b6
b6
All specifications and figures are subject to change without
notice. Printed in China ©2010
10
10
b6
b6
10
10
Professional Balance Charger
Microprocessor controlled high-performance rapid charger/discharger with integrated
balancer USB PC link and temperature sensor
Charge current up to 10A,discharge current up to 5A,1 to 6 series of Lilo/LiFe,1 to 18
cells of NiCd/NiMH,2 to 24V of Lead-acid(Pb)
Instruction Manual
w w w . i m a x r c . c o m
Advertisement
Table of Contents
Related Manuals for ImaxRC B6 10 pro
Summary of Contents for ImaxRC B6 10 pro
- Page 1 Professional Balance Charger Microprocessor controlled high-performance rapid charger/discharger with integrated balancer USB PC link and temperature sensor Charge current up to 10A,discharge current up to 5A,1 to 6 series of Lilo/LiFe,1 to 18 cells of NiCd/NiMH,2 to 24V of Lead-acid(Pb) Instruction Manual All specifications and figures are subject to change without w w w .
-
Page 2: Special Features
- Individual voltage balancer for Lithium batteries B6 10 Pro has an individual cell voltage balancer inside.So it does not need any balancer - PC based analysis using USB communication(**) separately when charging Lithium batteries(Lilo/LiPo/LiFe)for voltage balancing. -
Page 3: Warnings And Safety Notes
Warnings and safety notes Warnings and safety notes Warnings and safety notes Do not attempt to charge or discharge the following types of battery. -Battery pack,which consists of different types of cell(including different manufactur- Never leave the charge unsupervised when it is connected to its power supply.If any ers). -
Page 4: Program Flow Chart
Warnings and safety notes Program flow chart Program flow chart the battery you also have to pay attention on the process same as charging.To avoid the battery becoming deep-discharged,set the final discharge voltage correctly.Lithium batteries should not be deep-discharged,set the final discharge voltage,as this leads to a rapid loss of capacity or a total failure.Generally,you do not need to discharge Lithium battery voluntarily. - Page 5 Initial parameter set up(Users set program) The battery is on the cyclic process of charge and discharge B6 10 Pro will be operated with the default value of the essential user settings when it can often become warm after charge or discharge period.The is connected to a 12V battery for the first time.The screen displays the following...
-
Page 6: Lithium Battery(Lilo/Lipo/Life)Program
Lithium battery(Lilo/LiPo/LiFe)program Lithium battery(Lilo/LiPo/LiFe)program Lithium battery(Lilo/LiPo/LiFe)program Charging Lithium battery at balance mode These programs are only suitable for charging and discharging Lithium batteries with a This is for balancing the voltages of Lithium batteries of the battery pack to be nominal voltage of 3.3v,3.6v and3.7v per cell.These batteries need to adopt different charged.To do this,the battery pack being charged should have the individual cell charge technique is termed constant voltage(CV) and constant current(CC) -
Page 7: 'Fast' Charging Lithium Battery
Lithium battery(Lilo/LiPo/LiFe)program Lithium battery(Lilo/LiPo/LiFe)program 'FAST' charging Lithium battery Discharging Lithium battery The charging current getting smaller as the process goes to the near end term of The value of discharge current on the left side of Lithium battery charging.To finish charging process earlier,this program eliminate screen may not exceed 1C for a maximum safety certain term of CV process.Actualy,the charging current will goes to 1/5 from the initial and the final voltage on the right should not be... - Page 8 NiMH/NiCd battery(Lilo/LiPo/LiFe)program NiMH/NiCd battery(Lilo/LiPo/LiFe)program Charge-to-discharge & discharge-to-charge cycle NiMH/HiCd battery These programs are for charging or discharging NiMH (Nickel-Metal-Hydride) or NiCd (Nickel-Cadmium) battery commonly used for R/C model applications.To alter the value at the display,press Start/Enter key to make it blink then change the value using INC> Set the sequence on the left and the number of NiMH CYCLE...
- Page 9 24v.Pb batteries are totally different from NiCd or NiMH batteries.They can only deliver relatively lower current compare to their capacity,and similar restrictions definitely B6 10 Pro has a data storage and load program for your convenience.This feature can apply to charge.So the optimal charge current will be 1/10 of the capacity.Pb batteries store up to 10 battery data by number that represent the individual specification of must not be charged rapidly.Always follow the instruction is supplied by the...
- Page 10 Load Data program Various information during the process Various information during the process This program calls back the data that was stored at 'Save Data'program. To load the data,press Star/Enter key once to blink the data number field and select the You can inquire various information on LCD screen during charging or discharging number using INC>...
- Page 11 Glossary of terms Glossary of terms B6 10 Pro incorporates a various functions of protective and monitoring the system to verify functions and the state of its electronics.In any case of occurring error,the screen displays the cause of error that is self-explanatory with audible sound.
- Page 12 Balancing the multi Lithium battery packs Maximum circuit power chart Balancing the multi Lithium battery packs Maximum circuit power chart You can charge and balance several Lithium batteries at the same time,by using For the voltage of battery is more than 20V,the actual amount of charge current optional'Muti-board adaptor'(*).Please note that the battery packs being charged should delivered to the battery might automatically be limited,so not to exceed the charge's have same capacity and cell-count.
-
Page 13: Specifications
Specifications/Warranty and service Specifications Operating voltage range: 10.0-18.0 Volt Circuit power: max.200Watts(charging) max.25Watts(discharging) Charge current range: 0.1-10.0A Discharge current range: 0.1-5.0A Current drain for balancing Lipo: 200mAh/cell NiCd/NiMH battery cell count: 1-18 cells Lithium battery cell count: 1-6 Series Pb battery voltage: 2 to 24V Weight: 480 g...
