Ver. 5.0.0
XDS-3FL
OPERATION MANUAL
OPTIKA MICROSCOPES - ITALY
www.optikamicroscopes.com - info@optikamicroscopes.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XDS-3FL and is the answer not in the manual?

Questions and answers

Summary of Contents for Optika XDS-3FL

  • Page 1 Ver. 5.0.0 XDS-3FL OPERATION MANUAL OPTIKA MICROSCOPES - ITALY www.optikamicroscopes.com - info@optikamicroscopes.com...
  • Page 2: Table Of Contents

    CONTENTS SAFETY GUIDELINES.....................page 3 BEFORE USE......................page 4 1.0 NOMENCLATURE .....................page 6 2.0 ASSEMBLING ....................page 7 2.1 Assemble scheme ................page 7 2.2 Assemble steps ..................page 8 3.0 OPERATION .....................page 11 3.1 Illumination ...................page 13 3.2 Filter preventing board ................page 13 3.3 Centering bulb ..................page 14 3.4 View field diaphragm ................page 15 3.5 Select flourescence filter block ............page 15 4.0 GENERAL SPECIFICATION ................page 16...
  • Page 3: Safety Guidelines

    Please read this manual carefully before using the equipment. To ensure safe use, the user must read and follow all instructions in this manual. OPTIKA products are designed for safe use in normal operating conditions. The equipment and accessories described in the manual are manufactured and tested according to industry standards for safety instrumentation laboratory.
  • Page 4: Before Use

    BEFORE USE Connect the mains plug into the socket at the base Make sure, before you turn the illumination on, that the voltage selector is set to the mains voltage for your region. The power cord should be used only on network sockets equipped with adequate grounding. Contact a technician to check the state of your electrical system. If there is no need to install additional accessories, the instrument is now ready for use.
  • Page 5 BEFORE USE -Standard bulb: Fluorescence light: 100W mercury bulb Transmitted light: 6V30W halogen bulb (Philips) (11) Power supply: 90-240V wildly (12) Please use the plug provide our company. 2. Maintenance (1) Wipe the lens gently with a soft lens tissue. Carefully wipe off oil or fingerprints on the lens surfaces with tissue moistened with a little of 3:7 mixture of alcohol and ether or dimethy lbenzene.
  • Page 6: Nomenclature

    1.0 NOMENCLATURE Page 6...
  • Page 7: Assembling

    2.0 ASSEMBLING 2.1 Assembling scheme: Numbers denote the assembling order. -Before assembling, make sure there is no dust or dirt. Assemble carefully and do not scrap any part or touch the glass face. -During assembling, please be aware of no scratching and no touching on lenses. Page 7...
  • Page 8: Assemble Steps

    B1 3, then tight. (Fig.5) (5) Loose the screw cap 9 a little, and turn the remark block 8 to make the letter “B” point to operator, then tight 9. - XDS-3FL fluorescence microscope can only be equipped with 2pcs filter blocks. The standard is B1 and G1. Others for selection.
  • Page 9 2.0 ASSEMBLING 2-2-3 Set light source with mercury bulb (1) Loose screw 1 with M4 inner hexagon spanner. (Fig.9) (2) Insert the light source with mercury bulb 2 into fluorescence connector 3, and rotate 2 to make its upper plane 4 as horizontal, then tight the screw 1 with M4 spanner.
  • Page 10 2.0 ASSEMBLING 2-2-5 Connect power supply (1) Make sure that the main power supply and fluorescence power supply at “o” (OFF). (2) Connect one side the plug 1 to the connector 2 on light source with mercury bulb and lock the screo. (Fig. 12) (3) Use same way to connect other side of the plug 1 connector 3 fluorescence power supply.
  • Page 11: Operation

    3.0 OPERATION Page 11...
  • Page 12 3.0 OPERATION Page 12...
  • Page 13: Illumination

    3.0 OPERATION While using transmitted illumination, the operation way is the same as inverted biological microscope. Below is the operation way under reflected fluorescence illumination. 3-1 Illumination (1) After connect with main power supply, please set the switch 1 on fluorescence power supply at “_” (ON), then the indicator light.
  • Page 14: Centering Bulb

    3.0 OPERATION 3-3 Centering mercury bulb (1) Turn the nosepiece 1 to make blank hole into light-path. Take off nosepiece cap when it has. (Fig.18) Figure 18 (2) Pull filter exchanging pole 3 to the middle position for B1 observation. (3) Turn adjusting pole 3 for view field diaphragm by clock-wise to make the view field to largest.
  • Page 15: View Field Diaphragm

    3.0 OPERATION 3-4 View field diaphragm Field diaphragm limits the light beam diameter into condenser, therefore eliminates the surround light in order to enhance image contrast. When field diaphragm image is just at edge of field, objective can provide best performance and the image is clearest. (1) Turn adjusting pole 1 for view field diaphragm clock-wisely to open the view field diaphragm, otherwise to close.
  • Page 16: General Specification

    4.0 GENERAL SPECIFICATION Typology INVERTED RESEARCH MICROSCOPE Description Laboratory inverted microscope for research applications. Dye-cast frame, with high stability and ergonomy, for transmitted light and and reflected fluorescence observation. Illumination Transmitted Light: Light source type X-LED8 with white 8W LED; light intensity control using a knob on left side of the frame.
  • Page 17: Troubleshooting

    4.0 GENERAL SPECIFICATION Condenser LWD condenser, N.A. 0.30, working distance 72 mm. The condenser can be removed to extend the working distance up to 150 mm. Dimensions HEIGHT: 485 mm WIDTH: 300 mm DEPTH: 600 mm WEIGHT: 10 kg Accessories Interferential filter IF550, blu filter LBD.
  • Page 18 5.0 TROUBLESHOOTING 2. ELECTRICS (1) INDICATOR ON NO POWER SUPPLY CHECK THE CONNECTION OF POWER FLUORESCENCE SUPPLY POWER SUPPLY IS NOT THE FUSE IS BURNT OUT REPLACE FUSE (2) INDICATOR ON INCORRECT CONNECTION OF POWER CHECK THE CONNECTION FLUORESCENCE SUPPLY POWER SUPPLY LIGHT, DESTRUCTION OF POWER PLUG CHANGE A NEW ONE BUT BULB IS NOT LIGHT...
  • Page 19: Recycling And Recovery

    6.0 RECYCLING AND RECOVERY Art.13 Dlsg 25 july 2005 N°151. “According to directives 2002/95/EC, 2002/96/EC and 2003/108/EC relating to the reduction in the use of hazardous substances in electrical and electronic equipment and waste dispo- sal.” The basket symbol on equipment or on its box indicates that the product at the end of its useful life should be collected separately from other waste.
  • Page 20 Puig i Pidemunt, nº 28 1º 2ª - (Pol. Ind. Plà d’en Boet) 08302 MATARO (Barcelona) España Tel: +34 937.586.245 +34 937.414.529 New York Microscope Company Inc 100 Lauman Lane, Suite A, Hicksville, New York 11801, USA Tel.: 877.877.7274 - Fax: 516.801.2046 www.microscopeinternational.com - info@nyscopes.com OPTIKA MICROSCOPES - ITALY www.optikamicroscopes.com - info@optikamicroscopes.com...
