Allnet ALL168205 Express-Setup

Allnet powerline ethernet adapter
Hide thumbs Also See for ALL168205:

Advertisement

Quick Links

E
X
P
R
E
S
S
-
S
E
T
U
P
E
X
P
R
E
S
S
-
S
E
T
U
P
for
ALLNET POWERLINE ETHERNET ADAPTER
A
L
L
1
6
8
2
0
5
A
L
L
1
6
8
2
0
5
ALL 168205 Express-Setup © 2007 . All rights reserved
Seite 1

Advertisement

loading
Need help?

Need help?

Do you have a question about the ALL168205 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Allnet ALL168205

  • Page 1 ALLNET POWERLINE ETHERNET ADAPTER ALL 168205 Express-Setup © 2007 . All rights reserved Seite 1...
  • Page 2 REFACE This document describes installation of the ALL168205 200Mbps PLC-Ethernet Bridge Network products. Please read this document before installing the product. O THE NSTALLER This publication contains the following sections: Important safety instructions The first thing you need to know before you begin to install...
  • Page 3: Important Safety Instructions

    Because the ALL168205 200Mbps PLC-Ethernet Bridge product sends data over the powerline, it is recommended that you plug directly into a power outlet. Do not plug the device into a UPS or power strip with surge protection. The ALL168205 200Mbps PLC-Ethernet Bridge product has its own power filter for protection against surges.
  • Page 4 3. Network installation requires two steps: Install the ALL168205 200Mbps PLC-Ethernet Bridge For each PC to be added to the network, repeat the process 4. Check that you have the following parts for each PC on the network:...
  • Page 5 ALL 168205 Express-Setup © 2007 . All rights reserved Seite 5...
  • Page 6 5. Familiarize yourself with the Powerline device connections: 6. Limitation of the PLC device: To meet the safety regulation, the longest distance between powerline carrier devices will be limited at 100 meter and for in-house use only. More than 100 meter will cause the signal reduction or data loss. ALL 168205 Express-Setup ©...
  • Page 7 Product installation guide Important: Do not plug the device into a power strip or surge protector because these devices may consist of filter and impair signal. Also avoid plugging the device right next to noisy sources such as cell phone charger, Halogen light, noisy desktop computer, vacuum cleaner, etc. Both cases result in poor transmission speed.
  • Page 8: Specification

    Specification Specification Specification Specification Items Description Line Rate 200Mbps Effect Data Rate TCP: Up to 65 Mbps effective throughput UDP: Up to 85 Mbps effective throughput Frequency Band 2~28 MHz (With Mask) Access Methods CSMA/CA channel-access schemes Four-level priority based contention access, and multi segment bursting 8-levels VLAN priority field Modulation...
  • Page 9 ALL 168205 Express-Setup © 2007 . All rights reserved Seite 9...
