VCS325SSBI Series and VCS525SSBI Series
Assembly Procedures
Tools Required: Knife or scissors, Phillips or Robertson (square head) screwdriver.
WARNING: Some parts may have sharp edges; to avoid injury, wearing gloves during assem-
bly, lifting or moving the grill is recommended. Protective eyewear and long sleeves are also
strongly recommended.
CAUTION: This grill is intended ONLY to be built into an enclosure.
Model VCS525SSBI Shown
CAUTION: The assembly of this grill requires two (2) people.
30007230 10/14 Rev. 1 En

Advertisement

loading

Summary of Contents for Vermont Castings Signature Series VCS325SSBI Series

  • Page 1 VCS325SSBI Series and VCS525SSBI Series Assembly Procedures Model VCS525SSBI Shown Tools Required: Knife or scissors, Phillips or Robertson (square head) screwdriver. WARNING: Some parts may have sharp edges; to avoid injury, wearing gloves during assem- bly, lifting or moving the grill is recommended. Protective eyewear and long sleeves are also strongly recommended.
  • Page 2 VCS325SSBI/525SSBI Series Assembly Step 1: Unpack Carton and Verify Contents Use a sharp cutting tool to cut the straps on the packaging and then lift off the carton top. The sleeve sur- rounding the barbecue can be removed by lifting it straight up and over the top of the unit. Compare all con- tents to the parts list and the carton content lists below.
  • Page 3 VCS325SSBI/525SSBI Series Assembly Step 1: Unpack Carton and Verify Contents (continued) Literature Bag VCS525SSBI Carton Contents Literature Bag ( 30007234 1. Grease Tray Assembly Instructions 2. Spit Rod Parts List 3. Front Grease Tray User’s Manual 4. Cook Grates (4) Battery “AA”...
  • Page 4 VCS325SSBI/525SSBI Series Assembly VCS325SSBI / VCS525SSBI Framing Dimensions When Using Noncombustible Materials Drain Holes (2" diameter) Drain Holes (2" diameter) B332a Ref. VCS325SSBI VCS525SSBI ⁄ " (800 mm) ⁄ " (1105 mm) 24" (610 mm) 24" (610 mm) ⁄ " (239 mm) ⁄...
  • Page 5 VCS325SSBI/525SSBI Series Assembly VCS325SSBI / VCS525SSBI Framing Dimensions When Using Combustible Materials (ZC Insulated Jacket Required for Installation) Drain Holes (2" diameter) Drain Holes (2" diameter) B333a Ref. VCS325SSBI VCS525SSBI ⁄ " (846 mm) ⁄ " (1153 mm) ⁄ " (626 mm) ⁄...
  • Page 6 VCS325SSBI/525SSBI Series Assembly NOTE: Ensure your grill enclosure has been constructed according to the exact specifi cations shown in Figure 2. If the en- closure is constructed of wood or other similar combustible materials, the use of the insulated jacket Model VCS301SSIJ or VCS501SSIJ is required.
  • Page 7 VCS325SSBI/525SSBI Series Assembly Step 2: Assemble Brackets Parts Required: (1) Main Grill Unit (1) Left Bracket (1) Right Bracket (4) #10 x 1/2" Bolts (4) #10 Lock Nuts Figure 1 Prop up the front of the grill unit on a 2" or 3" block of wood or some other similar item. Remove the two (2) 1/4-20 x 3/8"...
  • Page 8 VCS325SSBI/525SSBI Series Assembly Step 3: Assemble the Rear Panel Parts Required: (1) Rear Panel (1) Back Flange (4) Self-tapping Screws Figure 2 Attach the back fl ange of the rear panel to the grill base with two (2) self-tapping screws. Fasten the ends of the rear panel to the left and right brackets with two (2) self-tapping screws.
  • Page 9 VCS325SSBI/525SSBI Series Assembly Step 4: Assemble the Grease Tray Front and Handle Parts Required: (1) Grease Tray Front (1) Handle (with screws) (2) #10 Bolts (2) #10 Nuts Figure 3 Remove the grease tray from the front of the grill base (below the control console). Remove the protective plastic from the grease tray front.
  • Page 10 VCS325SSBI/525SSBI Series Assembly Step 5: Install Backlighting Batteries and Battery Case into Battery Holder Bracket Parts Required: (1) Battery Case (8) ‘AA’ Batteries NOTE: Eight (8) ‘AA’ batteries are required for all grill models. (Not included) Figure 4 Install eight (8) batteries into supplied battery case, taking care of correct polarity. The battery holder bracket and wire connector are behind the lower left side of the console panel just below the left control knob.
  • Page 11 VCS325SSBI/525SSBI Series Assembly Step 6: Assemble the Grill Unit to the Enclosure NOTE: This step should be performed by two (2) persons wearing gloves. Figure 5 Before positioning the grill unit into the prepared enclosure or insulated jacket, depending on the available access, it may be necessary to temporarily disconnect the LP regulator or Natural Gas connector hose from the steel fl...
  • Page 12 VCS325SSBI/525SSBI Series Assembly Step 7: Install Internal Components Parts Required: VCS325SSBI VCS525SSBI (3) Sear Plates (5) Sear Plates (2) Cooking Grates (4) Cooking Grates (1) Warming Rack (1) Warming Rack (1) Smoker Box (Optional) (1) Smoker Box (Optional) Figures 6 & 7 Carefully place each of the sear plates side by side inside the grill by making sure the semicircular fi...
  • Page 13 VCS325SSBI/525SSBI Series Assembly Cooking Tips - Smoker Box • To produce more smoke and prevent fast burning, pre-soak the wood chips in a separate bowl of water for at least 20 minutes. • To add wood chips before cooking, fi ll the smoker box with your choice of fl avored chips (remove wood chips from water fi...
  • Page 14 149 Cleveland Drive • Paris, Kentucky 40361 www.vermontcastingsgroup.com...
