ImaxRC X200 Instruction Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
X200 Instruction
x200 Manual_EN.indd 1
12-12-5
11:32

Advertisement

loading
Need help?

Need help?

Do you have a question about the X200 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ImaxRC X200

Summary of Contents for ImaxRC X200

  • Page 1 X200 Instruction x200 Manual_EN.indd 1 12-12-5 11:32...
  • Page 2 Manual_EN.indd 2 12-12-5 11:32...
  • Page 3 X200 specific for your needs! x200 Manual_EN.indd 3 12-12-5 11:32...
  • Page 4 New Chager X200 Released www.imaxrc.com/X200 A whole new Multiple languages product definition customization A whole new product method definition method Touch Screen charger customization Touch Screen Operation 4.3 inch touch screen make the operation more convenient 4.3-inch screen 4.3 inch display screen 4.3 inch TFT display...
  • Page 5 · OS System www.imaxrc.com/X200 Type Current Cells Mode X200 support more Input / Output LiXX 1-6S Fast Charging than 6 type batteries Current NiXX 1-16S Balance charging LiPo / Lilon / LiFe / Charging 0.1-10A Pb 1-10S Charging NiMh / NiCd / Pb Discharging 0.1-3A...
  • Page 6 NiMH Battery,Single Nominal Voltage: 1.2V,Charge cut-off voltage 1.5V,- Discharge cut-off voltage 1.0V NiCd NiCd Battery,Single Nominal Voltage: 1.2V,Charge cut-off voltage 1.5V,- Discharge cut-off voltage 0.85V Pb Battery,Single Nominal Voltage: 2.0V,Charge cut-off voltage 2.5V,Dis- charge cut-off voltage1.72V x200 Manual_EN.indd 6 12-12-5 11:32...
  • Page 7 This function only for NiMH battery which same as The Charge mode. Cycle This function only for NiMH battery. On the basis of Users setting current for MiNH battery cycle charging and discharging.The Cycle times is 1-6. x200 Manual_EN.indd 7 12-12-5 11:32...
  • Page 8 X200 Fundamental Function www.imaxrc.com/X200 Touch Screen No:201230484397.8 DC IN No:201230484396.3 x200 Manual_EN.indd 8 12-12-5 11:32...
  • Page 9 Grooved design to prevent the misplug reduces time and effort.The anti-slip design increase friction force and make it more beautiful. IBP collection charge,balance,Signal transfer and temperature sense functions. x200 Manual_EN.indd 9 12-12-5 11:32...
  • Page 10 Manual_EN.indd 10 12-12-5 11:32...
  • Page 11 Preparing Connecting Using www.imaxrc.com/X200 x200 Manual_EN.indd 11 12-12-5 11:32...
  • Page 12 X200 is a professional RC model battery charger,please view the manual before using. If you are a fresh man please read this entire operating manual completely before using. 【Warning: 】The warning of charger operation and disclaimer, Please read and abide by the following terms before operation.
  • Page 13 Extras Including X200 included with 1pcs adapter board,1pcs connect cable and 1 pcs manual. X200 All in one Connect cable Manual Chapter 1 Preparing、Connecting、Using x200 Manual_EN.indd 13 12-12-5 11:32...
  • Page 14 Connecting X200 Please follow the below steps connecting: Please connecting the cable to the adapter port and the X200 DC IN port, and then plug the adapter power cord into the socket. Chapter 1 Preparing、Connecting、Using x200 Manual_EN.indd 14 12-12-5 11:32...
  • Page 15 Connecting the adapter board into the X200 IBP port. 【NOTE】 USB support 5V 2.1A charging voltage,and also use for iPad / iPod / iP- hone / HTC and other intelligent electronic equipment. Both the USB and All in one get charged simultaneously.
  • Page 16 Please make sure the port connect with battery（Other ports are same as it）. Chapter 1 Preparing、Connecting、Using x200 Manual_EN.indd 16 12-12-5 11:32...
  • Page 17 Sarting X200 startup X200 to enter the main interface ( Image 1 ). Image 1 Showing“Warning and Disclaimer” 2 seconds and will know the copyright and security information ( Image 2 ). It will be enter into the contacting interface if you can not agree with the disclaimer, and then you could contact the distributor return the charger ( Image 3 ) 5、...
  • Page 18 Present Setting Type Cells Battery Type: LiPo Mode: Balance Mode Current Cells: 2Cells 7.4V Current: Load Save Uset Shart C 2.0A D 1.0A Image 4 【NOTE】 Information bar can not get touched. Chapter 1 Preparing、Connecting、Using x200 Manual_EN.indd 18 12-12-5 11:32...
  • Page 19 Image 6 ) will Enter into main interface go on the next step. Present Setting Type Cells Battery Type: LiPo Mode: Balance Mode Current Cells: 2Cells 7.4V Current: Load Save Uset Shart C 2.0A D 1.0A Image 5 Image 6 Chapter 1 Preparing、Connecting、Using x200 Manual_EN.indd 19 12-12-5 11:32...
  • Page 20 There are six charge/discharge modes in Mode interface( Image 8 ), see iM.OS System function for further details. please set charge/discharge mode according to your requirement. Picture no.7 is showing Balance charge mode. Chapter 1 Preparing、Connecting、Using x200 Manual_EN.indd 20 12-12-5 11:32...
  • Page 21 Step 3: Touch Cells icon ( Image 9 ) to enter into Cells interface. Please set battery packs by sliding ( Image 10 ). Touch OK to go back to main interface and continue setting. Image 9 Image 10 【Note】Please set according to suitable battery packs. Chapter 1 Preparing、Connecting、Using x200 Manual_EN.indd 21 12-12-5 11:32...
  • Page 22 ( Image 12 ). Touch OK to go back to main interface and continue setting. Image 11 Image 12 【NOTE】 Set charge current in charge mode and discharge current in discharge mode. Chapter 1 Preparing、Connecting、Using x200 Manual_EN.indd 22 12-12-5 11:32...
  • Page 23 Save interface. Touch Unused icon to save the data and it will be easy for you to charge next time. ( Image 14 ) Image 13 Image 14 【NOTE】You could use this function after you have set Type/Mode/Cells and Current correctly. Chapter 1 Preparing、Connecting、Using x200 Manual_EN.indd 23 12-12-5 11:32...
  • Page 24 Step 6: You could load your previous data according to X200’s load function. Touch Load icon ( Image 15 ) to enter into Load interface. Choose the data you want to load ( Image 16 ). Image 15 Image 16 Chapter 1 Preparing、Connecting、Using...
  • Page 25 Step 7: Touch Start icon ( Image 17 ) to enter into Start interface. The system will check battery status automatically. If everything is OK, the charger will begin to charge.( Image 18 ) Image 17 Image 18 Chapter 1 Preparing、Connecting、Using x200 Manual_EN.indd 25 12-12-5 11:32...

