Acewell ACE-3252 User Manual

ACE-3252/3968-XX User Manual
Thanks for purchasing this ATV/Motorcycle computer. This manual
is specifically designed for ACE-39XX-XX series ATV/Motorcycle
computers. The ACE-3252 does not have any extra LED indicators.
The ACE-395X-XX series has 4-8 LED indicators. ACE-3968-XX
has aluminum CNC cases and ACE-395X has plastic housing.
Different model has different LED indicators; all other functions are
the same. You may find that the photo has a set of LED indicators
different from your computer; the photo is for reference only.
PANEL DESCRIPTIONS
1. Tachometer Scale
2. Bar Tachometer
3. 1st row: Current & Max. 8. Thermometer Bar
Speedometer
nd
4. 2 row: Other functions
5. RESET Button
Different model has different LED indicators, each indicator symbol
means as bellows:
FEATURES
 Displays bar-graphic tachometers, speedometer, bar fuel
meter, bar thermometer,
and one of other functions at the same time.
 Optional bar-graphic tachometer scale of 8,000rpm or 16,000
rpm for different bikes.
 Allows end user to adjust odometer when the odometer is less
than 30 km, after that the odometer is always stored in
memory even when the power is off.
 The main unit built-in 4-8 LED indicators for different
purpose application.

Three options fuel meter input resistance 100, 250 and 510Ω
are available.
 Universal speed sensing circuit for reed sensor and hall
sensor.

Includes bracket, RPM sensing wire, speed
sensor, thermo sensor, fitting kits and wiring
harness.

Water resistance, vibration (10G) and mechanical shock
(100G) resistances
SPECIFICATIONS
FUNCTIONS SYMBOL
Bar Tachometer
Digital Tachometer rpm
Speedometer
Digital Thermometer ℃ or ℉
Bar Temperature Meter bar
MAX
Maximum Thermometer
℃/℉
TRIP 1&2
Trip meter 1&2
ODO
Odometer
MAX
Maximum speed
AVG
Average speed
Bike Computer
6. MODE Button
7. Fuel Bar
9. Rpm Warning Indicator
10. Temperature Warning LED
digital gear indicator, speed pacer
tested.
Specifications
250-8,000 rpm
500-16,000rpm options
10-19,990 rpm,
2.4-399.9 km/h (248.5 MPH)
℉ ℉
+50℃-180℃ / 122 -356
1-7 Bar-graphic
℉ ℉
+50℃-180℃ / 122 -356
0.1 Km/Miles
0.0-9999.9 KM/Miles
0.0 - 99999.9 KM, 0.0-
62499.9 Miles
2.4-399.9 KM/h (248.5 0.1km/h or
MPH), MPH
2.4-399.9 KM/h (248.5 0.1km/h or
12/24 Hour Clock
Riding timer
Total Riding Timer
Voltage Gauge
Bar-Fuel Meter
Digital Gear Indicator
Power Input
Tachometer Sensor
Speed Sensor
Temperature Sensor
Wheel circumference setting 1mm-3999mm
Dimensions
Operation Temperature:
Storage Temperature:
FUNCTIONS
BAR RPM: Bar Graphic Tachometer
The bar tachometer has 8,000rpm and 16,000rpm options.
RPM: Digital Tachometer
1. It displays digital tachometer up to 19,900RPM.
2. Tachometer signal can pick up from either CDI or Sparking
plug.
: Shift Warning RPM
1. The function enables you to set up a shift warning RPM.
2. Shift warning LED indicator flashes amber when RPM reaches
500rpm in front of the setting value, then flashes red when
RPM reaches setting value, and stop flash after you shift gear.
MAX RPM: Maximum Tachometer
Displays highest tachometer achieved after last Reset operation.
SPD: Speedometer
Displays speed meter up to 399.9 Km/H or 248.5 MPH.
MAX: Maximum Speed Meter
Displays highest speed achieved after last Reset operation.
AVG: Average Speed Meter
It calculates average speed from last RESET.
TRIP 1&2: Trip Meter 1 & 2
1. TRIP function accumulates trip distance from last RESET as long
as bike is being ridden.
2. Trip 2 will be reset to zero automatically when last fuel bar
flashes.
ODO: Odometer
ODO accumulates total accumulated distance traveled during
1.
bike moving.
ODO data is adjustable when it is less than 30km (Miles), after
2.
that it stored in memory and couldn't be reset.
RT: Riding Timer
1. Calculates total operation time from last RESET.
2. Count automatically begins with movement.
TT: Total Riding Timer
1. Calculates total operation time from the beginning of the bike.
2. TT data is stored in memory, and couldn't be reset.
12/24 hour Clock
:
Displays 12 or 24 hour current time.
: Bar Thermometers:
Increments
Have 7 bars to indicate engine temperature and always
displayed. The warning LED indicator flashes to remind rider.
250rpm
℃ ℉
500rpm
/ : Digital Thermometer
10rpm
1. It displays -L-
0.1km/h or
℉
122 , and displays -H-
MPH
℃
180
1℃ /℉
2. The LCD screen will automatic change to temperature
screen and flashes the digits of temperature when the thermo
1℃ /℉
sensor detects temperature over the presetting warning
temperature; The MODE key is out of function until the
temperature cooling down and lower than the presetting
warning temperature
0.1km/miles
℃ ℉
MAX
Displays highest temperature achieved after last Reset operation.
• : Speed pacer:
MPH),
0:00' – 11H59'/23H59'
RT 0-99H59`59``
TT 0-9999H59'
V 6.0-36.0 Volt
BAR 100Ω, 250Ω, 500Ω options
n-8 gears
DC 12V
CDI or Ignition Coil Signal
Reed or Hall-effect Sensor
Thermo Sensor
130x78x30.5mm (ACE-395X-XX)
125x78x28.5mm (ACE-395X)
95.2x72x27mm (ACE-3250)
°
-20 C - +80
°
-30 C - +90
℃
℉
or -L- when temperature is lower than 50
℃
or –H-
℉
or 356 .
/ : Maximum Thermometer
MPH
1 Minute
1 second
1 Minute
0.1V
°
C (inner housing)
°
C (Inner housing)
℃
or
℉
when temperature is over
