- Page 1 OWNER’S MANUAL PLEASE READ CAREFULLY BEFORE USING THIS PRODUCT. 7” DIGITAL TFT LCD ALL ROUND VISION MONITOR Model: MXN-P7D Design and specifications are subject to change without notice.
-
Page 2: Table Of Contents
· · · · · · Package Contents Operation System Setting Function Picture Camera Set up Normal/Mirror Auto Picture Scan Camera Trigger Distance Marker Adjust Scan ON/OFF Function Lock ON/OFF Function Connection Installation MONITOR installation with Stand bracket & Sunvisor Installation of heavy duty mounting brackets Specification... -
Page 3: Package Contents
▣ PACKAGE CONTENTS MANUAL MONITOR SUNVISOR STAND BRACKET CABLE CLIP CAMERA INPUT CABLE BRACKET SCREWS ITEM Q’TY MONITOR SUNVISOR STAND BRACKET BRACKET SCREW CABLE CLIP CAMERA INPUT CABLE MANUAL MXN-P7D Owner’s Manual... -
Page 4: Operation
▣ OPERATION RIGHT Press [RIGHT] button to adjust monitor volume. Use [RIGHT] button to change OSD setting during system setting. LEFT Press [LEFT] button to adjust monitor volume. Use [LEFT] button to change OSD setting during system setting. DOWN Press [DOWN] button to navigate the menu for system setting. Press [UP] button to navigate the menu for system setting. -
Page 5: System Setting
Heating activates automatically when the temperature of inside monitor is below 0 degree Celcius. When the temperature of inside monitor is over 0 degree Celcius, heating stops automatically. RESET Press > > button to go the factory default setting. SYSTEM INFO. Refers to system information of the monitor. MXN-P7D Owner’s Manual... -
Page 6: Picture
▣ SYSTEM SETTING PICTURE CONTRAST 50 (0-100) BRIGHTNESS 50 (0-100) COLOR 50 (0-100) TINT 50 (0-100) PICTURE Press [ ] button to adjust preferred of the monitor. LEFT/RIGHT PICTURE CAMERA SET UP CAM1 TRIG. DELAY 2 SEC (0-9) CAM2 TRIG. DELAY 2 SEC (0-9) CAM3 TRIG. -
Page 7: Normal/Mirror
AUTO PICTURE SCAN Each scanning time of CAM1/CAM2/CAM3 can be selected. REMARK: If the SCAN TIME is set as『0』 , monitor skips its channel during the scanning. Press [ ] button for 4 seconds to auto scanning function. ACTIVATE/INACTIVATE MXN-P7D Owner’s Manual... -
Page 8: Camera Trigger
▣ SYSTEM SETTING CAMERA TRIGGER TRIGGER 1 CAM1/CAM2/CAM3 TRIGGER 2 CAM2/CAM3/CAM1 TRIGGER 3 CAM3/CAM1/CAM2 CAM1 DIST. MARKER MARKER ON/OFF SPEED SWITCH ON/OFF FREQUENCY 67 Hz UNDER FREQ. CAM CAM3/CAM1/CAM2 OVER FREQUENCY DISPLAY ON/OFF OVER FREQ. CAM CAM1/CAM2/CAM3 CAMERA TRIGGER TRIGGER 1/2/3 (Trigger source selection) Select the required trigger source at CAM1/CAM2/CAM3. -
Page 9: Distance Marker Adjust
When left color of distance marker is seen as color, left line of distance marker can be adjusted LEFT/RIGHT When right color of distance marker is seen as color, right line of distance marker can be adjusted LEFT/RIGHT MXN-P7D Owner’s Manual... -
Page 10: Scan On/Off Function
▣ SYSTEM SETTING CAM1 CAM2 CAM3 SCAN SCAN SCAN SCAN ON/OFF FUNCTION mode, hold [ ] buttons pressed for 4 seconds to activate Auto Scan Picture Power-ON function. During the auto scanning mode, press [ ] button for 4 seconds to inactivate Auto Scan Picture function. -
Page 11: Connection
Blue Speed Switch(TACHO SIGNAL)- Orange Ground- Black Main power 12V/24V DC via ignition (+15)- Camera 1(Option) Camera 2(Option) Camera 3(Option) CAMERA INPUT +12V DC OUTPUT, HEATER & SHUTTER AUDIO INPUT +12V DC OUTPUT, POWER VIDEO INPUT GROUND MXN-P7D Owner’s Manual... -
Page 12: Installation
▣ INSTALLATION MONITOR installation with STAND BRACKET & SUNVISOR Remove a protection tape and attach STAND BRACKET into stand place, then fix it with the supplied screws. Connect STAND BRACKET with monitor and adjust height/angle. Connect SUNVISOR to the MONITOR. Connect CAMERA INPUT CABLE to the MONITOR. -
Page 13: Installation Of Heavy Duty Mounting Brackets
HEAVY DUTY MOUNTING BRACKETS. Please check the compatibility in advance, then please follow installation as described below. TYPE A(Option) 30mm 38mm 38mm FMBK 5×10mm TYPE B(Option) 40mm 38mm FMs 3.5×10mm MXN-P7D Owner’s Manual... -
Page 14: Specification
-25°C to + 75°C STORAGE TEMP. -30˚C to + 85˚C IMPACT RATING CAMERA CONNECTOR 4-Pin mini DIN (MXN configuration) HOUSING Light Black(ABS) Volume · Brightness · Color · Contrast · Tint · CAM Screen 1/2/3 · ON-SCREEN DISPLAY CAM Trigger 1/2/3 · Heater · Speedswitch · Auto Power · Distance CONTROL FUNCTIONS marker ·... - Page 15 ▣ MEMO MXN-P7D Owner’s Manual...
- Page 16 OWNER’S MANUAL PLEASE READ CAREFULLY BEFORE USING THIS PRODUCT. 7” DIGITAL TFT LCD ALL ROUND VISION MONITOR Model: MXN-P7D Design and specifications are subject to change without notice.
