Allnet ALL 1693 Quick Setup Manual

56 mbps powerline ethernet adapter
Hide thumbs
1
2
3
4
5
6
7

Advertisement

Quick Links

Download this manual
Q
S
G
Q
S
G
U
I
C
K
E
T
U
P
U
I
D
E
U
I
C
K
E
T
U
P
U
I
D
E
FOR
ALLNET 56 MBPS POWERLINE ETHERNET ADAPTER
A
L
L
1
6
9
3
A
L
L
1
6
9
3
ALL1693
© 2005 All rights reserved.
Page 1

Advertisement

loading
Need help?

Need help?

Do you have a question about the ALL 1693 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Allnet ALL 1693

Summary of Contents for Allnet ALL 1693

  • Page 1 ALLNET 56 MBPS POWERLINE ETHERNET ADAPTER ALL1693 © 2005 All rights reserved. Page 1...

  • Page 2: Important Safety Instructions

    REFACE This document describes installation of the ALLNET ALL1693 PowerLine adapter O THE NSTALLER This publication contains the following sections: Important safety instructions The first thing you need to know before you begin to install Product installation guide Specification MPORTANT...
  • Page 3 Unplug the Adapter from the wall outlet and refer the product to qualified personnel for the following conditions: When the interconnect cords are damaged or frayed. If liquid has been spilled into the product or If the product has been exposed to rain or water. If the product does not operate normally when the operating instructions are followed.
  • Page 4 Pentium® 166 MHz processor, equivalent or higher Resource on your PC At least one free Ethernet port for the ALLNET ALL1693 Ethernet PowerLine Adapter 2. Your PC must not be configured for another network. This means that: No network clients except for Microsoft Network*, Client for Netware* Networks, or Microsoft Family...
  • Page 5 5. Familiarize yourself with the ALLNET ALL1693 connections: 6. Limitation of the PLC device: To meet the safety regulation, the longest distance between PowerLine carrier devices will be limited at 100 meter and for in-house use only. More than 100 meter will cause the signal reduction or data loss.
  • Page 6 Product installation guide Important: Do not plug the device into a power strip or surge protector because these devices may consist of filter and impair signal. Also avoid plugging the device right next to noisy sources such as cell phone charger, Halogen light, noisy desktop computer, vacuum cleaner, etc. Both cases result in poor transmission speed.

  • Page 7: Specification

    Specification Items Description 56Mbps Line Rate Effect Data Rate Up to 16Mbps effective throughput Frequency Band 4.3~20.9 MHz Access Methods CSMA/CA 4 Levels OFDM (QAM 64/16, DBPSK, DQPSK) Modulation One Ethernet port Port Standards IEEE 802.3, IEEE 802.3U, HomePlug 1.0.1 Operating System Window 98 SE, Me, 2000,XP, MAC, Linux Nodes...
