VCS3006 / VCS3506 ASSEMBLY PROCEDURES
Tools Required: knife or scissors, #2 and #3 Phillips or Robertson (square head) screwdriver,
7/16" and 3/8" wrench or ratchet, hammer, flat head screwdriver.
Step 1: Unpack Carton and Verify Contents
Use a sharp cutting tool to cut the straps on the packaging and then open the carton top. The sleeve
surrounding the barbecue can be removed by lifting it straight up and over the top of the unit. Unpack all
parts and c
ompare all contents to the parts list that accompanies this assembly manual.
protective plastic coverings from the metal parts
parts when removing the protective plastic. Refer to the parts list for fastener detail.
Some parts may have sharp edges; to avoid injury, wearing gloves during assembly is strongly
CAUTION:
recommended
. Be careful not to scratch or damage the finish of the metal
Page 1
Next,
remove the
50003807 01/06 Rev.0 En
