3.1.1.

Technical specifications

Technical specifications
Fuel type
Hourly consumption
Global heat output Max
Global heat output Min:
Efficiency
3
Heatable volume m
Recommended draught
Smoke temperature
Particulate
Smoke outlet
Combustion chamber dimensions
Net weight
External combustion air inlet
CO emission in the smoke (13 %O
Smoke flow rate
Flue pipe
Flue pipe cross-section
Minimum flue pipe height
Notes
The stove is an intermittent combustion appliance
* These data may vary according to the type of fuel
used
Dimensions and technical specifications
USE AND MAINTENANCE MANUAL
)
2
Veld natural/air
Wood - logs
2.05 Kg/h – 1.4 kg/h
KW 7/Kcal 6020
KW 3.5/Kcal 3010
84,7 %
151/40 – 172/35 – 201/30
12 Pa / 0,12 mbar
240 °C
30 mg/Nm3 (13% O2)
17 mg/MJ
Ø 15 cm
33 x 25 - h 43
Kg 175
cm² 200
0,09 %
6.9 g/s
18x18 cm Ø18
4 m
