Installation, Operation
and Maintenance Manual
One-Piece Manifold Reverse Osmosis System
Model PWRO5MAN
PURE WATER
Important
Please read the entire manual before proceeding with the
installation and startup. Your failure to follow any attached
instructions or operating parameters may lead to the product's
failure.
Save manual for future reference.
System tested and certified by NSF International
against NSF/ANSI Standard 58 for the reduction
of the claims specified on the performance data
sheet .
Do not use with water that is microbiologically unsafe or
Note:
of unknown quality without adequate disinfection before or after
the system . Systems certified for cyst reduction may be used
on disinfected waters that may contain filterable cysts .
PWRO5MAN
Table of Contents
Operational Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Contents of Reverse Osmosis System . . . . . . . . . . . . . . . . . . . . . 3
Tools Recommended For Installation . . . . . . . . . . . . . . . . . . . . . . 3
Drill a Hole for the Faucet in a Porcelain Sink . . . . . . . . . . . . . . . . 3
Punch a Hole for the Faucet in a Stainless Steel Sink . . . . . . . . . . 3
How to use Quick-Connect Fittings . . . . . . . . . . . . . . . . . . . . . . . 4
Watts Chrome Top Mount Faucet Installation . . . . . . . . . . . . . . . . 5
Adapt-A-Valve™ Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Drain Saddle Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Green Tube Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Reverse Osmosis Module Mounting . . . . . . . . . . . . . . . . . . . . . . 6
Red Tube Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Check Air Pressure in the Tank . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Tank Elbow Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Blue Tube Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Blue Tube to Faucet Connection . . . . . . . . . . . . . . . . . . . . . . . . . 7
Final Filter Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Startup Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
6-Month Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Annual Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Membrane Replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Procedure for Extended Non-Use . . . . . . . . . . . . . . . . . . . . . . . 10
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Arsenic Facts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Parts List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Service Record . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Limited Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
IOM-WQ-PWRO5MAN
