- Page 1 Charge Equaliser CE25 CE40...
- Page 2 THE CHARGE EQUALISER The Charge Equaliser operates in a two battery 24V DC negative earth system. The Output Voltage of the Charge Equaliser is regulated to half the Input Voltage. 12V power is available from the lower battery in a 24V system via the centre tap (bridging link). The Charge Equaliser ensures that the voltage across the lower 12V battery (I.e.
- Page 3 SPECIFICATIONS CE25 CE40 Input Voltage Range 20V-32V 20V-32V Output Voltage Range 6V-16V 6V-16V No Load Current <100mA <100mA Standby Current <10mA <10mA Input Fuse Rating (24V) 40A (Not supplied) 50A (Not supplied) Output Fuse Rating 40A (Not supplied) 50A (Not supplied) Output Current (Max.)
- Page 4 Friendly, personalised, professional service and product support In the unlikely event that a technical issue arises with a Redarc product, customers are encouraged to initially contact the Redarc Technical Support Team on (08) 8322 4848 In the unlikely event that a technical issue arises with a Redarc product, customers are encouraged to initially contact the Redarc Technical Support Team on (08) 8322 4848 or or power@redarc.com.au...
