Lava SSerial-PCIe Datasheet

LAVA The Source for Ports
LAVA SSerial-PCIe
PCIe Bus Single 16550 Serial Board
Features & Benefits
! Adds one 9-pin 16550 UART serial port to PCIe
equipped PCs
!
Port is capable of a maximum throughput rate of
115.2 kbps
!
Easy Plug and Play installation—automatically
selects next available IRQ and I/O addresses
!
Includes LAVA Com Port Redirect Utility for
renaming Com ports—allows for backward
compatibility with software that supports Com 1-4
only
! Compatible with any RS-232 serial peripheral
!
LAVA Lifetime Warranty
Connectors
!
One DB-9 male RS-232
System Requirements
!
PCIe host slot (1x, 2x, 4x, 8x, 16x), low -profile
chassis
!
Windows OS
Drivers ship with product. For updated software
support visit www.lavalink.com
2 Vulcan Street
Tel: 416.674.5942
Toronto, ON Fax: 416.674.8262
Canada M9W 1L2 Email: sales@lavalink.com
.
Copyright ©
LAVA Computer MFG Inc.
Printed in Canada.
Specifications subject
to change without notice.
www.lavalink.com
