Page 1: User Manual
ZM Series Monitors User Manual ENGLISH bandg.com... - Page 2 Preface As Navico is continuously improving this product, we retain the right to make changes to the product at any time which may not be reflected in this version of the manual. Please contact your nearest distributor if you require any further assistance. It is the owner’s sole responsibility to install and use the equipment in a manner that will not cause accidents, personal injury or property damage.
-
Page 3: Table Of Contents
Shortcut functions OSD menu Updating the firmware Checking current firmware version Installing an Update Dimensional drawings Troubleshooting tips Cleaning and maintenance Display removal Replacing the gasket Replacing the filters Other maintenance General specifications Accessories Contents | ZM Series User Manual... -
Page 4: Introduction
Introduction The B&G ZM Series monitors offer a low profile, high brightness solution for displaying video from a variety of sources. This includes two models; the ZM16”, and ZM19” Touch monitors. These models are suited for both indoor and outdoor use. Both monitors accept video via HDMI, DVI-I and composite inputs. -
Page 5: Display Installation
Fixing options The ZM series monitors can be dash or bracket mounted (using optional VESA adaptor). When dash mounting, unit should be fitted using the rear mounted dash mount brackets, and bezel screws from the front. Exclusion of the dash mount bracket will greatly increase strain on bezel screws and adjacent bezel plastics, and is not recommended. -
Page 6: Flush Mounting The Display
5mm of threaded rod protrudes through other side of bracket. Fit stopper foot on to end of wing screw. Complete for both threaded holes on each bracket. Display installation | ZM Series User Manual... - Page 7 Once flush with front surface of screen, slide top bezel to the left, and bottom bezel to the right to lock in to place. Display installation | ZM Series User Manual...
-
Page 8: Vesa Mounting The Display
- do not install monitor in such a place where it may be used as a handhold, or have additional equipment attached to it. Display installation | ZM Series User Manual... -
Page 9: Connecting The Display
Connecting the display The ZM series monitors largely use industry standard cables, which can be purchased pre- terminated in a variety of lengths. The following chapter provides additional detail where cables require field termination by the installer. Rear connections Connection... -
Page 10: Connecting Power
In certain problematic installations it may help stabilize touch screen sensitivity, ie. prevent ‘false’ touches, or non-registered touches. Recommended fuse rating Model ZM16-T ZM19-T Fuse 3 amp 4 amp Connecting the display | ZM Series User Manual... -
Page 11: Connecting Touch Control
Connecting touch control The touch screen ZM series monitors can provide touch control to the Zeus Processor as well as Windows 7 and Windows 8 PCs. Connection can be made via serial data for Zeus Processor or USB for PC systems. -
Page 12: Typical Installation
Micro-C network drop cable - allows software updating of monitor via Zeus Processor Power cable - Zeus Processor ¼ Note: peripheral devices in diagram do not necessarily show all required connections where not directly related to ZM series monitor. 10 | Connecting the display | ZM Series User Manual... -
Page 13: Operating The Display
Adjusts image contrast (range Contrast between darkest and lightest ) Display 0-100 Shifts colours represented by screen (analogue video only) Saturation Varies colour intensity, from dull to full and rich (analogue video only) | 11 Operating the display | ZM Series User Manual... - Page 14 Vertical Adjusts vertical position, where 0 = left, and 100 = right Option Sub option Description English French German Language Select language best suited for OSD text Spanish Italian Portuguese 12 | Operating the display | ZM Series User Manual...
-
Page 15: Updating The Firmware
USB touch control is automatically enabled upon connection. Updating the firmware Updates to the ZM series monitor firmware may occasionally become available. The updates will typically include improvements to existing functionality or new features, and will be made available via the B&G website: www.bandg.com. -
Page 16: Dimensional Drawings
Dimensional drawings ZM16: 383mm ZM19: 461mm MAX 25.4 mm (1.00") ZM16: 400mm ZM19: 478mm 8 mm (0.31") 66.0 mm (2.60") MAX 88.0 mm (3.46") 14 | Dimensional drawings | ZM Series User Manual... -
Page 17: Troubleshooting Tips
Video compromised by interference from other equipment Vertical shaded bars on Incoming video may be in 4:3 ratio, either leave in ‘aspect’ mode, screen image or set to ‘fill’ to use full screen space. | 15 Troubleshooting tips | ZM Series User Manual... -
Page 18: Cleaning And Maintenance
The backing paper on outside of gasket will help prevent stretch, and should only be removed when display is ready to install in to dashboard. 16 | Cleaning and maintenance | ZM Series User Manual... -
Page 19: Replacing The Filters
The operator should never remove the display unit cover or attempt to service the equipment. Any attempt to do so may make the warranty invalid. | 17 Cleaning and maintenance | ZM Series User Manual... -
Page 20: General Specifications
(8-32 bit colour, 25, 29, 30 Hz Interlaced) 1024 x 768 (8-32 bit colour, 60 Hz) ¼ Note: Occasionally specifications may change - refer to the latest edition of the manual on the website: www.bandg.com 18 | General specifications | ZM Series User Manual... -
Page 21: Accessories
000-11248-001 HDMI cable (10m) 000-11249-001 Connector kit (power and serial plugs) 000-11625-001 ¼ Note: Occasionally available accessories may change - refer to the latest edition of the manual on the website: www.bandg.com | 19 Accessories | ZM Series User Manual... - Page 23 0980...