  • Page 26: Table Of Contents

    4.20 4.20 0.00 0.00 0.00 Dalta V: 5.00 Image 19 【NOTE】 The charger will send out an alert and pop-up window if the battery packs’ setting is incorrect (Image 20). Image 20 Chapter 1 Preparing、Connecting、Using x200 Manual_EN.indd 26 12-12-5 11:32...
  • Page 27 ( Image 22 ). Present Setting Type Cells Battery Type: LiPo Mode: Balance Mode Current Cells: 2Cells 7.4V Current: Load Save Uset Shart C 2.0A D 1.0A Image 21 Image 22 Chapter 1 Preparing、Connecting、Using x200 Manual_EN.indd 27 12-12-5 11:32...
  • Page 28 There are four charge/discharge modes in Mode interface( Image 24 ), see iM.OS System function for further details. please set charge/discharge mode accord- ing to your requirement. Picture no.23 is showing charge mode. Chapter 1 Preparing、Connecting、Using x200 Manual_EN.indd 28 12-12-5 11:32...
  • Page 29 【NOTE】The battery cannot be charged if each pack of the battery voltage is less than 0.7V, please use the less battery packs to activate charging process. If you need lower voltage during discharging process, please use the less battery packs to discharge. Chapter 1 Preparing、Connecting、Using x200 Manual_EN.indd 29 12-12-5 11:32...
  • Page 30 Image 28 【NOTE】Please set charge current in charge mode and discharge current in dis- charge mode. As for Save and Load functions, please see Step5 and 6 in Example1 for further details. Chapter 1 Preparing、Connecting、Using x200 Manual_EN.indd 30 12-12-5 11:32...
  • Page 31 Step 5: touch Start icon ( Image 29 ) to enter into Start interface. The charger will check battery status automatically. If everything is OK, the charger will begin to charge ( Image 30 ). Image 29 Image 30 Chapter 1 Preparing、Connecting、Using x200 Manual_EN.indd 31 12-12-5 11:32...
  • Page 32 【NOTE】The charger will send out an alert and pop-up window if the battery packs’ setting is not correct. ( Image 31 ) All Lipo battery packs setting are the same operation. Image 31 Chapter 1 Preparing、Connecting、Using x200 Manual_EN.indd 32 12-12-5 11:32...

