Introduction

Welcome to Kramer Electronics (since 1981): a world of unique, creative and
affordable solutions to the infinite range of problems that confront the video,
audio and presentation professional on a daily basis. In recent years, we have
redesigned and upgraded most of our line, making the best even better! Our
500-plus different models now appear in 8 Groups
by function.
Congratulations on purchasing your Kramer VP-740HC ScaleMagix 2 ™,
which is ideal for the following typical applications:
Home cinema central visual switcher
Presentation
Educational, industrial, points of sale, churches and other large audience
applications
The package includes the following items:
VP-740HC ScaleMagix 2 ™
Power cord
This user manual
2

Getting Started

We recommend that you:
Unpack the equipment carefully and save the original box and packaging
materials for possible future shipment
Review the contents of this user manual
Use Kramer high performance high resolution cables

2.1 Quick Start

This quick start chart summarizes the basic steps when connecting a VP-740HC
ScaleMagix 2 ™:
1 GROUP 1: Distribution Amplifiers; GROUP 2: Video and Audio Switchers, Matrix Switchers and Controllers; GROUP 3:
Video, Audio, VGA/XGA Processors; GROUP 4: Interfaces and Sync Processors; GROUP 5: Twisted Pair Interfaces;
GROUP 6: Accessories and Rack Adapters; GROUP 7: Scan Converters and Scalers; and GROUP 8: Cables and Connectors
2 We recommend that you use only the power cord that is supplied with this machine
3 Download up-to-date Kramer user manuals from the Internet at this URL: http://www.kramerelectronics.com
4 The complete list of Kramer cables is on our Web site at http://www.kramerelectronics.com
Introduction
2
, Null-modem adapter and infra-red remote control transmitter
3
1
, which are clearly defined
4
1
