Installation, Operation
and Maintenance Manual
3-Stage Ultraviolet Systems
Model PWDWUV3
PURE WATER
Important
Please read the entire manual before proceeding with the
installation and startup. Your failure to follow any attached
instructions or operating parameters may lead to the product's
failure.
Save manual for future reference.
This system has been designed to fit under most kitchen sinks.
DO NOT TOUCH THE UV LAMP OR QUARTZ TUBE AT ANY
TIME WITH BARE HANDS OR FINGERS.
Fingerprints or skin oils on the lamp and tube assembly may reduce
UV functionality.
This system requires a GFCI electrical outlet at point of
installation.
Table of Contents
Mounting System Under Sink . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Installation of Faucet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Adapt-A-Valve™ Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Start up Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Recommended Replacement Schedule. . . . . . . . . . . . . . . . . . . . . . . 5
Filter Element Cartridges . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Filter Change . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
UV Lamp, Cap and Quartz Tube . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Parts List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Limited Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Do not use with water that is microbiologically unsafe or
Note:
of unknown quality without adequate disinfection before or after
the system. Systems certified for cyst reduction may be used
on disinfected waters that may contain filterable cysts.
IOM-WQ-PWDWUV3
PWDWUV3
Pages
Advertisement
Table of Contents
Related Manuals for Watts PWDWUV3
Summary of Contents for Watts PWDWUV3
-
Page 1: Table Of Contents
IOM-WQ-PWDWUV3 Installation, Operation and Maintenance Manual 3-Stage Ultraviolet Systems Model PWDWUV3 PURE WATER Important Please read the entire manual before proceeding with the installation and startup. Your failure to follow any attached instructions or operating parameters may lead to the product’s failure. -
Page 2: Mounting System Under Sink
Introduction STEP 2 Thank you for your purchase of a Watts Pure Water under coun- Drill a Hole for the Faucet in a Porcelain Sink ter filtration system with UV. With proper installation and mainte- Note: Most sinks are predrilled with 1½" or 1¼" diameter hole nance, this system will provide you with high-quality water for years that you can use for your RO faucet. -
Page 3: Installation Of Faucet
Non-Airgap Faucet Installation STEP 3 Standard Faucet Installation 1. Long Reach Spout 2. Handle 3. Faucet Body 4. Escutcheon Plate 5. Black Rubber Washer 6. Stem Bolt 7. Black Locating Washer 8. Small Black Washer 9. Star Washer 10. Lock Nut 11. -
Page 4: Adapt-A-Valve™ Installation
STEP 4 Start Up Instructions Adapt-A-Valve™ Installation Step A Lift black faucet handle up on faucet to start flow of water through unit. Run 7 gallons of water through unit. Close Verify contents prior to installation: faucet. ( 1 ) - Plastic Adapt-a-Valve™ & Black Collet Note: You may hear some noise as air is being purged from the ( 1 ) - Brass Adapter no washer unit and the first few glasses of water through the unit may be... -
Page 5: Recommended Replacement Schedule
Recommended Replacement Schedule Filter Element Cartridges Ultra Violet Bulb Replacement Watts recommends changing the filter element cartridges at least Warning: Do not touch UV Lamp or Quartz Tube with bare every 6 months or 1350 gallons (5100 liters). fingers or hands. Fingerprints on the lamp or tube may reduce lamp effectiveness. -
Page 6: Parts List
Parts List TRANSFORMER CHROME FAUCET UV MODULE 1/4” BLUE TUBE 1/4” 1/4” WHITE WHITE TUBE TUBE KITCHEN SINK 1/4” GREEN TUBE FEED WATER ADAPT-A-VALVE MAIN WATER SUPPLY SHUT-OFF VALVE SEDIMENT CARBON FILTER BLOCK iteM # description Adapt-A-Valve™ Elbow - 1/4" QC X 1/4" M Filter Housing - Lid - 1/4"... -
Page 8: Limited Warranty
WArrAnty: Certain Watts Pure Water products come with a limited warranty from Watts Regulator Co. Other products may have no warranty or are covered by the original manufacturer’s warranty only. For specific product warranty information, please visit www.watts.com or the published literature that comes with your product. Any remedies stated in such warranties are exclusive and are the only remedies for breach of warranty.