  • Page 33: Type

    33) to go back to main interface and continue setting. Present Setting Type Cells Battery Type: LiPo Mode: Balance Mode Current Cells: 2Cells 7.4V Current: Load Save Uset Shart C 2.0A D 1.0A Image 32 Image 33 Chapter 1 Preparing、Connecting、Using x200 Manual_EN.indd 33 12-12-5 11:32...

  • Page 34: Image 34

    35 ) to go back to main interface and continue setting. Image 34 Image 35 【NOTE】 There are some options in Mode interface ( Image 35 ). Please set accord- ing to your requirement. Picture no.31 is showing charge process. Chapter 1 Preparing、Connecting、Using x200 Manual_EN.indd 34 12-12-5 11:32...
  • Page 35 Step 3: touch Cells icon ( Image 36 ) to enter into Cells interface. Please set Pb battery packs by sliding ( Image 37 ). Touch OK to go back to main interface and continue setting. Image 36 Image 37 【NOTE】Pleasr set according to suitable battery packs. Chapter 1 Preparing、Connecting、Using x200 Manual_EN.indd 35 12-12-5 11:32...
  • Page 36 Image 38 Image 39 【NOTE】Set charge current in charge mode and discharge current in discharge mode. As for Save and Load functions, please see Step 5 and 6 in Example1 for further details. Chapter 1 Preparing、Connecting、Using x200 Manual_EN.indd 36 12-12-5 11:32...
  • Page 37 Step 5: touch Start icon ( Image 40 ) to enter into Start interface. The charger will check battery status automatically. If everything is OK, the charger will begin to charge. ( Image 41 ) Image 40 Image 41 Chapter 1 Preparing、Connecting、Using x200 Manual_EN.indd 37 12-12-5 11:32...
  • Page 38 【NOTE】The charger will send out an alert and pop-up window if the battery packs’ setting is incorrect. ( Image 43 ) All Lipo battery packs setting are the same operation. Image 43 Chapter 1 Preparing、Connecting、Using x200 Manual_EN.indd 38 12-12-5 11:32...
  • Page 39 X200 Experiments www.imaxrc.com/X200 x200 Manual_EN.indd 39 12-12-5 11:32...
  • Page 40 SYSTEM is bran-new software of charger which was Independently research and develop by iMaxRC. It is the first operation system in the world especially to support touch screen charger,and it’s going to be Industry standard for touch screen charger series.
  • Page 41 Time Input raturey Lixx Nixx Wasle Cycle Check Delta Time Times Time Peak Backlight Buzzer Language Level Back Image 47 Please find detailed list of features on next page. Chapter 2 Enjoy function of X200 x200 Manual_EN.indd 41 12-12-5 11:33...
  • Page 42 Rang of setting: 5-60mins. Time for checking cells count of LiPo battery pack. NixxDeltaPeak Nixx Delta Peak Rang of setting: 5-200mV. NiHm/NiCd Delta peak. Waste Time Wasle Time Spacing interval between 2 Cycles. Rang of setting: 1-60mins. Chapter 2 Enjoy function of X200 x200 Manual_EN.indd 42 12-12-5 11:33...
  • Page 43 2. when charging power reach 100W, fan speed will be one level up as charging power rise by each 5W. 3. Fan speed will be one level up as discharging power rise by each 2W. NOTE: Fan Speed of X200 charger will begin to change in any of above situation. Chapter 2 Enjoy function of X200 x200 Manual_EN.indd 43...
  • Page 44 Manual_EN.indd 44 12-12-5 11:33...
  • Page 45 IMPORTANT REMIND www.imaxrc.com/X200 x200 Manual_EN.indd 45 12-12-5 11:33...
  • Page 46 Please follow the instruction to operate your X200 charger, to insure safety of you and charger, and use it easily. Please keep manual within easy reach, to be easy reference for you and other user. 【NOTE】 Procedures, which if not properly followed, can result in potential nullification of any vendor warranties or liabilities.
  • Page 47 X200 charger from air-vent. This may lead inner surface of screen appear mist. Do not Maintain Yourself X200 charger not include any spare part for user to make the maintenance , never dis- mantle the product by yourselves. Please contact with IMAXRC authorized distributor for maintenance.
  • Page 48 All specifications and figures are subject to change without notice. Printed in China © 2012 x200 Manual_EN.indd 48 12-12-5 11:33...
