Series PWFGAC, PWFMZ, PWFCAL
Installation, Operation
and Maintenance Manual
WARNING
!
Read this Manual BEFORE using this equipment.
Failure to read and follow all safety and use information can
result in death, serious personal injury, property damage, or
damage to the equipment.
Keep this Manual for future reference.
WARNING
!
You are required to consult the local building and plumbing
codes prior to installation. If the information in this manual
is not consistent with local building or plumbing codes,
the local codes should be followed. Inquire with governing
authorities for additional local requirements.
WARNING
!
Need for Periodic Inspection/Maintenance: This product must
be tested periodically in compliance with local codes, but at least
once per year or more as service conditions warrant. All prod-
ucts must be retested once maintenance has been performed.
Corrosive water conditions, and/or unauthorized adjustments or
repair could render the product ineffective for the service intended.
Regular checking and cleaning of the product's internal compo-
nents helps assure maximum life and proper product function.
WARNING
!
Do not use with water that is microbiologically unsafe or of un-
known quality adequate disinfection before and after the system.
NOTICE
Hydrocarbons such as Kerosene, Benzene, Gasoline,
etc., may damage products that contain O-rings or plastic
components. Exposure to such hydrocarbons may cause the
products to leak. Do not use the product(s) contained in this
document on water supplies that contain Hydrocarbons such
as Kerosene, Benzene, Gasoline, etc.
PWFGAC PWFMZ PWFC Series
Table of Contents
System Specification Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
General Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-4
How to Use this Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Control Valve Function and Cycles of Operation . . . . . . . . . . . . . . . . . . . . 4
Installation Preview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Pre-Installation Considerations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
General Installation Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Bypass Valve Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Move Filter System Into Place . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Connect the Drain Line . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Start Up. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
PWF System Programming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
PWF Quick Programming Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
PWF OEM System Setup Programming. . . . . . . . . . . . . . . . . . . 12-13
PWF Installer Display and Settings. . . . . . . . . . . . . . . . . . . . . . . 14-15
PWF User Displays . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15-16
NOTES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
IOM-WQ-PWFGAC-PWFMZ-PWFCAL
Advertisement
Table of Contents
Related Manuals for Watts PWFGAC1
Summary of Contents for Watts PWFGAC1
-
Page 1: Table Of Contents
IOM-WQ-PWFGAC-PWFMZ-PWFCAL Series PWFGAC, PWFMZ, PWFCAL Installation, Operation and Maintenance Manual WARNING Read this Manual BEFORE using this equipment. Failure to read and follow all safety and use information can result in death, serious personal injury, property damage, or damage to the equipment. Keep this Manual for future reference. -
