INSTALLED. -
Page 6: Determining The R-Values
A hearth extension installed directly on the floor must be R = Thermal resistance K/T = C; 1/C = R a minimum of 16" x 52" and be constructed of materials Example: 3/4" Marble with 3/8" Micore with an R-factor equal to or greater than .80. If com- Determine the R value for each material used as follows: bustible materials are used to construct the hearth exten- Marble:K/T= 11/.75=14.66. -
Page 7: Fireplace Installation
FIREPLACE INSTALLATION This list of specific instructions will help you make certain header and framing may be installed as shown in figure 5 that every installation operation is done correctly. Complete or figure 7 according to the installer's preference. the installation steps in the sequence shown. The entire fireplace can be elevated above the floor to Local building codes should be consulted in all cases as to achieve a raised hearth effect. -
Page 8: Installing The Chimney
STEP 6. FRAMING CEILING AND ROOF OPENING Figure 11 Figure 12 SEE FIGURE 17 FOR INSTRUCTIONS IF THE FLUE-PIPE WILL BE OFFSET BELOW THE FIRST CEILING LEVEL. If you are not using elbows in this installation frame, the ceiling and roof openings are directly above one another in the locations you chose in the Planning Ahead section of this manual. -
Page 9: 10 Foot Rule Of Thumb
is 13'6"; four elbows (two pairs) is 21'. Figure 13 G. Elbows may be used directly off the top of the firebox and may be mounted with the return elbow directly on top of the offset elbow. H. A MINIMUM OF 1" AIR SPACE CLEARANCE MUST BE MAINTAINED FROM THE CHIMNEY PIPE AND ELBOWS TO ALL COMBUSTIBLES. - Page 10 5. See figure 17 for offset calculation: Locate the center support. point of the flue on the ceiling with a plumb bob as shown 6. When the flue penetrates the ceiling at a 30° angle, on page 5. The center of the correct location for the install firestop spacer 8230F.
-
Page 11: Chase Installations
other exterior wall in your home. STEP 11. INSTALLING FLASHING Place the flashing over the chimney pipe where it pene- 4. A metal cover made by a local sheet metal shop is re- trates the roof and mark the outline of the flashing on the quired to complete a chase installation. -
Page 12: Installing A Gas Line
The following steps are recommended to stop potential cold air problems. INSTALLING A GAS LINE All Temco fireplaces are designed to accept a 1/2" gas line INSULATION OF THE FIREPLACE ENCLOSURE for a decorative gas appliance complying with Z21.60 Stan-... -
Page 13: Mobile Home Installation
8203D termination cap are required to complete the in- elbows are used. stallation. 3. TEMCO glass doors, firestop thimble and model AlR-3B WARNING: Do not install a fireplace in a sleeping combustion air kit and BL-1 must be installed for mobile room of a mobile home. -
Page 14: Finishing Your Fireplace
There are a wide variety of finishing materials available for and stone are made of non-combustible materials before your TEMCO fireplace from formal wall treatments with using them on the face of the fireplace. Some of these prod- marble and mantels to rustic wood paneling, stone or brick. - Page 15 Figure 26 MANTEL PROJECTION Mantel legs may project along the radiation line as illustrated. 6" min. 2 5/8" 7" min. 3" 8" min. 3 1/2" 10" min. 4 3/8" 12" min. 5 1/4" Hearth Installa- Figure 27...
-
Page 16: How To Use
THIS FIREPLACE. 4. A TEMCO fireplace grate must be used in this fireplace. It is pre-installed at the factory as an integral part of the fireplace. 15. NEVER CLOSE ANY DAMPERS UNTIL YOU ARE CERTAIN THAT THERE ARE NO WARM EMBERS. -
Page 17: Replacement Parts
REPLACEMENT PARTS The following replacement parts are available from your TEMCO dealer. Part # Description Quantity 42" 39" 36" 1. Firescreen rod, straight 3T65864 3T65730 3T65648 2. Screws for screen rods 1A68188 1A68188 1A68188 3. Firescreen with rings 1T62197 1T66146 1T66146 4.
