71-4172-250
6/02
Lionel
Railroad Tugboat
Owner's Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Railroad Tugboat and is the answer not in the manual?

Questions and answers

Related Manuals for Lionel Railroad Tugboat

Summary of Contents for Lionel Railroad Tugboat

  • Page 1 71-4172-250 6/02 Lionel Railroad Tugboat Owner’s Manual...

  • Page 2: Table Of Contents

    Replacing the lamps 10-11 Limited Warranty/Lionel Service The following Lionel marks may be used throughout this instruction manual and are protected under law. All rights reserved. Lionel®, TrainMaster®, Odyssey®, RailSounds™, CrewTalk™, TowerCom™, DynaChuff™, StationSounds™, Pullmor®, ElectroCoupler™, Magne-Traction®, CAB-1 Remote Controller®,...

  • Page 3: Setting Up The Tugboat's Mast, Antenna, And Smoke Stack

    Setting up the Tugboat’s mast, antenna, and smoke stack s illustrated in Figure 1, carefully stand pilothouse. Refer to Figure 1. up the mast, then slide it through the Match the tabs on the bottom of the hole in the back of the upper deck until the smoke stack with the notches in the deck, mast rests in the hole in the lower deck.

  • Page 4: Installing The Lifeboat

    Installing the lifeboat lide the two wire davits through the holes in the top deck and into the holes in the lower deck. Lower the lifeboat into the cradle, inserting the lifeboat posts into the holes below. Refer to Figure 2. Be sure that the lifeboat post Note! with the tab is towards the...

  • Page 5: Powering The Tugboat

    Powering the tugboat he Railroad Tugboat was designed to Lionel Lock-On. Simply attach one wire to operate best at 12-18 volts (AC). There each of the AC POWER terminals and are two ways to supply power to this connect them to the power supply or accessory.
  • Page 6 Powering the tugboat (continued) To power you tugboat with batteries, The smoke unit will not operate Note! remove the screw from the deck of the boat when the tugboat is powered by as shown in Figure 5. Lift away the hatch to batteries.

  • Page 7: Connecting The Controller

    Connecting the controller he controller is used to operate the to expose a hole in the terminal sound unit and to blow the whistle. The post. Place the bare end of the four controller wires are connected to four wire into the post, then tighten thumbscrew terminals on the underside of the thumbscrew back down to the Tugboat.

  • Page 8: Adding Smoke Fluid

    Adding smoke fluid efore you operate the Tugboat, add four rotate the stack about an eighth of a turn, to eight drops of fluid to the smoke then lift it away. Add the fluid into the hole generator. To add smoke fluid, carefully in the circuit board as illustrated in Figure 7.

  • Page 9: Operating Your Tugboat

    Operating your Tugboat hrow the switch (disguised as the Press WHISTLE on the controller to blow Tugboat’s bitt) at the back of the the whistle. AC Power users, slide the SMOKE Tugboat to the right for transformer or UNIT switch to ON, and watch as smoke Lock-On power.

  • Page 10: Replacing The Lamps

    Tugboat deck. Unscrew the lamp and replace holder. Gently unscrew the lamp and replace it it with Lionel part no. 610-4172-300, then with Lionel part no. 610-4172-300, available replace the pilothouse.

  • Page 11: Replacing The Lamps

    Replacing the lamps (continued) Latch Figure 10. Pilot house lamp replacement...

  • Page 12: Limited Warranty/Lionel Service

    Center, together with proof of original purchase above instructions carefully before returning any will, at the option of Lionel L.L.C., be repaired or merchandise for service. You may choose to have replaced, without charge for parts or labor. In the...
