Kilotech KLE 200 Owner's Manual

1. Introduction
Congratulations and thank you for purchasing a Kilotech KLE series scale. As with all
Kilotech quality products, proper care and maintenance must be adopted in order to keep
the scale at peek performance.
2. Description
The KLE economy series electronic scales are precision instruments, designed to
provide years of service with virtually no maintenance. The KLE contains a one piece solid-
state precision electronics PC board and a five digit LCD display which is 0.5 inches in
height. Power is supplied through an AC adapter (included) or batteries.
。Portable Advanced balances contain two display menus which enable you to calibrate
and configure the balance for specific operating requirements.
。CALIBRATION Menu–Allows the balance to be calibrated by using standard weights.
。SETUP Menu–allows the balance to be set for environmental conditions and customized
for specific weighing functions.
When the balance is first turned on, it can be used to weigh in grams tare items without
setting the menus. Refer to the individual menus in this manual for detailed descriptions and
procedures for programming.
3.Unpacking
Weighing
Platform
Display Window
All Portable Advanced balances are supplied with a weighing platform, some of which
have been installed, AC power adapter, instruction manual ,and certificate of quality.
4． ． ． ． Environment
Balance performance can be affected by excessive air currents, corrosives, vibration,
temperature or humidity extremes.
DO NOT use the scale:
•
Next to open windows or doors causing drafts or rapid temperature changes.
•
Near air conditioning or heat vents.
•
Near vibrating, rotating or reciprocating equipment.
•
On a non-level work surface.
•
Near corrosive vapors (example: nitric acid).
5． ． ． ． INSTALLATION
5.1 Power
5.1.1 The scale can be operated using 4 AA alkaline (not included), or the AC adapter
supplied.
5.1.2 AC adapter/Batteries
Plug the jack from the adapter into the receptacle located on the side of the scale. Plug
the adapter into a 110v AC outlet or install 4 AA alkaline batteries in holder under the scale.
5.2 Battery Installation
⑴ Turn the balance over.
⑵ Press the tabs on the battery cover inward and lift the cover off.
⑶ Remove the battery holder.
⑷
Install the 4AA alkaline battery in the battery holder, orienting the Plus (+) and minus
(-) ends as indicated on the holder.
AC Adapter
Receptacle
Calibration Menu Lockout Switch
Push Button
