Summary of Contents for Lava Lava SSerial-550
- Page 1 Lava SSerial-550 Installation Manual SSERIAL BOARD LAVA COMPUTERS MADE MOKO L16.3E CANADA Rev. B00...
- Page 2 Hardware Set-Up Address Block Address Block Configuration (COM Settings) COM-1 COM-2 03F8h 02F8h default COM-3 COM-4 03E8h 02E8h IRQ Block IRQ Block Configuration IRQ-4 IRQ-3 default IRQ-5 IRQ-7...
-
Page 3: Serial Configuration
Serial Configuration 1. Put only one jumper on each jumper block, to represent the desired Com & IRQ setting. 2. If you have only one Com port, set up the SSerial-550 for Com 2 and IRQ 3. 3. It is recommended that each Com Port be assigned a unique IRQ by the user. -
Page 4: Technical Support
(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Lava Computer MFG Inc. 908 Niagara Falls Blvd. #629. North Tonawanda NY 14120-2060...
