NEC Express5800/R120f-1E System Configuration Manual page 5

SYSTEM CONFIGURATION GUIDE
Model
Memory
Internal Storage
Expansion Slots
Video
Interfaces
Server Management
Redundant Fan
Redundant Power Supply
Power Supply
Power
Consumption
Acoustical Noise
(Sound Pressure
3
Level)
Dimensions (W x D x H )
Weight (Minimum / Maximum)
Temperature, Relative Humidity
(non-condensing)
Regulatory and Safety
NEC Corporation
–
NEC Express5800R120f-1E
Type
Standard Capacity
Maximum Capacity
Memory protection
Standard Capacity
Maximum Capacity
Disk Controller
RAID
Hot Plug
Optical Disk Drive
Optical Drive Bays
Disk Drive Bays
Standard
Optional Riser Card
N8116-39
( )
Optional Riser Card
N8116-33
( )
Controller (VRAM)
Resolution / Color
(Max. Config, Idling)
(Max. Config,
Operating)
Max. Config, Idling
Max. Config, Operating
Revision 6.0 – July 16, 2015
R120f-1E
DDR4-2133 Registered DIMM
DDR4-2133 Load Reduced DIMM
0 GB
512 GB (16 x 32 GB)
ECC, x4 SDDC, Memory Mirroring, Memory Lockstep, Memory
Sparing
0 GB
SAS HDD : 14.4 TB (8 x 1.8 TB)
SATA HDD : 16 TB (8 x 2 TB)
SAS SSD : 3.2 TB ( 8 x 400 GB)
SATA SSD : 6.4 TB (8 x 800 GB)
SATA : 6Gb/s (Integrated)
SAS: 12 Gb/s (Optional)
SATA : RAID 0/1/5/6/10/50/60 (Optional)
SAS : RAID 0/1/5/6/10/50/60 (Optional)
Supported
Optional
1
8
Total: 3 slots available
1 PCIe 3.0 x8 (x8 connector)
1 PCIe 3.0 x8 (x8 connector) dedicated RAID slot
1 PCIe 3.0 x8 (x8 connector) flexible integrated NIC slot
Total: 4 slots available
2 PCIe 3.0 x8 (x8 connector)
1 PCIe 3.0 x8 (x8 connector) dedicated RAID slot
1 PCIe 3.0 x8 (x8 connector) flexible integrated NIC slot
Total: 4 slots available
2 PCIe 3.0 x16 (x16 connector)
1 PCIe 3.0 x8 (x8 connector) dedicated RAID slot
1 PCIe 3.0 x8 (x8 connector) flexible integrated NIC slot
Integrated in Server Management Controller (32MB)
1
1600 x 1200 / 16.7M
2 x VGA (15-pin mini D-sub, 1 x front, 1 x rear)
1 x Serial (9-pin mini D-sub, RS232-C, Serial A, 1 x rear)
4 x USB3.0 (2 x front, 2 x rear)
1 x Management LAN connector (RJ-45, 1 x rear)
EXPRESSSCOPE Engine 3
Standard, hot plug
Optional, hot plug
1-2 x 460 Watt or 800 Watt 80 PLUS® Platinum certified hot plug
PSU, or 800 Watt 80 PLUS® Titanium certified hot plug PSU
100-240 VAC ± 10% 50 / 60 Hz ± 3 Hz
191 VA 194 VA
/ 189 Watt / 192 Watt
602 VA 649 VA
/ 598 Watt / 645 Watt
45.2 dB 45.2 dB
53.8 dB 54.0 dB
439.8 x 722.0 x 43.4 mm / 17.3 x 28.4 x 1.7 in (1U)
14.6 kg / 21.0 kg, 32.18 lbs. / 46.29 lbs.
Operating: 10° to 40° C / 50° to 104° F, 20 to 80%
Non-Operating: -10° to 55° C / 14° to 131° F, 20 to 80%
FCC, UL, CB, CE, BSMI, UL(Mexico), KC, CCC, RCM, RoHS,
WEEE
185 VA 194 VA
/ 184 Watt / 193 Watt
540 VA 658 VA
/ 537 Watt / 653 Watt
45.2 dB 45.2 dB
55.3 dB 54.0 dB
5
