- Page 1 StarEye led-unit 12 volt 350 mA Integrated dimmable step down convertor LUX LUMEN - Kernenergiestraat 53A - 2610 WILRIJK T: +32 3 293 35 50 – F: +32 3 293 35 44 www.lux-lumen.com...
-
Page 2: Table Of Contents
PPLICATION OF WARRANTY 9.2 RMA ................16 PROCEDURE 10 USED LIST OF ABBREVIATIONS .......... 17 StarEye spot dimmable p.2/17 LUX LUMEN - Kernenergiestraat 53A - 2610 WILRIJK T: +32 3 293 35 50 – F: +32 3 293 35 44 www.lux-lumen.com... -
Page 3: Picture
Picture 1.1 General StarEye spot dimmable p.3/17 LUX LUMEN - Kernenergiestraat 53A - 2610 WILRIJK T: +32 3 293 35 50 – F: +32 3 293 35 44 www.lux-lumen.com... -
Page 4: Dimensions
Dimensions StarEye spot dimmable p.4/17 LUX LUMEN - Kernenergiestraat 53A - 2610 WILRIJK T: +32 3 293 35 50 – F: +32 3 293 35 44 www.lux-lumen.com... -
Page 5: Safety Information
Safety information Before installing, powering up, or servicing the StarEye led-unit, it is highly recommended that you read this manual, and you ensure yourself that you completely understand its content. Observe the safety precautions in this manual. Install and operate the led-unit only as described in this manual, and in conformity with local regulations. -
Page 6: Protection From Electric Shock
Do not modify the led-fixture, in a way, not described in this manual. StarEye spot dimmable p.6/17 LUX LUMEN - Kernenergiestraat 53A - 2610 WILRIJK T: +32 3 293 35 50 – F: +32 3 293 35 44 www.lux-lumen.com... -
Page 7: Protection From Injury
StarEye spot dimmable p.7/17 LUX LUMEN - Kernenergiestraat 53A - 2610 WILRIJK T: +32 3 293 35 50 – F: +32 3 293 35 44 www.lux-lumen.com... -
Page 8: Physical Installation
This led-unit can be used in all directions. 4.3 Mounting Track mounting The StarEye can be equipped with a track adaptor in order to be installed easily on 12 V track systems. Surface mounting The StarEye led-unit can be mounted on all kind of non combustible materials, but take in consideration that the module can have a Tc of approx 30 °C higher as ambient temperature. -
Page 9: Adjusting Of Intensity
4.4 Adjusting of intensity At the back of the StarEye led-unit, you will find a small potentiometer, which allows to vary the light output of the fixture. This can be seen here: Use a flat screwdriver, width of 2 mm. -
Page 10: External Connections
Never connect the live power on the input terminals of the StarEye led-unit! In case of doubts, contact your point of sale. Polarity The StarEye led-unit is polarity sensitive. So observe polarity and cabling: • Inner conductor marked with 1 = positive • Inner conductor marked with 2 = negative Improper connection, might damage the StarEye led-unit and power supply permanently. -
Page 11: Emc And Safety Requirements
EMC and safety requirements The StarEye led-unit is fully compliant to the LVD and EMC directive of the European council, if used in a properly designed setup. EMC requirements of the power supply The StarEye led-unit is only intended to be used in lighting... -
Page 12: Installation Setup
Neutral white, 4000K CRI = 75, Efficacy 100 lm/watt o Cold white, 6500K CRI=75, Efficacy 130lm/watt The ingress protection of the StarEye led-unit is IP 20, and as such, the unit can only be used in indoor applications. The dimensions of the main led housing is a cylindrical aluminum lathed part of 35mm diameter with length of max. -
Page 13: Service And Maintenance
Never use solvents to clean the outer housing of the unit. Never use water, or wet cloth. StarEye spot dimmable p.13/17 LUX LUMEN - Kernenergiestraat 53A - 2610 WILRIJK T: +32 3 293 35 50 – F: +32 3 293 35 44 www.lux-lumen.com... -
Page 14: Warranty
Warranty service is valid for one year from the date of purchase by the consumer, as evidenced by invoice date given out by your point of sale. Warranty service Service under warranty can only be done by Lux Lumen. Coördinaties: Lux Lumen Kernenergiestraat 53 A... - Page 15 In the absence of applicable national legislation, this warranty will be the consumer’s sole and exclusive remedy, and Lux Lumen cannot be liable for any incidental or consequential damages for breach of any express or implied warranty of this product.
-
Page 16: Rma Procedure
9.2 RMA procedure To send material back to Lux Lumen, you need a RMA (Return Material Authorization) document that you will receive from Lux Lumen. Without the RMA document, we cannot accept the material. The procedure to obtain a RMA:... -
Page 17: Used List Of Abbreviations
• °F: Temperature in degrees Fahrenheit • °C: Temperature in degrees Celsius • LED: Light Emitting Diode StarEye spot dimmable p.17/17 LUX LUMEN - Kernenergiestraat 53A - 2610 WILRIJK T: +32 3 293 35 50 – F: +32 3 293 35 44 www.lux-lumen.com...
