MXN -HD7DM Owner's Manual

Mxn mxn-hd7dm 7' 'tft digital lcd monitor
Hide thumbs Also See for MXN-HD7DM:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Owner's Manual
TFT DIGITAL LCD Monitor
for MXN-HD7DM - Owner's Manual
f

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MXN-HD7DM and is the answer not in the manual?

Questions and answers

Related Manuals for MXN MXN-HD7DM

Summary of Contents for MXN MXN-HD7DM

  • Page 1 TFT DIGITAL LCD Monitor for MXN-HD7DM - Owner’s Manual...

  • Page 2: Table Of Contents

    · · · · · · Package Contents Operation System Setting Function Picture Camera Set up Normal/Mirror Auto Picture Scan Camera Trigger Distance Marker Adjust Scan ON/OFF Function Lock ON/OFF Function Connection Installation Monitor installation with Stand bracket & Sunvisor Installation of heavy duty mounting brackets Specification...

  • Page 3: Package Contents

    PACKAGE CONTENTS CABLE CLIP BRACKET SCREWS MONITOR SUNVISOR SUNVISOR SCREWS STAND BRACKET MANUAL ITEM Q’TY MONITOR SUNVISOR SUNVISOR SCREW STAND BRACKET BRACKET SCREW CABLE CLIP CAMERA INPUT CABLE CAMERA INPUT CABLE MANUAL Owner’s Manual...

  • Page 4: Operation

    OPERATION A . DAY/NIGHT SENSOR (CDS) Automatic brightness control sensor. B . HEATER LAMP Orange color will be illuminated in case heater function is activated. C . MENU Press [MENU] button for system setting. D . SELECT Press [SELECT] button to select the respective camera channel. (CAM1-CAM2-CAM3-CAM1..) E .

  • Page 5: System Setting

    SYSTEM SETTING FUNCTION DIMMER (Automatic Brightness Control) Select AUTO to have Automatic or Manual brightness of the monitor. FUNCTION DIMMER AUTO/OFF REMARK: By activating REMARK: By activating DIMMER AUTO DIMMER AUTO function, the monitor adjusts the brightness function, the monitor adjusts the brightness LANGUAGE ENGLISH/…...

  • Page 6: Picture

    SYSTEM SETTING PICTURE PICTURE Press [ LEFT/RIGHT ] button to adjust preferred PICTURE of the monitor. CONTRAST 50 (0-100) BRIGHTNESS 50 (0-100) COLOR 50 (0-100) TINT 50 (0-100) CAMERA SET UP CAMERA SET UP TRIG. DELAY CAM1 TRIG. DELAY 2 SEC (0-9) CAM2 TRIG.

  • Page 7: Normal/Mirror

    NORMAL/MIRROR NORMAL/MIRROR NORMAL/MIRROR CAM1 NORMAL/MIRROR CAM2 NORMAL/MIRROR NORMAL/MIRROR Each camera picture (CAM1/CAM2/CAM3) can be switchable as image. CAM3 NORMAL/MIRROR UP/DOWN UP/UPSIDE DOWN UP/UPSIDE DOWN UP/DOWN Camera pictures can be switchable as image. AUTO PICTURE SCAN AUTO PICTURE SCAN Each scanning time of CAM1/CAM2/CAM3 can be selected. AUTO SCAN ON/OFF CAM1 SCAN TIME...

  • Page 8: Camera Trigger

    SYSTEM SETTING CAMERA TRIGGER CAMERA TRIGGER TRIGGER 1 CAM1/CAM2/CAM3 TRIGGER 1/2/3 (Trigger source selection) TRIGGER 2 CAM2/CAM3/CAM1 Select the required trigger source at CAM1/CAM2/CAM3. TRIGGER 3 CAM3/CAM1/CAM2 CAM1 DIST. MARKER MARKER ON/OFF REMARK REMARK SPEED SWITCH ON/OFF FREQUENCY 67 Hz TRIGGER PRIORITY: TRIGGER 1 >...

  • Page 9: Distance Marker Adjust

    DISTANCE MARKER ADJUST User can adjust location of distance marker. At Power mode, select distance marker by pressing [ ] buttons. UP/DOWN When color of distance markers is seen as color, user can adjust the lines DOWN LEFT/RIGHT When both color of distance markers are seen as color, both lines can be adjusted LEFT/RIGHT...

  • Page 10: Scan On/Off Function

    SYSTEM SETTING SCAN ON/OFF FUNCTION CAM1 CAM2 CAM3 Power-ON mode, hold [ ] buttons pressed for 4 seconds to activate Auto Scan SCAN SCAN SCAN Picture function. During the auto scanning mode, press [ ] button for 4 seconds to inactivate Auto Scan Picture function.

  • Page 11: Connection

    CONNECTION 7” TFT DIGITAL LCD Monitor Green White Blue S pee itch TACH SIGN NAL)- Orange r ou Black M ain 2 V / 4V DC via ignition (+15)- CAMERA INPUT Camera 1(Option) +12V DC OUTPUT, AUDIO INPUT HEATER & SHUTTER Camera 2(Option) +12V DC OUTPUT, POWER...

  • Page 12: Installation

    INSTALLATION MONITOR installation with STAND BRACKET & SUNVISOR Remove a protection tape and attach STAND BRACKET into stand place, then fix it with the supplied screws. Connect STAND BRACKET with monitor and adjust height/angle. Attach SUNVISOR to the MONITOR and fix it with the supplied screws. Connect CAMERA INPUT CABLE to the MONITOR.

  • Page 13: Installation Of Heavy Duty Mounting Brackets

    Installation of heavy duty mounting brackets MONITOR can be connected with different type of heavy duty mounting brackets. Please check the compatibility in advance, then please follow installation as described below. TYPE A(option) TYPE B(option) 30mm 40mm 38mm 38mm 38mm FMBK 5 10mm FMs 3.5 10mm Owner’s Manual...

  • Page 14: Specification

    Storage Temp. -30˚C to + 85˚C Impact Rating Camera Connector 4-pin mini DIN (MXN configuration) Housing Soft black(Al12) ON-Screen Display Volume · Brightness · Color · Contrast · Tint · CAM Screen 1/2/3 · CAM Trigger 1/2/3 · Heater ·...
  • Page 15 TFT DIGITAL LCD Monitor for MXN-HD7DM - Owner’s Manual 48 08 08 20...
