- Page 1 71-8466-250 1/02 Lionel Rotary Snowplow Owner’s Manual...
-
Page 2: Table Of Contents
Lubricating the Pullmor motor armature Lubricating the front pulley Replacing the headlamp 10-11 Limited Warranty/Lionel Service The following Lionel marks may be used throughout this instruction manual and are protected under law. All rights reserved. Lionel ® , TrainMaster ®... -
Page 3: Transformer Operations
• Do not power your Rotary Snowplow with direct current (DC). Damage to sensitive electronic components may occur. Move ‘em out! • Get your Rotary Snowplow moving. Press the DIR button on your CAB-1 remote or Lionel transformer. This sequences the Lionel reverse unit to the next operating state. -
Page 4: Locking Your Rotary Snowplow Into A Single Operational State
Transformer operations Locking your Rotary Snowplow into a single operational state o select a single operational state for now “locked” into your chosen direction. your Lionel Rotary Snowplow (example: When you no longer want single-direction forward only), you can deactivate the operation, just slide the reverse unit control reverse unit’s sequencing function with the... - Page 5 Transformer operations Locking your Rotary Snowplow into a single operational state (continued) able 1 lists the sequence of directions switch. Refer to Figure 1 on page 4 for the that your Snowplow will go through, location of that switch. depending on the setting of the E unit...
-
Page 6: Using Your Rotary Snowplow's Magnetic Coupler
(see Figure 2 below) over the central Snowplow moves on. coil of a remote-control track section and Magnetic coupler on the back of your Rotary Snowplow Trigger plate Remote-control track section Figure 2. Trigger plate operation... -
Page 7: Maintaining And Servicing Your Rotary Snowplow
Maintaining and servicing your Rotary Snowplow Lubricating your Rotary Snowplow elp your Lionel Rotary Snowplow lead a do), and avoid getting grease or oil on the long and productive life on your rail- Rotary Snowplow’s wheels or your track. road by maintaining it properly. -
Page 8: Lubricating The Pullmor Motor Armature
2. Locate the Snowplow drive pulley on top of the motor at the rear of the locomotive. Refer to Figure 4. 3. Place two or three drops of Lionel oil at the base of the pulley to lubricate the motor shaft. 4. Replace the body shell, tightening the two cab mounting screws. -
Page 9: Lubricating The Front Pulley
Rotary Snowplow Lubricating the front pulley o keep your Rotary Snowplow operating properly, be sure to lubricate the front pulley axle after every six to eight hours of operation. Refer to Figure 5 for the location of this lubrica- tion point. -
Page 10: Replacing The Headlamp
Rotary Snowplow features an operating headlight. During the course of normal opera- tion, this lamp may require replacement. The lamp is Lionel part no. 610-8446-100, available from your authorized Lionel Dealer. Follow these steps and refer to Figure 6 on page 11 as you replace this lamp. - Page 11 Maintaining and servicing your Rotary Snowplow Replacing the headlamp (continued) Lens assembly Lionel part no. Front of electronics board 610-8446-100 2 pin connector Thread wires through hole 3. Pull wires out Snowblower housing 1. Remove connector 2. Pry white tabs open Figure 6.
-
Page 12: Limited Warranty/Lionel Service
Center, together with proof of original purchase above instructions carefully before returning any will, at the option of Lionel L.L.C., be repaired or merchandise for service. You may choose to have replaced, without charge for parts or labor. In the...
